Bosch Spare Parts for Cordless Drill Driver GSR 14,4 V-LI

SKU: GSR 14,4 V-LI - 601H60400
€133.16
VAT included

Bosch Spare Parts for Cordless Drill Driver GSR 14,4 V-LI

Bosch genuine spare parts for replacing or repairing Cordless Drill Driver GSR 14,4 V-LI/3601H60400.

Fix Your Cordless Drill Driver GSR 14,4 V-LI. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

Bosch Spare Parts for Cordless Drill Driver GSR
  • Bosch Spare Parts for Cordless Drill Driver GSR
  • Bosch Spare Parts for Cordless Drill Driver GSR 14,4 V-LI

Bosch Spare Parts for Cordless Drill Driver GSR 14,4 V-LI

SKU: GSR 14,4 V-LI - 601H60400 Condition: New
€133.16
VAT included

Bosch Spare Parts for Cordless Drill Driver GSR 14,4 V-LI

Bosch genuine spare parts for replacing or repairing Cordless Drill Driver GSR 14,4 V-LI/3601H60400.

Fix Your Cordless Drill Driver GSR 14,4 V-LI. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

settings 25 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

23 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 2605105134 Housing Section BLUE €25.37
4
photo_cameraImage coming soon 1607233300 Electronic Module €101.29
5
Switch Adjusting Slide for Cordless Drill Bosch GSR 14,4 V-LI 2601099188 Switch Adjusting Slide for Cordless Drill Bosch GSR 14,4 V-LI €3.04
9
photo_cameraImage coming soon 2601115568 Manufacturer's nameplate GSR 14,4V-LI €2.09
20
photo_cameraImage coming soon 2601115569 Nameplate €2.09
25
photo_cameraImage coming soon 2608572251 Keyless Chuck 13 MM €69.97
32
photo_cameraImage coming soon 2601099189 Adjusting Slide RED €4.55
45
photo_cameraImage coming soon 2606200262 Planetary Gear Train €75.96
46
photo_cameraImage coming soon 2604690055 Compression Spring €1.23
91
photo_cameraImage coming soon 2607336077 Slide-In Accu Package 14,4V, 2,6Ah, LI, MS €285.52
91
photo_cameraImage coming soon 2607336223 Slide-In Accu Package BBS-MR XL-PACK 14,4V, LI €268.87
91
photo_cameraImage coming soon 2607336877 Slide-In Accu Package 14,4V, 2,0Ah, LI, MS-L €112.02
93
photo_cameraImage coming soon 1609200147 Screwdriver Blade 6 MM €2.47
101
photo_cameraImage coming soon 2609110201 Torx Flat-Head Screw 3x16 €2.77
107
Screw TX M 6x30 mm Left for Cordless Drills Bosch GSR 14,4-18 V-LI 2609110635 Screw TX M 6x30 mm Left for Cordless Drills Bosch GSR 14,4-18 V-LI €1.74
653
photo_cameraImage coming soon 2607225321 Charger EU 230/10,8-18V, 30 MIN €93.69
653
photo_cameraImage coming soon 2607225323 Charger GB 230/10,8-18V, 30 MIN €112.85
653
photo_cameraImage coming soon 2607225325 Fast Charger AUS 240/10,8-18V, 30 MIN €151.00
653
photo_cameraImage coming soon 2607225423 Fast Charger EU 230/10,8-18V, 1h €102.13
653
photo_cameraImage coming soon 2607225425 Fast Charger GB 230/10,8-18V, 1h €102.13
802
photo_cameraImage coming soon 2607022833 DC motor 14,4V €84.40
804
photo_cameraImage coming soon 1609280474 Contact retainer €12.96
821
photo_cameraImage coming soon 2609110633 Tab Washer €1.33

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Bosch Spare Parts for Cordless Drill Driver GSR 14,4 V-LI

Fix Your Cordless Drill Driver GSR 14,4 V-LI/3601H60400. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Cordles Drill and the respective parts of the code.
Cordless Drill GSR 14,4 V-LI/

Cordless Drill GSR 14,4 V-LI/3 601 H60 400
# Part Num. Description
1 2605105134 Housing Section BLUE
4 1607233300 Electronic Module
5 2601099188 Adjusting Slide
9 2601115568 Manufacturer's nameplate GSR 14,4V-LI
20 2601115569 Nameplate
22 2609110634 Screw
25 2608572251 Keyless Chuck 13 MM
32 2601099189 Adjusting Slide RED
45 2606200262 Planetary Gear Train
46 2604690055 Compression Spring
91 2607336077 Slide-In Accu Package 14,4V, 2,6Ah, LI, MS
91 2607336149 Battery Set 14,4V, 1,3Ah, LI, MS
91 2607336223 Slide-In Accu Package BBS-MR XL-PACK 14,4V, LI
91 2607336877 Slide-In Accu Package 14,4V, 2,0Ah, LI, MS-L
93 1609200147 Screwdriver Blade 6 MM
101 2609110201 Torx Flat-Head Screw 3x16
107 2609110635 Pan head screw M 6x30
653 2607225321 Charger EU 230/10,8-18V, 30 MIN
653 2607225323 Charger GB 230/10,8-18V, 30 MIN
653 2607225325 Fast Charger AUS 240/10,8-18V, 30 MIN
653 2607225423 Fast Charger EU 230/10,8-18V, 1h
653 2607225425 Fast Charger GB 230/10,8-18V, 1h
802 2607022833 DC motor 14,4V
804 1609280474 Contact retainer
821 2609110633 Tab Washer
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
GSR 14,4 V-LI - 601H60400
9 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS

Specific References

New

Download

Diagram Bosch GSR 14,4 V-LI

Diagram Bosch GSR 14,4 V-LI

Download (152.49KB)
