Bosch Spare Parts for High Pressure Cleaner GHP 5-75
€21.23
VAT included
Bosch Spare Parts for High Pressure Cleaner GHP 5-75
Bosch genuine replacement parts for to replace broken parts for to fix High Pressure Cleaner GHP 5-75 - 3600J10700.
Bosch Spare Parts for High Pressure Cleaner GHP 5-75
€21.23
VAT included
Bosch Spare Parts for High Pressure Cleaner GHP 5-75
Bosch genuine replacement parts for to replace broken parts for to fix High Pressure Cleaner GHP 5-75 - 3600J10700.
settings
107 spare parts
description
4 exploded views
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
107 spare parts
Page 1
zoom_in View exploded
local_shipping ON DEMAND ONLY
Page 2
zoom_in View exploded
local_shipping ON DEMAND ONLY
Page 3
zoom_in View exploded
local_shipping ON DEMAND ONLY
Page 4
zoom_in View exploded
local_shipping ON DEMAND ONLY
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
501/1
|
photo_cameraImage coming soon | 1619PA9742 Trigger | €20.02 | |
|
501/2
|
photo_cameraImage coming soon | 1619PA9743 Spring | €8.15 | |
|
501/3
|
photo_cameraImage coming soon | 1619PA9744 Lock | €11.07 | |
|
501
|
photo_cameraImage coming soon | F016L73068 Handle | €47.96 | |
|
502
|
photo_cameraImage coming soon | F016L73327 Jet Pipe | €47.96 | |
|
503
|
photo_cameraImage coming soon | F016L73384 Jet Pipe | €87.77 | |
|
504
|
photo_cameraImage coming soon | F016F04524 Hose | €129.61 | |
|
511
|
photo_cameraImage coming soon | F016L73351 Filter | €26.32 | |
|
512
|
photo_cameraImage coming soon | F016L73352 Filter | €26.32 |
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Bosch Spare Parts for High Pressure Cleaner GHP 5-75
Bosch genuine replacement parts for to replace broken parts for to fix High Pressure Cleaner GHP 5-75 - 3600J10700.In the following table, look for the model of the Cleaner and the respective parts of the code.
| Pressure Cleaner GHP 5-75/3 600 J10 700 | ||
| # | Part Num. | Description |
| 1 | F016L73283 | Housing |
| 2 | F016L72008 | Knob |
| 3 | F016L73028 | Rubber Base |
| 4 | F016L73029 | Accessory Deposit |
| 5 | F016L73284 | Housing |
| 6 | F016L73031 | Cover |
| 7 | F016L73032 | Accessory Deposit |
| 8 | F016L73033 | Housing part |
| 9 | F016L73034 | Housing part |
| 10 | F016L73336 | Rod |
| 11 | F016L73036 | Handle |
| 12 | F016L73037 | Accessory Deposit |
| 13 | F016L73038 | Accessory Deposit |
| 14 | F016L73039 | Adjustment Knob |
| 15 | F016L73040 | Cover Plate |
| 16 | F016L73041 | Water filter |
| 17 | F016L73239 | Suction Pipe |
| 18 | F016L73053 | Screw |
| 19 | F016L73044 | Housing |
| 20 | F016L73045 | Wheel Shaft |
| 21 | F016L73046 | Wheel |
| 22 | F016L73047 | Plain Washer |
| 23 | F016L73048 | Cover |
| 24 | F016L72122 | Safety Cover |
| 25 | F016L72010 | Adapter |
| 26 | F016L73591 | Filter |
| 27 | F016L72119 | Rubber Base |
| 28 | F016L72012 | Screw |
| 29 | F016L72187 | Screw |
| 30 | F016L73337 | Plastic-Cutting Screw |
| 31 | F016L73051 | Plain Washer |
| 32 | F016L72109 | Grommet |
| 33 | F016L72120 | Plain Washer |
| 34 | F016L73711 | Screw |
| 35 | F016L73100 | Vibration Damper |
| 36 | F016L73338 | Suction Pipe |
| 37 | F016L73278 | Plug |
| 38 | F016L72169 | Rotary Knob |
| 101 | F016L72124 | Plug |
| 102 | F016L72170 | Pump head |
| 103 | F016L72126 | Screw |
| 104 | F016L72035 | O-Ring |
| 105 | F016F04381 | Adapter |
| 106 | F016L72014 | O-Ring |
| 107 | F016F04382 | Adapter |
| 108 | F016L72074 | O-Ring |
| 109 | F016L72129 | Valve |
| 110 | F016L72130 | Seal |
| 111 | F016L72131 | O-Ring |
| 112 | F016L72132 | Bushing |
| 113 | F016L72133 | Bushing |
| 115 | F016L72134 | Screw |
| 116 | F016L72135 | Piston Guide |
| 117 | F016L72136 | Spring |
| 118 | F016F04323 | Piston 3 Stück |
| 119 | F016L72137 | Wobble Plate |
| 121 | F016L72139 | Screw |
| 122 | F016L72138 | Plug |
| 124 | F016L72141 | O-Ring |
| 126 | F016L72072 | Spring |
| 127 | F016L72073 | Ball |
| 128 | F016L72074 | O-Ring |
| 129 | F016L72143 | Nipple |
| 130 | F016L72019 | O-Ring |
| 131 | F016L72018 | Valve Insert |
| 132 | F016L72017 | Spring |
| 133 | F016L72016 | O-Ring |
| 134 | F016L72015 | Injector |
| 135 | F016L72065 | O-Ring |
| 136 | F016L72030 | O-Ring |
| 137 | F016L72066 | Pin |
| 138 | F016L72067 | Spring |
| 139 | F016L72068 | Plain Washer |
| 140 | F016L72069 | O-Ring |
| 141 | F016L72070 | Adapter |
| 142 | F016L72071 | Adapter |
| 143 | F016L72174 | Threaded Bushing |
| 144 | F016L72030 | O-Ring |
| 145 | F016L72031 | Piston |
| 146 | F016L72032 | Piston |
| 147 | F016L72033 | O-Ring |
| 148 | F016L72030 | O-Ring |
| 149 | F016L72034 | Spacer Ring |
| 150 | F016L72035 | O-Ring |
| 151 | F016L72014 | O-Ring |
| 152 | F016L72036 | Piston Guide |
| 153 | F016L72037 | Wobble Plate |
| 154 | F016L72038 | Spring |
| 155 | F016L72039 | Wobble Plate |
| 156 | F016L72040 | Pin |
| 157 | F016L72041 | Insert |
| 158 | F016L72042 | Plug |
| 159 | F016L72043 | Nut |
| 160 | F016L73290 | Knob |
| 161 | F016F04355 | Valve |
| 162 | F016L73294 | Pump head |
| 401 | F016L72144 | Ball Bearing |
| 402 | F016L72176 | Wobble Plate |
| 403 | F016L72146 | Ball Bearing |
| 404 | F016L73063 | Rotary shaft lip seal |
| 405 | F016L72177 | Screw |
| 406 | F016L72149 | Pump |
| 407 | F016L72150 | Ball Bearing |
| 408 | F016L72151 | Cover |
| 409 | F016L72152 | Seal |
| 410 | F016L72153 | O-Ring |
| 411 | F016L72154 | Fan |
| 412 | F016L73065 | Air Duct |
| 413 | F016L72156 | Plain Washer |
| 414 | F016L72157 | Screw |
| 415 | F016L72158 | O-Ring |
| 416 | F016L72159 | Housing |
| 417 | F016L72160 | Plain Washer |
| 418 | F016L72161 | Screw |
| 419 | F016L73339 | Cover |
| 420 | F016L72087 | Switch |
| 421 | F016L72092 | Grommet |
| 422 | F016L73340 | Power supply cord |
| 423 | F016L72163 | O-Ring |
| 424 | F016L72178 | Condenser |
| 425 | F016L73324 | Motor |
| 426 | F016L72094 | Clamp |
| 427 | F016L72093 | Electronic Module |
| 428 | F016L72086 | Screw |
| 429 | F016L72096 | Grommet |
| 430 | F016L72260 | O-Ring |
| 431 | F016L73343 | O-Ring |
| 501 | F016L73068 | Handle |
| 501/1 | 1619PA9742 | Trigger |
| 501/2 | 1619PA9743 | Spring |
| 501/3 | 1619PA9744 | Lock |
| 502 | F016L73327 | Jet Pipe |
| 502/815 | 1619PB2119 | O-Ring 9,5x1,5 |
| 503 | F016L73384 | Jet Pipe |
| 503/815 | 1619PB2119 | O-Ring 9,5x1,5 |
| 504 | F016F04524 | Hose |
| 505 | F016L72099 | O-Ring |
| 511 | F016L73351 | Filter |
| 512 | F016L73352 | Filter |
| 814 | F016F04324 | Seal |
| 880 | F016L73319 | Wear and Tear Part Set |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GHP 5-75 - 3600J10700
12 Items
Data sheet
- SHIPPING IN:
- ON DEMAND ONLY
- MORE INFO:
- CALL US FOR AVAILABILITY AND SHIPPING TIMES
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N BOSCH:
- BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
