Bosch Spare Parts for Percussion Drill PSB 700 RE - 0603386703

SKU: Bosch PSB 700 RE - 0603386703
€11.74
VAT included

Bosch Spare Parts for Percussion Drill PSB 700 RE - 0603386703

We have the original Spares for PSB 700 RE/230V/EU, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Percussion Drill PSB 700 RE - 0603386703. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee

Bosch PSB 700 RE - 0603386703
Bosch Spare Parts for Percussion Drill PSB 700 RE - 0603386703
  • Bosch Spare Parts for Percussion Drill PSB 700 RE - 0603386703
  • Bosch Spare Parts for Percussion Drill PSB 700 RE - 0603386703
Bosch

Bosch Spare Parts for Percussion Drill PSB 700 RE - 0603386703

SKU: Bosch PSB 700 RE - 0603386703 Condition: New
€11.74
VAT included

Bosch Spare Parts for Percussion Drill PSB 700 RE - 0603386703

We have the original Spares for PSB 700 RE/230V/EU, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Percussion Drill PSB 700 RE - 0603386703. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee

Bosch PSB 700 RE - 0603386703
settings 42 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
39 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
Pos. Item Price Buy
1
 photo_cameraImage coming soon 2605104755 Housing Section  €15.38
2
 230-240V Stator (FIELDS) for Jigsaw Bosch PST 700 PE 2604220682 230-240V Stator (FIELDS) for Jigsaw Bosch PST 700 PE €25.25
3
 photo_cameraImage coming soon 2604011295 Armature 230-240V €43.27
4
 photo_cameraImage coming soon 2607200601 Switch €27.47
5
 photo_cameraImage coming soon 1607000387 Power supply cord EU 2,65m 2 x 0,75mm €10.76
6
 Grommet for Drills Bosch PSB550-650-700/2-1000 2600707066 Grommet for Drills Bosch PSB550-650-700/2-1000 €2.28
9
 photo_cameraImage coming soon 2601117834 Manufacturer's nameplate  €2.78
22
 Tapping Screw DIN 7981 for Percussion Drill Bosh GSB-PSB 2910611002 Tapping Screw DIN 7981 for Percussion Drill Bosh GSB-PSB €1.20
24
 photo_cameraImage coming soon 1900210000 O-Ring 5,0x1,5 MM  €2.13
25
 Red Change-Over Switch for Percussion Drills Bosch PSB500-650-700RE 2602098008 Red Change-Over Switch for Percussion Drills Bosch PSB500-650-700RE €2.89
27
 photo_cameraImage coming soon 2603239024 Damping Element €1.34
28
 photo_cameraImage coming soon 2608040177 Handle Cover BLACK  €4.88
38
 photo_cameraImage coming soon 2601990027 Indexing Disk  €1.24
39
 Pressure Plate for Percussion Drill Bosch PSB 500 RE 2601074004 Pressure Plate for Percussion Drill Bosch PSB 500 RE €1.54
40
 photo_cameraImage coming soon 1903230009 Ball DIN 5401-5 G28  €1.43
44
 photo_cameraImage coming soon 2602329038 Roller Body  €1.24
47
 Sliding Lever Holder for Impact Drill Bosch PSB 500 RE 2608040120 Sliding Lever Holder for Impact Drill Bosch PSB 500 RE €2.10
53
 photo_cameraImage coming soon 2601329043 Contact Strap  €1.57
55
 Carbon Brushes Holder White Wire for Impact Drills Bosch GSB 13 RE 1614431025 Carbon Brushes Holder White Wire for Impact Drills Bosch GSB 13 RE €3.04
56
 Carbon Brushes Holder Blu Wire for Impact Drills Bosch GSB 13 RE 2604448228 Carbon Brushes Holder Blu Wire for Impact Drills Bosch GSB 13 RE €3.04
210
 photo_cameraImage coming soon 2601116284 Reference Plate €1.91
654
 photo_cameraImage coming soon 2602025125 Auxiliary Handle BLACK €8.38
655
 photo_cameraImage coming soon 2609005615 Depth-Gauge €4.55
808
 photo_cameraImage coming soon 2601117930 Marking Plate  €1.24
813
 photo_cameraImage coming soon 2600905103 Deep-Groove Ball Bearing 7x19x6 €4.75
816
 photo_cameraImage coming soon 2604321946 Carbon-Brush Set  €9.50
819
 photo_cameraImage coming soon 2910611006 Tapping Screw DIN 7981-ST2,9x13-C-H  €2.13
826
 photo_cameraImage coming soon 2910611020 Tapping Screw DIN 7981-ST3,9x19-C-H €1.68
831
 Drilling Spindle for Percussion Drill Bosch PSB 700 RE 2606135931 Drilling Spindle for Percussion Drill Bosch PSB 700 RE €21.35
833
 photo_cameraImage coming soon 2605807937 Bearing Bracket  €27.77
836
 photo_cameraImage coming soon 2605808926 Gear Cover  €11.95
841
 Compression Spring for Bosch Impact Drills GSB13-16/PSB500-650-700 2604616006 Compression Spring for Bosch Impact Drills GSB13-16/PSB500-650-700 €1.91
842
 Shim mm 0.3 for Percussion Drill Bosch GSB 13 RE 2600101047 Shim mm 0.3 for Percussion Drill Bosch GSB 13 RE €1.52
845
 photo_cameraImage coming soon 2605805011 Flanged Bearing  €11.95
870
 Fan for Hammer Drill Bosch GSB 18-2 RE 2606610029 Fan for Hammer Drill Bosch GSB 18-2 RE €3.09
890
 photo_cameraImage coming soon 2607001305 Fastening parts kit  €6.01
891
 photo_cameraImage coming soon 2603410046 Screw Phillips M3x5 €2.77
895
 photo_cameraImage coming soon 2600290044 Retaining snap ring  €3.70
896
 photo_cameraImage coming soon 2606320086 Carrier 1,125 M €20.21

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Bosch Spare Parts for Percussion Drill PSB 700 RE - 0603386703

Fix Your Percussion Drill PSB 700 RE/230V/EU - 0603386703. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Percussion Drill and the respective parts of the code.
Bosch PSB 700 RE - 0603386703

Percussion Drill Bosch PSB 700 RE/230V/EU - 0603386703
# Part Num. Description
1 2605104755 Housing Section
2 2604220682 Field 230-240V
3 2604011295 Armature 230-240V
4 2607200601 Switch
5 1607000387 Power supply cord CN 2,65m 2 x 0,75mm H05 W-F
6 2600707066 Grommet Ø6,2-Ø6,9x90 MM
9 2601117834 Manufacturer's nameplate
16 2604337115 Brush Plate
22 2910611002 Tapping Screw DIN 7981-ST2,2x9,5-C-H
24 1900210000 O-Ring 5,0x1,5 MM
25 2602098008 Change-Over Switch RED
27 2603239024 Damping Element
28 2608040177 Handle Cover BLACK
38 2601990027 Indexing Disk
39 2601074004 Pressure Plate
40 1903230009 Ball DIN 5401-5 G28
44 2602329038 Roller Body
46 2608572173 Keyless Chuck
47 2608040120 Frame
53 2601329043 Contact Strap
55 1614431025 Pvc-Insulated Cable L=95 MM
56 2604448228 Pvc-Insulated Cable L=120 MM BLUE
210 2601116284 Reference Plate
654 2602025125 Auxiliary Handle BLACK
655 2609005615 Depth-Gauge
808 2601117930 Marking Plate
813 2600905103 groove ball bearing 7x19x6
816 2604321946 Carbon-Brush Set
819 2910611006 Tapping Screw DIN 7981-ST2,9x13-C-H
826 2910611020 Tapping Screw DIN 7981-ST3,9x19-C-H
831 2606135931 Drilling Spindle 1/2"
833 2605807937 Bearing Bracket
836 2605808926 Gear Cover
841 2604616006 Compression Spring
842 2600101047 Shim 0,3 MM
845 2605805011 Flanged Bearing
849 2916540005 Retaining ring DIN 7993-A8
870 2606610029 Fan
890 2607001305 Fastening parts kit
891 2603410046 Cross Recessed-Head Screw M3x5
895 2600290044 Retaining snap ring
896 2606320086 Carrier 1,125 M
