Bosch

Bosch Spare Parts for Circular Hand Saw PKS 55

SKU: Bosch PKS 55 - 3603E00000.
€16.49
VAT included

Bosch Spare Parts for Circular Hand Saw PKS 55

Bosch original spare parts for to replace broken parts for to fix Circular Hand Saw - PKS 55/230V/EU - 3603E00000.

Fix Your Circular Hand Saw. All Spares can be supplied. Our Spares are Genuine Parts and Come with a Full Guarantee.

Bosch Spare Parts for Circular Hand Saw PKS 55
  • Bosch Spare Parts for Circular Hand Saw PKS 55
  • Bosch Spare Parts for Circular Hand Saw PKS 55
Bosch

Bosch Spare Parts for Circular Hand Saw PKS 55

SKU: Bosch PKS 55 - 3603E00000. Condition: New
€16.49
VAT included

Bosch Spare Parts for Circular Hand Saw PKS 55

Bosch original spare parts for to replace broken parts for to fix Circular Hand Saw - PKS 55/230V/EU - 3603E00000.

Fix Your Circular Hand Saw. All Spares can be supplied. Our Spares are Genuine Parts and Come with a Full Guarantee.

settings 30 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
30 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
13
 photo_cameraImage coming soon 1609203X99 Cylindrical Gear  €13.92
14
 photo_cameraImage coming soon 1609203Y00 Gear Shaft  €6.28
15
 photo_cameraImage coming soon 1609203Y01 groove ball bearing  €4.18
16
 photo_cameraImage coming soon 1609203Y02 Extension Spring  €1.94
20
 photo_cameraImage coming soon 1609203X86 Vacuum Adapter  €6.17
21
 photo_cameraImage coming soon 1609203Y03 Gear Housing  €29.24
29
 photo_cameraImage coming soon 1609203Y06 Pivoting Blade Guard  €15.38
32
 photo_cameraImage coming soon 1609203Y07 Clamping Flange  €4.32
34
 photo_cameraImage coming soon 1609203Y08 Conical Spring Washer  €4.18
35
 photo_cameraImage coming soon 1609203Y19 Screw  €2.47
37
 photo_cameraImage coming soon 1604200234 On-Off Switch  €11.95
42
 photo_cameraImage coming soon 1609203Y55 Power supply cord  €17.88
43
 photo_cameraImage coming soon 1609203Y38 Lever  €1.91
44
 photo_cameraImage coming soon 1609203Y39 Rod  €1.91
47
 photo_cameraImage coming soon 1907950006 Offset Screwdriver DIN 911-SW5 BLACK €5.40
48
 photo_cameraImage coming soon 1609203Y57 Angle Support  €3.40
50
 photo_cameraImage coming soon 1609203Y58 Plain Washer  €1.91
51
 photo_cameraImage coming soon 1609203Y59 Wing Nut  €2.47
55
 photo_cameraImage coming soon 1609203Y61 Wing Screw  €3.40
62
 photo_cameraImage coming soon 1609203Y77 Bolt  €2.89
801
 photo_cameraImage coming soon 1609203Y09 Carbon-Brush Set  €11.95
805
 photo_cameraImage coming soon 1609203Y10 Field 230V  €32.95
808
 photo_cameraImage coming soon 1609203Y11 Armature 230V  €56.40
809
 photo_cameraImage coming soon 1609203Y12 Motor Housing  €22.52
810
 photo_cameraImage coming soon 1609203Y13 Bearing Bracket  €14.92
818
 photo_cameraImage coming soon 1609203Y14 Stopping Device  €4.32
824
 photo_cameraImage coming soon 1609203Y15 Stopper  €3.62
836
 photo_cameraImage coming soon 1609203Y16 Set Of Handles  €17.55
838
 photo_cameraImage coming soon 1609203Y71 Suppression Capacitor  €2.47
864
 photo_cameraImage coming soon 1609203Y18 Base Plate €22.52

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Bosch Spare Parts for Circular Hand Saw PKS 55

Bosch original spare parts for to replace broken parts for to fix Circular Hand Saw - PKS 55/230V/EU - 3603E00000.

Fix Your Circular Hand Saw. All Spares can be supplied. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Circular Saw and the respective parts of the code.
BOSCH
Circular Hand Saw - PKS 55/230V/EU - 3603E00000
13 1609203X99 Cylindrical Gear
14 1609203Y00 Gear Shaft
15 1609203Y01 groove ball bearing
16 1609203Y02 Extension Spring
20 1609203X86 Vacuum Adapter
21 1609203Y03 Gear Housing
22 1609203Y04 Spring Pin
23 1609203Y27 Tapping Screw
27 1609203Y05 Screw
29 1609203Y06 Pivoting Blade Guard
30 1609203Y23 Lever
31 1609203Y76 Screw
32 1609203Y07 Clamping Flange
34 1609203Y08 Conical Spring Washer
35 1609203Y19 Screw
37 1604200234 On-Off Switch
40 1609203Y53 Cable Clip
41 1609203Y54 Grommet
42 1609203Y55 Power supply cord
43 1609203Y38 Lever
44 1609203Y39 Rod
45 1609203Y40 Plain Washer
47 1907950006 Offset Screwdriver DIN 911-SW5 BLACK
48 1609203Y57 Angle Support
50 1609203Y58 Plain Washer
51 1609203Y59 Wing Nut
52 1609203Y78 Screw
53 1609203Y60 Hex Nut
55 1609203Y61 Wing Screw
57 1609203Y79 Screw
58 1609203Y32 Plain Washer
61 1609203Y62 Tapping Screw
62 1609203Y77 Bolt
63 1609203Y44 Bolt
69 1601118R71 Nameplate
70 1601118R67 Manufacturer's nameplate PKS 55
801 1609203Y09 Carbon-Brush Set
805 1609203Y10 Field 230V
808 1609203Y11 Armature 230V
809 1609203Y12 Motor Housing
810 1609203Y13 Bearing Bracket
818 1609203Y14 Stopping Device
824 1609203Y15 Stopper
836 1609203Y16 Set Of Handles
838 1609203Y71 Suppression Capacitor
860 1609203Y17 Guide Piece
864 1609203Y18 Base Plate

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Bosch PKS 55 - 3603E00000.
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS

Specific References

New

Download

Diagram Bosch PKS 55

Diagram Bosch PKS 55

Download (151.6KB)
