Bosch

Bosch Spare Parts for Angle Grinder GWS 1000

SKU: Bosch GWS 1000 - 3601H21003
€2.31
VAT included

Bosch Spare Parts for Angle Grinder GWS 1000

Bosch original spare parts, sourced from the manufacturer, at the best price on the web, for to Make Maintenance or Replacement of Broken parts of the Angle Grinder GWS 1000 - 3601H21003.

Bosch GWS 1000 - 3601H21003
Bosch Spare Parts for Angle Grinder GWS 1000
  • Bosch Spare Parts for Angle Grinder GWS 1000
  • Bosch Spare Parts for Angle Grinder GWS 1000
Bosch

Bosch Spare Parts for Angle Grinder GWS 1000

SKU: Bosch GWS 1000 - 3601H21003 Condition: New
€2.31
VAT included

Bosch Spare Parts for Angle Grinder GWS 1000

Bosch original spare parts, sourced from the manufacturer, at the best price on the web, for to Make Maintenance or Replacement of Broken parts of the Angle Grinder GWS 1000 - 3601H21003.

Bosch GWS 1000 - 3601H21003
settings 62 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
55 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
Pos. Item Price Buy
d
 photo_cameraImage coming soon 1600136014 Shim 0,2 MM THICK €2.46
d
 photo_cameraImage coming soon 1600136015 Shim 0,3 MM THICK €2.46
d
 photo_cameraImage coming soon 1600136020 Shim 0,15 MM THICK €3.47
photo_cameraImage coming soon 1602025052 Auxiliary Handle M10 ANTI-VIBRATION €28.44
photo_cameraImage coming soon 1607000482 Carbon-Brush Set 10 x 1 607 014 176 €110.58
2
 photo_cameraImage coming soon 1604220283 Field 220-240V €32.46
4
 Switch for Angle Grinder Bosch GWS115-PWS115 1607200086 Switch for Angle Grinder Bosch GWS115-PWS115 €17.37
7
 Fastening Clamp for Angle grinder Bosch GWS 6-115 1601302017 Fastening Clamp for Angle grinder Bosch GWS 6-115 €1.09
9
 photo_cameraImage coming soon 1601118G95 Manufacturer's nameplate GWS 1000 €1.99
12
 photo_cameraImage coming soon 1607328074 Suppression Capacitor €5.02
13
 Ball Bearing 7x19x6 for Bosch Power Tools 2600905032 Ball Bearing 7x19x6 for Bosch Power Tools €5.89
14
 photo_cameraImage coming soon 1600905032 groove ball bearing 8x22x7 €5.65
24
 photo_cameraImage coming soon 1605500228 Cover BLUE €2.35
25
 photo_cameraImage coming soon 1605500251 Housing Cover DARK BLUE €5.65
26
 photo_cameraImage coming soon 1600206036 Rubber Ring €1.56
27
 Armature Bearing Rubber Ring for Angle Grinder Bosch GWS 6-115 1600206025 Armature Bearing Rubber Ring for Angle Grinder Bosch GWS 6-115 €2.28
29
 photo_cameraImage coming soon 1600591025 Air-Deflector Ring €1.99
30
 photo_cameraImage coming soon 1600591014 Air-Deflector Ring €2.08
32
 Spindle Shaft M 14 for Angle Grinders Bosch GWS 6-115 1603523110 Spindle Shaft M 14 for Angle Grinders Bosch GWS 6-115 €12.04
33
 photo_cameraImage coming soon 1600210035 O-Ring 46,0x1,1 MM €1.62
35
 photo_cameraImage coming soon 1600136013 Shim 0,1 MM THICK €2.46
37
 Rotary Shaft lip Seal for Angle Grinder Bosch GWS 7-115 1600290016 Rotary Shaft lip Seal for Angle Grinder Bosch GWS 7-115 €2.61
40
 Spring Retaining Ring for Angle Grinder Bosch GWS 8-115 1600119011 Spring Retaining Ring for Angle Grinder Bosch GWS 8-115 €2.25
41
 photo_cameraImage coming soon 1600200029 Plain bearing €5.90
45
 Hex Nut M7 SW10 for Angle Grinder Bosch PWS 6-115 1603300016 Hex Nut M7 SW10 for Angle Grinder Bosch PWS 6-115 €1.71
47
 photo_cameraImage coming soon 2603490021 Torx Oval-Head Screw 4x12 €1.39
50
 Torx Oval-Head Screw 4x20 for BOSCH Power Tools 2603490023 Torx Oval-Head Screw 4x20 for BOSCH Power Tools €1.09
52
 White Wire 90 mm for Angle Grinder Bosch GWS 8-115 1604448013 White Wire 90 mm for Angle Grinder Bosch GWS 8-115 €2.55
80
 Sealing Disk for Grinder Bosch GWS 6-115 3600150021 Sealing Disk for Grinder Bosch GWS 6-115 €4.82
105
 photo_cameraImage coming soon 1601008005 Insulating Plate €2.35
301/16
 photo_cameraImage coming soon 1601323025 Brush Holder €2.86
301/18
 Switch Handle for Angle Grinder Bosch GWS 8-115 1602026088 Switch Handle for Angle Grinder Bosch GWS 8-115 €1.53
301/19
 Compression Spring for Angle Grinders Bosch PWS 7-115 1604611026 Compression Spring for Angle Grinders Bosch PWS 7-115 €0.94
301/17
 Spiral Spring for Angle Grinders Bosch GWS/PWS6-115 1604652013 Spiral Spring for Angle Grinders Bosch GWS/PWS6-115 €2.07
301/1
 photo_cameraImage coming soon 1605108249 Motor Housing DARK BLUE €8.77
343/44
 photo_cameraImage coming soon 1604611042 Compression Spring €1.62
343
 photo_cameraImage coming soon 1607000742 Catch Lever €6.80
651
 photo_cameraImage coming soon 1605510355 Protective Cover Ø115 MM €12.74
803
 photo_cameraImage coming soon 1604010A20 Armature With Fan 230V €69.33
805
 photo_cameraImage coming soon 1607000227 Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F €36.70
806
 photo_cameraImage coming soon 1600703040 Grommet €1.70
808
 photo_cameraImage coming soon 160111A3H3 Nameplate  €3.22
810
 Carbon Brushes for Angle Grinders Bosch GWS 8-115-PWS 10-125 CE 1607014176 Carbon Brushes for Angle Grinders Bosch GWS 8-115-PWS 10-125 CE €16.31
821
 photo_cameraImage coming soon 16058065SC Gear Housing €30.11
828
 photo_cameraImage coming soon 1607000448 Bearing Flange €11.92
828/04
 O-Ring 47,0x1,5 mm for Angle Grinder Bosch GWS 8-115 3600210109 O-Ring 47,0x1,5 mm for Angle Grinder Bosch GWS 8-115 €2.20
831
 Spring Element for Angle Grinder Bosch GWS 8-115 1601290013 Spring Element for Angle Grinder Bosch GWS 8-115 €1.63
835
 Fan for Rotary Hammer Bosch PBH 300 E 1606610132 Fan for Rotary Hammer Bosch PBH 300 E €3.08
838
 photo_cameraImage coming soon 1600A0022W Gear Unit €28.28
840
 photo_cameraImage coming soon 1607000A71 Push-Button €3.11
890
 O-Ring 20,35x1,78 mm for Angle Grinder Bosch PWS 6-115 1600210039 O-Ring 20,35x1,78 mm for Angle Grinder Bosch PWS 6-115 €1.28
891
 photo_cameraImage coming soon 2602025067 Auxiliary Handle M10, Ø32,5x105 MM €3.67
892
 Upper Flange M14 for Angle Grinder Bosch GWS 6-115-GWS 660 1603345043 Upper Flange M14 for Angle Grinder Bosch GWS 6-115-GWS 660 €9.26
893
 Pin-Type Face-Wrench for Angle Grinders Bosch GWS 850 CE 1607950052 Pin-Type Face-Wrench for Angle Grinders Bosch GWS 850 CE €4.84
895
 Clamping Flange for Angle Grinder Bosch PWS 6-115 2605703014 Clamping Flange for Angle Grinder Bosch PWS 6-115 €7.98

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Bosch Spare Parts for Angle Grinder GWS 1000

Bosch original spare parts, sourced from the manufacturer, at the best price on the web, for to Make Maintenance or Replacement of Broken parts of the Angle Grinder GWS 1000 - 3601H21003.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Bosch GWS 1000 - 3601H21003

Angle Grinder GWS 1000/3 601 H21 003
# Part Num. Description
2 1604220283 Field 220-240V
4 1607200086 On-Off Switch
7 1601302017 Fastening Clamp
9 1601118G95 Manufacturer's nameplate GWS 1000
12 1607328074 Suppression Capacitor
13 2600905032 Ball Bearing 7x19x6
14 1600905032 groove ball bearing 8x22x7
24 1605500228 Cover BLUE
25 1605500251 Housing Cover DARK BLUE
26 1600206036 Rubber Ring
27 1600206025 Rubber Ring
29 1600591025 Air-Deflector Ring
30 1600591014 Air-Deflector Ring
32 1603523110 Grinding Spindle M14, SW17
33 1600210035 O-Ring 46,0x1,1 MM
35 1600136013 Shim 0,1 MM THICK
d 1600136020 Shim 0,15 MM THICK
d 1600136014 Shim 0,2 MM THICK
d 1600136015 Shim 0,3 MM THICK
37 1600290016 Rotary shaft lip seal
40 1600119011 Retaining clip
41 1600200029 Plain bearing
45 1603300016 Hex Nut M7, SW10
47 2603490021 Torx Oval-Head Screw 4x12
49 2914491410 Thread-forming tap. Screw M4x16
50 2603490023 Torx Oval-Head Screw 4x20
52 1604448013 Connecting Cable L=90 MM WHITE
53 1603435078 Torx Oval-Head Screw
54 1603414026 Torx Oval-Head Screw 4x30
80 3600150021 Sealing disk
104 1600210044 O-Ring 4,5x1,0 MM BLUE
105 1601008005 Insulating Plate
301/1 1605108249 Motor Housing DARK BLUE
301/16 1601323025 Brush Holder
301/17 1604652013 Spiral Spring
301/18 1602026088 Switch Handle
301/19 1604611026 Compression Spring
301/20 1602319011 Adjusting Slide
301/48 1613435034 Lens Head Screw 3x10 ST
343 1607000742 Catch Lever
343/44 1604611042 Compression Spring
651 1605510355 Protective Cover Ø115 MM
803 1604010A20 Armature With Fan 230V
805 1607000227 Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F
806 1600703040 Grommet
808 160111A3H3 Nameplate
810 1607014176 Carbon-Brush Set
d 1607000482 Carbon-Brush Set 10 x 1 607 014 176
818 2910110048 Pan head screw DIN 85-AM3x6-CUZN
821 16058065SC Gear Housing
828 1607000448 Bearing Flang
828/04 3600210109 O-Ring 47,0x1,5 MM
831 1601290013 Spring Element
835 1606610132 Fan
838 1600A0022W Gear Unit
840 1607000A71 Push-Button
890 1600210039 O-Ring 20,35x1,78 MM
891 2602025067 Auxiliary Handle M10, Ø32,5x105 MM
d 1602025052 Auxiliary Handle M10 ANTI-VIBRATION
892 1603345043 Round Nut M14
893 1607950052 Pin-Type Face-Wrench
895 2605703014 Clamping Flange Ø22,3xØ42 MM

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GWS 1000 - 3601H21003
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS

Specific References

New

Download

Diagram Bosch GWS 1000

Diagram Bosch GWS 1000

Download (175.37KB)
