Bosch

Bosch Spare Parts for Circular Saw GKS 85

SKU: Bosch Sega Circolare GKS 85
€6.44
VAT included

Bosch Spare Parts for Circular Saw GKS 85

Bosch genuine replacement parts for to replace broken parts for to fix Circular Saw GKS 85 - 3601E7A000.

Circular Saw GKS 85 - 3601E7A000
Bosch Spare Parts for Circular Saw GKS 85
  • Bosch Spare Parts for Circular Saw GKS 85
  • Bosch Spare Parts for Circular Saw GKS 85
Bosch

Bosch Spare Parts for Circular Saw GKS 85

SKU: Bosch Sega Circolare GKS 85 Condition: New
€6.44
VAT included

Bosch Spare Parts for Circular Saw GKS 85

Bosch genuine replacement parts for to replace broken parts for to fix Circular Saw GKS 85 - 3601E7A000.

Circular Saw GKS 85 - 3601E7A000
settings 78 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
78 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
2
 photo_cameraImage coming soon 1619P08320 Field 230V €52.41
4
 photo_cameraImage coming soon 1619P01115 Switch €16.00
5
 photo_cameraImage coming soon 1619P02320 Power supply cord EU 4,15m 2x1,50 H07RN-F €24.92
6
 photo_cameraImage coming soon 2600703011 Grommet Ø8,3-Ø9,4x95 MM  €2.53
7
 photo_cameraImage coming soon 1619P01104 Cable Clip €1.25
9
 photo_cameraImage coming soon 1619P01135 Manufacturer's nameplate €2.53
12
 photo_cameraImage coming soon 1619P06099 Suppression Filter €5.91
13
 photo_cameraImage coming soon 2610017348 Deep-Groove Ball Bearing €11.90
14
 photo_cameraImage coming soon 1619P06095 Deep-Groove Ball Bearing €13.35
19
 photo_cameraImage coming soon 2603490021 Torx Oval-Head Screw 4x12 €1.39
20
 photo_cameraImage coming soon 1619P06071 Electronic Module €41.66
22
 photo_cameraImage coming soon 1619P01139 End cap €5.91
23
 photo_cameraImage coming soon 1619P01140 Baffle BLACK €4.87
24
 photo_cameraImage coming soon 1619P06098 Set Of Handles €12.44
25
 photo_cameraImage coming soon 1619P01142 Auxiliary Handle BLACK €6.49
26
 photo_cameraImage coming soon 1619P01127 Rubber Ring €1.25
27
 photo_cameraImage coming soon 1619P06100 Cable €1.73
28
 photo_cameraImage coming soon 1619P06101 Cable €1.73
29
 photo_cameraImage coming soon 1619P04505 Cable €1.25
30
 photo_cameraImage coming soon 1619P06102 Cable €1.73
31
 photo_cameraImage coming soon 1619P06072 Terminal Block €2.19
32
 photo_cameraImage coming soon 1619P01156 Switch Button €1.73
33
 photo_cameraImage coming soon 2610935251 Compression Spring €1.25
34
 photo_cameraImage coming soon 1619P01637 Strain-Relief Clamp €1.25
36
 photo_cameraImage coming soon 1619P06502 Terminal €1.25
37
 photo_cameraImage coming soon 1619P01143 Cap BLACK €1.25
38
 photo_cameraImage coming soon 1619P01620 Guide Bracket €4.87
39
 photo_cameraImage coming soon 1619P01642 Compression Spring €1.33
41
 photo_cameraImage coming soon 1619P07414 Shim washer €1.25
46
 photo_cameraImage coming soon 1619P01623 Shaft €14.90
47
 photo_cameraImage coming soon 1900905279 Deep-Groove Ball Bearing 15x35x11 €11.90
48
 photo_cameraImage coming soon 1900905173 Deep-Groove Ball Bearing 6000-2RS DIN 625 €5.70
49
 photo_cameraImage coming soon 1619P01624 Cylindrical Gear €16.86
50
 photo_cameraImage coming soon 1619P01625 Washer €5.43
51
 photo_cameraImage coming soon 1619P06089 Locking Washer €5.43
52
 photo_cameraImage coming soon 1619P01634 Clamp Screw €2.75
53
 photo_cameraImage coming soon 1619P01628 Bearing Flange €8.70
54
 photo_cameraImage coming soon 1619P01629 Retaining Plate €3.01
58
 photo_cameraImage coming soon 1619P01630 Pivoting Blade Guard €24.42
59
 photo_cameraImage coming soon 1619P01631 Lever €1.73
60
 photo_cameraImage coming soon 1619P01632 Extension Spring €2.53
61
 photo_cameraImage coming soon 1619P01633 Bumper €1.73
62
 photo_cameraImage coming soon 1619P02580 Spacer Tube €1.25
63
 photo_cameraImage coming soon 1619P01635 Flange Bushing €1.73
65
 photo_cameraImage coming soon 1619P06522 Stud bolt €1.25
66
 photo_cameraImage coming soon 1619P01639 Protective Guard €33.85
67
 photo_cameraImage coming soon 2917780185 Slotted Spring Pin DIN 7346-8x45 €1.73
69
 photo_cameraImage coming soon 1619P01665 Base Plate €33.85
70
 photo_cameraImage coming soon 1619P01666 Hinge Bracket €7.48
71
 photo_cameraImage coming soon 1619P01154 Depth-Gauge €6.49
72
 photo_cameraImage coming soon 1619P01155 Support bracket €3.74
73
 photo_cameraImage coming soon 1619P01158 Hinge €5.70
74
 photo_cameraImage coming soon 2610923224 Shoulder Screw €1.25
75
 photo_cameraImage coming soon 2915061003 Hex Nut DIN 985-M 5-8-A €1.73
76
 photo_cameraImage coming soon 1619P01636 Wing Nut €1.73
78
 photo_cameraImage coming soon 2910281201 Round-Head Bolt DIN 603-M6x20  €1.34
79
 photo_cameraImage coming soon 1619P01668 Adjusting Lever €1.25
80
 photo_cameraImage coming soon 1619P01669 Rod €5.09
81
 photo_cameraImage coming soon 2916021013 Plain Washer 8-ST €1.73
84
 photo_cameraImage coming soon 1619P01618 Wing Screw BLACK €1.25
87
 photo_cameraImage coming soon 1619P01643 Screw €1.25
88
 photo_cameraImage coming soon 1619P01644 Screw €1.25
89
 photo_cameraImage coming soon 1619P01676 Screw €1.25
90
 photo_cameraImage coming soon 2610924685 Adjusting Screw €1.25
91
 photo_cameraImage coming soon 1619P01677 Screw M5x10-H €1.25
92
 photo_cameraImage coming soon 1619P01678 Screw €1.25
93
 photo_cameraImage coming soon 1619P01679 Screw €1.25
94
 photo_cameraImage coming soon 1619P01680 Screw M6x20-H €1.25
95
 photo_cameraImage coming soon 1619P01673 Screw €1.25
653
 photo_cameraImage coming soon 1907950006 Offset Screwdriver DIN 911-SW5 BLACK €5.40
655
 photo_cameraImage coming soon 1619P01674 Screw M 6x10 €1.25
660
 photo_cameraImage coming soon 1619X01612 Mitre Fence €11.90
680
 photo_cameraImage coming soon 1619P01627 Vacuum Adapter €4.43
801
 photo_cameraImage coming soon 1619P04514 Motor Housing €17.90
803
 photo_cameraImage coming soon 1619P01696 Armature set 230V €88.17
808
 photo_cameraImage coming soon 1619P01675 Nameplate €2.53
810
 Carbon Brushe Set for Circular Saw Bosch GKS 85 1619P01685 Carbon Brushe Set for Circular Saw Bosch GKS 85 €11.80
816
 photo_cameraImage coming soon 1619P02799 Brush Holder €19.34

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Bosch Spare Parts for Circular Saw GKS 85

Bosch genuine replacement parts for to replace broken parts for to fix Circular Saw GKS 85 - 3601E7A000.

In the following table, look for the model of the Circular Saw and the respective parts of the code.
Circular Saw GKS 85 - 3601E7A000
Circular Saw GKS 85 - 3601E7A000
# Part Num. Description
2 1619P08320 Field 230V
4 1619P01115 Switch
5 1619P02320 Power supply cord EU 4,15m 2x1,50 H07RN-F
6 2600703011 Grommet Ø8,3-Ø9,4x95 MM
7 1619P01104 Cable Clip
9 1619P01135 Manufacturer's nameplate
12 1619P06099 Suppression Filter
13 2610017348 Deep-Groove Ball Bearing
14 1619P06095 Deep-Groove Ball Bearing
19 2603490021 Torx Oval-Head Screw 4x12
20 1619P06071 Electronic Module
22 1619P01139 End cap
23 1619P01140 Baffle BLACK
24 1619P06098 Set Of Handles
25 1619P01142 Auxiliary Handle BLACK
26 1619P01127 Rubber Ring
27 1619P06100 Cable
28 1619P06101 Cable
29 1619P04505 Cable
30 1619P06102 Cable
31 1619P06072 Terminal Block
32 1619P01156 Switch Button
33 2610935251 Compression Spring
34 1619P01637 Strain-Relief Clamp
36 1619P06502 Terminal
37 1619P01143 Cap BLACK
38 1619P01620 Guide Bracket
39 1619P01642 Compression Spring
41 1619P07414 Shim washer
46 1619P01623 Shaft
47 1900905279 Deep-Groove Ball Bearing 15x35x11
48 1900905173 Deep-Groove Ball Bearing 6000-2RS DIN 625
49 1619P01624 Cylindrical Gear
50 1619P01625 Washer
51 1619P06089 Locking Washer
52 1619P01634 Clamp Screw
53 1619P01628 Bearing Flange
54 1619P01629 Retaining Plate
58 1619P01630 Pivoting Blade Guard
59 1619P01631 Lever
60 1619P01632 Extension Spring
61 1619P01633 Bumper
62 1619P02580 Spacer Tube
63 1619P01635 Flange Bushing
65 1619P06522 Stud bolt
66 1619P01639 Protective Guard
67 2917780185 Slotted Spring Pin DIN 7346-8x45
69 1619P01665 Base Plate
70 1619P01666 Hinge Bracket
71 1619P01154 Depth-Gauge
72 1619P01155 Support bracket
73 1619P01158 Hinge
74 2610923224 Shoulder Screw
75 2915061003 Hex Nut DIN 985-M 5-8-A
76 1619P01636 Wing Nut
78 2910281201 Round-Head Bolt DIN 603-M6x20
79 1619P01668 Adjusting Lever
80 1619P01669 Rod
81 2916021013 Plain Washer 8-ST
84 1619P01618 Wing Screw BLACK
87 1619P01643 Screw
88 1619P01644 Screw
89 1619P01676 Screw
90 2610924685 Adjusting Screw
91 1619P01677 Screw M5x10-H
92 1619P01678 Screw
93 1619P01679 Screw
94 1619P01680 Screw M6x20-H
95 1619P01673 Screw
653 1907950006 Offset Screwdriver DIN 911-SW5 BLACK
655 1619P01674 Screw M 6x10
660 1619X01612 Mitre Fence
680 1619P01627 Vacuum Adapter
801 1619P04514 Motor Housing
803 1619P01696 Armature set 230V
808 1619P01675 Nameplate
810 1619P01685 Carbon-Brush Set
816 1619P02799 Brush Holder
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch Sega Circolare GKS 85
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS

Specific References

New

Download

Diagram Bosch GKS 85

Diagram Bosch GKS 85

Download (194.97KB)

You might also like

Wing Nut for Circular Saw Bosch PKS66CE
Bosch SKU: 1603339005
Wing Nut for Circular Saw Bosch PKS66CE
Wing Nut for Circular Saw Bosch PKS66CE Original Spare Parts Bosch, Wing Nut M6 for Circular Saw PKS 66 CE/0 603 234 703 - PKS 66/0 603 234 503 - GKS 55/0 601 567 003 - 65/0 601 568 003. Part for the following article : - Circular Saw...
AVAILABLE €2.57
Details
O-Ring 46,0x1,1mm for Circular Saw Bosch GKS 55
Bosch SKU: 3600210124
O-Ring 46,0x1,1mm for Circular Saw Bosch GKS 55
O-Ring 46,0x1,1mm for Circular Saw Bosch GKS 55 Original spare parts Bosch, O-Ring 46,0x1,1mm Red for Circular Saw GKS 55 - GKS 65 - PKS 66 - GNF 20 CA - GNF 35 CA. Parts for segunti articles: - 0 603 234 503 - Circular Saw Bosch PKS...
AVAILABLE €2.53
Details
Outer Washer Disc Lock for Circular Saw Bosch PKS 54 CE Sale
Bosch SKU: 1605703108
Outer Washer Disc Lock for Circular Saw Bosch PKS 54 CE
Outer Washer Disc Lock for Circular Saw Bosch PKS 54 CE Original Spare Parts Bosch, Outer Washer Disc Lock for Circular Saw PKS 54 CE/0 603 223 603 - GKS 160/3 601 F70 000. Part for the following article : - Circular Saw PKS 54 CE/0...
AVAILABLE €4.42
Details
Flat Head Screw M6x170 mm for Circular Saw Bosch PKS66CE
Bosch SKU: 1603434005
Flat Head Screw M6x170 mm for Circular Saw Bosch PKS66CE
Flat Head Screw M6x170 mm for Circular Saw Bosch PKS66CE Original Spare Part Bosch, Flat Head Screw M6x170 mm for Circular Saws PKS 66 CE 0 603 234 703 - PKS 66/0 603 234 503 - GKS 55/0 601 567 003 - GKS 65/0 601 568 003. Part for the...
AVAILABLE €2.13
Details
Extension Spring for Circular Saw Bosch GKS 55
Bosch SKU: 1604649001
Extension Spring for Circular Saw Bosch GKS 55
Extension Spring for Circular Saw Bosch GKS 55 Original spare parts Bosch, Extension Spring for Circular Saws GKS 55 - GKS 65 - PKS 66 - PKS 66 CE Parts for segunti articles: -  Circular...
Last items in stock €6.18
Details
Riving Knife for Circular Saw Bosch GKS 65
Bosch SKU: 1600025013
Riving Knife for Circular Saw Bosch GKS 65
Riving Knife for Circular Saw Bosch GKS 65 Original spare part Bosch, Riving Knife for Circular Saws GKS 65/0 601 568 003 - PKS 66/0 603 234 503 Part for the following products: - Circular Saw Bosch GKS 65/0 601 568 003 - Circular Saw...
AVAILABLE €7.11
Details
Carbon Brushe Set for Circular Saw Bosch GKS 85
Bosch SKU: 1619P01685
Carbon Brushe Set for Circular Saw Bosch GKS 85
Carbon Brushe Set for Circular Saw Bosch GKS 85 Genuine part Bosch, Carbon Brushe Set for Circular Saw Bosch GKS 85/3 601 E7A 000 - Circular Saw Skil Master 5885/F 015 588 511 Part for the following products: -  Circular Saw Bosch GKS...
AVAILABLE €11.80
Details
Comments (0)
