Bosch Spare Parts for Rotary Hammer PBH 300 E

SKU: Bosch PBH 300 E - 0603358760
€2.60
VAT included

Bosch Spare Parts for Rotary Hammer PBH 300 E

Bosch original spare parts for replacing damaged parts or fix broken and worn parts of the Rotary Hammer PBH 300 E - 0603358760.

Bosch PBH 300 E - 0603358760
Bosch Spare Parts for Rotary Hammer PBH 300 E
  • Bosch Spare Parts for Rotary Hammer PBH 300 E
  • Bosch Spare Parts for Rotary Hammer PBH 300 E
  • Bosch Spare Parts for Rotary Hammer PBH 300 E
Bosch

Bosch Spare Parts for Rotary Hammer PBH 300 E

SKU: Bosch PBH 300 E - 0603358760 Condition: New
€2.60
VAT included

Bosch Spare Parts for Rotary Hammer PBH 300 E

Bosch original spare parts for replacing damaged parts or fix broken and worn parts of the Rotary Hammer PBH 300 E - 0603358760.

Bosch PBH 300 E - 0603358760
settings 116 spare parts
description 2 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:: BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
91 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
Pos. Item Price Buy
1
 photo_cameraImage coming soon 1615108102 Motor Housing GREEN €18.81
2
 photo_cameraImage coming soon 1614220117 Field 230V €22.34
3
 photo_cameraImage coming soon 1614010128 Armature With Fan 220-230V €121.10
4
 photo_cameraImage coming soon 2607200512 Switch €35.47
6
 photo_cameraImage coming soon 2600703018 Grommet Ø7,3-Ø8,6x76 MM €2.22
7
 photo_cameraImage coming soon 1601302018 Fastening Clamp €2.25
9
 photo_cameraImage coming soon 1611110A33 Manufacturer's nameplate €2.85
10
 photo_cameraImage coming soon 1611110A34 Reference Plate €2.85
13
 photo_cameraImage coming soon 1610905025 Deep-Groove Ball Bearing 7x19x6 €7.92
14
 photo_cameraImage coming soon 1900900289 Deep-Groove Ball Bearing 12x28x8 €9.05
15
 Fan for Rotary Hammer Bosch PBH 300 E 1606610132 Fan for Rotary Hammer Bosch PBH 300 E €3.08
18
 photo_cameraImage coming soon 1610591011 Air-Deflector Ring €1.64
22
 photo_cameraImage coming soon 1616317602 Cylindrical Gear Z=50 €10.52
24
 photo_cameraImage coming soon 1617000500 Toothed Shaft Z=3/9 €43.34
26
 photo_cameraImage coming soon 1618700063 Hammer Piston €14.66
27
 photo_cameraImage coming soon 1618710060 Striker €14.66
28
 photo_cameraImage coming soon 1613124043 Striker Pin €5.12
29
 photo_cameraImage coming soon 1613105012 Piston Pin €3.68
32
 photo_cameraImage coming soon 1612026089 Clamp Handle €4.51
33
 photo_cameraImage coming soon 1610190016 Perforated disk €1.94
35
 Rubber Bushing for Hammer Bosch GBH 2-24 DFR 1610206021 Rubber Bushing for Hammer Bosch GBH 2-24 DFR €2.89
37
 photo_cameraImage coming soon 1610390032 Damping Bushing Ø21 MM €4.51
38
 Supporting Disc for Rotary Hammer Bosch GBH 2-24 DFR 1610102026 Supporting Disc for Rotary Hammer Bosch GBH 2-24 DFR €2.58
41
 Shim Washer 1,2 mm for Rotary Hammer Bosch GBH 2-22 RE 1610101011 Shim Washer 1,2 mm for Rotary Hammer Bosch GBH 2-22 RE €1.67
42
 photo_cameraImage coming soon 1610202015 Plain bearing €2.40
43
 photo_cameraImage coming soon 1611098005 Tab Washer €2.40
44
 photo_cameraImage coming soon 1615820092 Switching Element €2.40
45
 Switch Spring for Hammer Bosch GBH 2-24 DFR 1614651014 Switch Spring for Hammer Bosch GBH 2-24 DFR €1.87
46
 Red Knob Switch Pin for Hammers Bosch GBH 36V-VF-LI 1614690002 Red Knob Switch Pin for Hammers Bosch GBH 36V-VF-LI €1.67
48
 Holding Plate for Rotary Hammer Bosch GBH 36 VF-LI 1611016003 Holding Plate for Rotary Hammer Bosch GBH 36 VF-LI €2.22
49
 photo_cameraImage coming soon 1612026088 Switch Button RED €1.64
50/9
 photo_cameraImage coming soon 1610508026 Protective Cap L=21,5 MM, SDS-PLUS €3.75
50
 photo_cameraImage coming soon 1618598175 Quick-Change Collet Chuck L=70 MM SDS-PLUS €83.24
52
 photo_cameraImage coming soon 1615500309 Cover €5.12
57
 photo_cameraImage coming soon 1610390025 Stop Bushing €7.92
58
 photo_cameraImage coming soon 1610390026 Guide Ring €11.32
59
 photo_cameraImage coming soon 1610910080 Needle bearing €2.85
60
 photo_cameraImage coming soon 1610910073 Needle-Roller Bearing €9.42
61
 photo_cameraImage coming soon 1610910098 Needle bearing €2.96
64
 photo_cameraImage coming soon 1610913010 Needle-Roller Assembly €3.90
65
 photo_cameraImage coming soon 1610591016 Plain bearing €2.02
67
 photo_cameraImage coming soon 1610905016 groove ball bearing €8.24
69
 photo_cameraImage coming soon 1610283041 Rotary shaft lip seal €5.12
70
 photo_cameraImage coming soon 1610283023 Rotary shaft lip seal €4.35
71
 Scraper for Hammer Bosch GBH 2-24 DFR 1610290029 Scraper for Hammer Bosch GBH 2-24 DFR €2.88
73
 O-Ring 17,0x3,0 MM Green for Rotary Hammer Bosch GBH 3-28 DFR 1610210121 O-Ring 17,0x3,0 MM Green for Rotary Hammer Bosch GBH 3-28 DFR €2.76
74
 photo_cameraImage coming soon 1610210104 O-Ring 11,0x3,5 MM €2.02
75
 photo_cameraImage coming soon 1610210159 O-Ring 18,0x3,5 MM €2.67
76
 O-Ring 10,5x2,7 mm for Hammers Bosch GBH 36V-VF-LI 1610210046 O-Ring 10,5x2,7 mm for Hammers Bosch GBH 36V-VF-LI €1.67
77
 photo_cameraImage coming soon 1610210106 O-Ring 60,0x3,0 MM €2.02
80
 photo_cameraImage coming soon 1614634006 Compression Spring €5.12
83
 photo_cameraImage coming soon 1614611010 Compression Spring €2.85
85
 Retaining Ring for Rotary Hammer Bosch GBH 2-24 DFR 1614601011 Retaining Ring for Rotary Hammer Bosch GBH 2-24 DFR €1.56
88
 Cylindrical Roller for Hammers Bosch GBH 2-24 DFR-PBH 300 E 1613200007 Cylindrical Roller for Hammers Bosch GBH 2-24 DFR-PBH 300 E €2.17
89
 photo_cameraImage coming soon 2910141168 Hex Socket Head Cap Screw DIN 912-M 5x35-8.8 €3.75
90
 photo_cameraImage coming soon 2910141168 Hex Socket Head Cap Screw DIN 912-M 5x35-8.8 €3.75
91/1
 photo_cameraImage coming soon 2910211038 Tapping Screw DIN 7971-ST4,8x38-F €1.26
92
 photo_cameraImage coming soon 2912401019 Tapping Screw DIN7981-ST3,9x16-C-Z  €1.48
94
 photo_cameraImage coming soon 2603435015 Recessed-Head Screw DIN 7981-ST3,5x9,5-F €2.02
96
 photo_cameraImage coming soon 2912401018 Tapping Screw DIN7981-ST3,9x13-C-Z €1.41
97
 photo_cameraImage coming soon 1615108099 Handle Cover €7.92
98
 photo_cameraImage coming soon 1615133030 Cover BLACK €9.05
120
 photo_cameraImage coming soon 1612025060 Auxiliary Handle M8 BLACK €7.20
121
 photo_cameraImage coming soon 1618040054 index turning toolholder Ø51x110 MM €5.12
122
 photo_cameraImage coming soon 1613490002 T-Head Bolt M8x40 MM €6.32
123
 photo_cameraImage coming soon 1611316009 Clamping Band Ø51 MM €4.51
125
 photo_cameraImage coming soon 1614448035 Connecting Cable L=330 MM WHITE €1.94
126
 photo_cameraImage coming soon 1614448036 Connecting Cable L=215 MM BLUE €1.64
325/54
 photo_cameraImage coming soon 1616333029 Crown Gear Z=32 €11.32
325/79
 photo_cameraImage coming soon 2600210003 O-Ring 40,0x1,5 MM €1.94
661
 Grease Tube 30 ML for Bosch Hammer GBH-GSH 1615430010 Grease Tube 30 ML for Bosch Hammer GBH-GSH €9.33
805
 photo_cameraImage coming soon 1614460026 Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F €19.60
808
 photo_cameraImage coming soon 1601106032 Nameplate 26x52 MM €2.61
816/04
 photo_cameraImage coming soon 1617014124 Carbon-Brush Set €12.76
819
 photo_cameraImage coming soon 1617000833 Impact Mechanism Housing €60.83
820
 photo_cameraImage coming soon 1617000315 Gear Housing €66.59
821
 photo_cameraImage coming soon 1617000978 Ratchet Sleeve €43.34
821/01
 photo_cameraImage coming soon 1617000979 Ratchet Sleeve €111.25
823
 photo_cameraImage coming soon 1616328044 Gear Sleeve Z=25 €31.45
825
 photo_cameraImage coming soon 1615805064 Bearing Flange €39.64
826
 photo_cameraImage coming soon 1617000516 Toothed Shaft Z=3/9 €80.21
830
 photo_cameraImage coming soon 1615819022 Drive end shield €72.65
853
 photo_cameraImage coming soon 1617000196 Pinion Z=15 €49.40
855
 photo_cameraImage coming soon 1617000982 Jack Shaft Z=9 €24.20
898
 photo_cameraImage coming soon 1617000197 Wear and Tear Part Set €31.45
899
 photo_cameraImage coming soon 1617000198 Wear and Tear Part Set €31.45
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 2
Pos. Item Price Buy
120
 photo_cameraImage coming soon 1612025060 Auxiliary Handle M8 BLACK €7.20
121
 photo_cameraImage coming soon 1618040054 index turning toolholder Ø51x110 MM €5.12
122
 photo_cameraImage coming soon 1613490002 T-Head Bolt M8x40 MM €6.32
123
 photo_cameraImage coming soon 1611316009 Clamping Band Ø51 MM €4.51
661
 Grease Tube 30 ML for Bosch Hammer GBH-GSH 1615430010 Grease Tube 30 ML for Bosch Hammer GBH-GSH €9.33

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Bosch Spare Parts for Rotary Hammer PBH 300 E

Bosch original spare parts for replacing damaged parts or fix broken and worn parts of the Rotary Hammer PBH 300 E - 0603358760.

In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
Bosch PBH 300 E - 0603358760

Rotary Hammer PBH 300 E/0 603 358 760
# Part Num. Description
1 1615108102 Motor Housing GREEN
2 1614220117 Field 230V
3 1614010128 Armature With Fan 220-230V
4 2607200512 Switch
6 2600703018 Grommet Ø7,3-Ø8,6x76 MM
7 1601302018 Fastening Clamp
9 1611110A33 Manufacturer's nameplate
10 1611110A34 Reference Plate
13 1610905025 Deep-Groove Ball Bearing 7x19x6 607 V
14 1900900289 Deep-Groove Ball Bearing 12x28x8
15 1606610132 Fan
18 1610591011 Air-Deflector Ring
22 1616317602 Cylindrical Gear Z=50
24 1617000500 Toothed Shaft Z=3/9
26 1618700063 Hammer Piston
27 1618710060 Striker
28 1613124043 Striker Pin
29 1613105012 Piston Pin
32 1612026089 Clamp Handle
33 1610190016 Perforated disk
34 1610005000 Felt Disc
35 1610206021 Rubber Ring
36 1610390016 Guide Bushing
37 1610390032 Damping Bushing Ø21 MM
38 1610102026 Supporting Disc
41 1610101011 Shim washer 1,2 MM THICK
42 1610202015 Plain bearing
43 1611098005 Tab Washer
44 1615820092 Switching Element
45 1614651014 Switch Spring
46 1614690002 Driver Pin
48 1611016003 Holding Plate
49 1612026088 Switch Button RED
50 1618598175 Quick-Change Collet Chuck L=70 MM SDS-PLUS
50/9 1610508026 Protective Cap L=21,5 MM, SDS-PLUS
52 1615500309 Cover
57 1610390025 Stop Bushing
58 1610390026 Guide Ring
59 1610910080 Needle bearing
60 1610910073 Needle-Roller Bearing
61 1610910098 Needle bearing
62 1610200020 Plain bearing
63 1610910064 Needle bearing
64 1610913010 Needle-Roller Assembly
65 1610591016 Plain bearing
67 1610905016 Deep-Groove Ball Bearing
68 1610119009 Retaining ring
69 1610283041 Rotary shaft lip seal
70 1610283023 Rotary shaft lip seal
71 1610290029 Scraper
73 1610210121 O-Ring 17,0x3,0 MM GREEN
74 1610210104 O-Ring 11,0x3,5 MM
75 1610210159 O-Ring 18,0x3,5 MM
76 1610210046 O-Ring 10,5x2,7 MM
77 1610210106 O-Ring 60,0x3,0 MM
78/1 1610134005 Shim 0,1 MM THICK
78/2 1610134006 Shim 0,2 MM THICK
80 1614634006 Compression Spring
81 1614611009 Compression Spring
83 1614611010 Compression Spring
84 1610101627 Supporting Disc 1,2 MM THICK
85 1614601011 Retaining ring
86 1614601024 Retaining ring
87 1610390027 Screw Bushing
88 1613200007 Roller
89 2910141168 Hex Socket Head Cap Screw DIN 912-M 5x35-8.8
90 2910141168 Hex Socket Head Cap Screw DIN 912-M 5x35-8.8
91 2910211036 Tapping Screw DIN 7971-ST4,8x25-F
91/1 2910211038 Tapping Screw DIN 7971-ST4,8x38-F
92 2912401019 Tapping Screw DIN7981-ST3,9x16-C-Z
93 2910141162 Hex Socket Head Cap Screw DIN 912-M5x20-8.8
94 2603435015 Recessed-Head Screw DIN 7981-ST3,5x9,5-F
96 2912401018 Tapping Screw DIN7981-ST3,9x13-C-Z
97 1615108099 Handle Cover
98 1615133030 Cover BLACK
99 2910211005 Tapping Screw DIN 7971-ST2,9x9,5-F
100 2914211311 Oval-Head Screw 40 x 35MM
120 1612025060 Auxiliary Handle M8 BLACK
121 1618040054 index turning toolholder Ø51x110 MM
122 1613490002 T-Head Bolt M8x40 MM
123 1611316009 Clamping Band Ø51 MM
125 1614448035 Connecting Cable L=330 MM WHITE
126 1614448036 Connecting Cable L=215 MM BLUE
325/54 1616333029 Crown Gear Z=32
325/79 2600210003 O-Ring 40,0x1,5 MM
661 1615430010 Grease Tube 30 ML
713 2607001316 Keyless Chuck Ø1-Ø13 MM, 1/2"
720 2602025077 Auxiliary Handle Ø 51 MM
724 1613001003 Depth-Gauge SW 6x330 MM
791 2605438389 Carrying Case
805 1614460026 Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F
808 1601106032 Nameplate 26x52 MM
816 1617000357 Brush Holder
816/04 1617014124 Carbon-Brush Set
816/05 1614652002 Spiral Spring
819 1617000833 Impact Mechanism Housing
820 1617000315 Gear Housing
821 1617000978 Ratchet Sleeve
821/01 1617000979 Ratchet Sleeve
823 1616328044 Gear Sleeve Z=25
825 1615805064 Bearing Flange
826 1617000516 Toothed Shaft Z=3/9
830 1615819022 Drive end shield
853 1617000196 Pinion Z=15
855 1617000982 Jack Shaft Z=9
898 1617000197 Wear and Tear Part Set
899 1617000198 Wear and Tear Part Set
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch PBH 300 E - 0603358760
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS

Specific References

New

Download

Diagram Bosch PBH 300 E

Diagram Bosch PBH 300 E

Download (254.91KB)

You might also like

Ball DIN 5401-5,5 mm for Bosch Impact Drills GSB16-18-20-22
Bosch SKU: 1903230010
Ball DIN 5401-5,5 mm for Bosch Impact Drills GSB16-18-20-22
Ball DIN 5401-5,5 mm for Bosch Impact Drills GSB16-18-20-22 Bosch genuine parts, Ball DIN 5401-5,5MM-III-ST, for Impact Drills GSB 16 RE - GSB 18-2 RE - GSB 20-2 RE - GSB 22-2 RE - PSB 700-2 RE - PSB 800-2 RA - PBH 240 RE. Parts for...
AVAILABLE €1.91
Details
Switch Change-Over for Impact Drills Bosch GSB16-18/2RE
Bosch SKU: 2607200231
Switch Change-Over for Impact Drills Bosch GSB16-18/2RE
Switch Change-Over for Impact Drills Bosch GSB16-18/2RE Genuine parts Bosch, Switch Change-Over for Impact Drills GSB 16 RE/0 601 140 603 - GSB 18-2 RE/0 601 141 603 - PBH 220 RE/0 603 336 703 - PBH 240 RE/0 603 326 703. Part for the...
AVAILABLE €16.62
Details
Front Hood for Hammer Bosch PBH 220 RE
Bosch SKU: 1610508008
Front Hood for Hammer Bosch PBH 220 RE
Front Hood for Hammer Bosch PBH 220 RE Original parts Bosch, Protection Hood L = 17 MM for Hammers SDS-PLUS Bosch PBH 220 RE/0603336703. Parts for the following products: - PBH 220 RE / 0603336703 - Code: 1610508008
AVAILABLE €2.89
Details
Switch for Hammer Bosch PBH 2000 RE-SRE
Bosch SKU: 1617200515
Switch for Hammer Bosch PBH 2000 RE-SRE
Switch for Hammer Bosch PBH 2000 RE-SRE Genuine parts Bosch, ON/OFF switch for Hammers PBH 2000 RE/3 603 C44 300 - PBH 2000 SRE/3 603 C44 301. Parts for the following articles: -  Hammer PBH 2000 RE/3 603 C44 300 -  Hammer...
Last items in stock €37.98
Details
Red Knob Switch for Hammers Bosch GBH 36V-VF-LI
Bosch SKU: 1612026035
Red Knob Switch for Hammers Bosch GBH 36V-VF-LI
Red Knob Switch for Hammers Bosch GBH 36V-VF-LI Original parts Bosch, Red Knob Switch for Hammers Bosch GBH GBH 36 VF-LI - GBH 36 V-LI/3 - GBH 2-23 RE/3 - PBH 220 RE/0 - PBH 240 RE. Parts for segunti articles: - Hammer Bosch GBH 36...
AVAILABLE €1.67
Details
Red Knob Switch Pin for Hammers Bosch GBH 36V-VF-LI
Bosch SKU: 1614690002
Red Knob Switch Pin for Hammers Bosch GBH 36V-VF-LI
Red Knob Switch Pin for Hammers Bosch GBH 36V-VF-LI Original parts Bosch, Red Knob Switch Pin for Hammers Bosch GBH GBH 36 VF-LI - GBH 36 V-LI/3 - GBH 2-23 RE/3 - PBH 220 RE/0 - PBH 240 RE. Parts for segunti articles: - Hammer Bosch...
AVAILABLE €1.67
Details
O-Ring 10,5x2,7 mm Switch for Hammers Bosch GBH 36V-VF-LI
Bosch SKU: 1610210046
O-Ring 10,5x2,7 mm for Hammers Bosch GBH 36V-VF-LI
O-Ring 10,5x2,7 mm for Hammers Bosch GBH 36V-VF-LI Original part Bosch, O-Ring 10,5x2,7 mm for Hammers Bosch GBH GBH 36 VF-LI - GBH 36 V-LI/3 - GBH 2-23 RE/3 - PBH 220 RE/0 - PBH 240 RE. Part for the following products: -...
AVAILABLE €1.67
Details
Grease Tube 30 ML for Bosch Hammer GBH-GSH
Bosch SKU: 1615430010
Grease Tube 30 ML for Bosch Hammer GBH-GSH
Grease Tube 30 ML for Bosch Hammer GBH-GSH Genuine spare parts Bosch, Grease Tube 30 ML for Bosch Hammer GBH 11 DE/0 611 245 703 - GBH 7-46 DE/0 611 263 703 - GBH 5/40 DCE/0 611 216 703 - GBH 5-38 D - 0 611 240 003 - GBH...
on 7/10 Business Days Approx €9.33
Details
Front Hood for Hammer Bosch GBH-PBH
Bosch SKU: 1610508047
Front Hood for Hammer Bosch GBH-PBH
Front Hood for Hammer Bosch GBH-PBH Original parts Bosch, Front Hood for Hammer Bosch GBH 36 VF-LI/3 611 J01 R00 - GBH 36 V-LI/3 611 J00 R00 - GBH 3-28 DFR/3 611 B4A 000 - GBH 2-26 DFR/0 611 254 703 - GBH 2-23 RE/3 611 B50 400 - PBH...
Last items in stock €2.89
Details
Carbon Brushes Holder for Hammer Bosch GBH 2-24 DFR
Bosch SKU: 1617000343
Carbon Brushes Holder for Hammer Bosch GBH 2-24 DFR
Carbon Brushes Holder for Hammer Bosch GBH 2-24 DFR Bosch original replacement, Carbon Brusches Holders Assy for Hammers GBH 2-24 DFR/0 611 238 703 - PBH 220 RE/0 603 336 703 - PBH 240 RE/0 603 326 703. Parts for the following...
AVAILABLE €16.62
Details
Retaining Ring mm 24x29x2,5 for Hammer Bosch GBH 2-24 DFR Sale
Bosch SKU: 1614601026
Retaining Ring mm 24x29x2,5 for Hammer Bosch GBH 2-24 DFR
Retaining Ring mm 24x29x2,5 for Hammer Bosch GBH 2-24 DFR Bosch original parts, Retaining Ring mm 24x29x2,5 for Hammers GBH 2-24 DFR/0 611 238 703 - PBH 220 RE/0 603 336 703 - PBH 240 RE/0 603 326 703. Parts for segunti articles: -...
AVAILABLE €1.58
Details
Suppression Filter for Hammer Bosch GBH 2-24 DFR
Bosch SKU: 1617328026
Suppression Filter for Hammer Bosch GBH 2-24 DFR
Suppression Filter for Hammer Bosch GBH 2-24 DFR Original parts Bosch, Suppression Filter for Hammers GBH 2-24 DFR - PBH 220 RE - PBH 240 RE. Parts for the following products: -  Hammer Bosch GBH...
Usually Ships in: 7/10 Business Days Approx. €8.99
Details
White Wire 130 mm for Rotary Hammer Bosch GBH 2-24 DFR
Bosch SKU: 2604448005
White Wire 130 mm for Rotary Hammer Bosch GBH 2-24 DFR
White Wire 130 mm for Rotary Hammer Bosch GBH 2-24 DFR Bosch original replacement, Carbon Brusches Holders Assy White Wire 130 mm for Rotary Hammer Bosch GBH 2-24 DFR - GSB 20-2 RE - PBH 220 RE - PBH 240 RE Parts for the following...
AVAILABLE €2.61
Details
Carbon Brushes for Rotary Hammer Bosch GBH 2-24 DFR
Bosch SKU: 1617014134
Carbon Brushes for Rotary Hammer Bosch GBH 2-24 DFR
Carbon Brushes for Rotary Hammer Bosch GBH 2-24 DFR Bosch original replacement, Carbon Brusches for Rotary Hammer Bosch GBH 2-24 DFR/0 611 238 703 - PBH 220 RE/0 603 336 703 Part for the following products: -  Rotary Hammer Bosch GBH...
AVAILABLE €12.27
Details
Rubber Bushing for Hammer Bosch GBH 2-24 DFR
Bosch SKU: 1610206021
Rubber Bushing for Hammer Bosch GBH 2-24 DFR
Rubber Bushing for Hammer Bosch GBH 2-24 DFR Genuine replacement Part Bosch, Rubber Bushing for Rotary Hammers GBH 2-24 DFR/0 611 238 703 - PBH 300 E/0 603 358 760. Part for the following products: - Rotary Hammer Bosch GBH 2-24 DFR/0...
AVAILABLE €2.89
Details
Switch Spring for Hammer Bosch GBH 2-24 DFR Sale
Bosch SKU: 1614651014
Switch Spring for Hammer Bosch GBH 2-24 DFR
Switch Spring for Hammer Bosch GBH 2-24 DFR Bosch original parts, Switch Spring for Hammers GBH 2-24 DFR/0 611 238 703 - PPBH 220 RE/0 603 336 703 - PBH 240 RE/0 603 326 703 Parts for the following products: - Hammer Bosch GBH 2-24...
AVAILABLE €1.87
Details
Scraper for Hammer Bosch GBH 2-24 DFR
Bosch SKU: 1610290029
Scraper for Hammer Bosch GBH 2-24 DFR
Scraper for Hammer Bosch GBH 2-24 DFR Original parts Bosch, Scraper for Rotary Hammers GBH 2-24 DFR - PBH 220 RE - PBH 240 RE - PBH 300 E Parts for the following products: - Rotary Hammer Bosch GBH 2-24 DFR/0 611 238 703 - Rotary...
AVAILABLE €2.88
Details
Holding Plate for Rotary Hammer Bosch GBH 36 VF-LI
Bosch SKU: 1611016003
Holding Plate for Rotary Hammer Bosch GBH 36 VF-LI
Holding Plate for Rotary Hammer Bosch GBH 36 VF-LI Bosch original part, Holding Plate for Rotary Hammers GBH 36 VF-LI - GBH 2-26 DFR - GBH 2-20 D - GBH 2-24 DFR - PBH 300 E - PBH 220 RE - PBH 240 RE Part for the following products: -...
AVAILABLE €2.22
Details
Shim Washer 1,2 mm for Rotary Hammer Bosch GBH 2-22 RE
Bosch SKU: 1610101011
Shim Washer 1,2 mm for Rotary Hammer Bosch GBH 2-22 RE
Shim Washer 1,2 mm for Rotary Hammer Bosch GBH 2-22 RE Genuine Part Bosch, Shim Washer 1,2 mm for Cordless Hammer Bosch GBH 36 VF-LI/3 611 J01 R00 - GBH 36 V-LI/3 611 J00 R00. Parts for the following products: - Rotary hammer Bosch...
AVAILABLE €1.67
Details
Fan for Rotary Hammer Bosch PBH 300 E Sale
Bosch SKU: 1606610132
Fan for Rotary Hammer Bosch PBH 300 E
Fan for Rotary Hammer Bosch PBH 300 E Genuine Part Bosch, Fan for Rotary Hammer PBH 300 E - Wall Chaser GNF 35 CA - Angle Grinder 1801 - Angle Grinder AG40-11P - Polisher GP712VS. Parts for the following products: - Rotary Hammer PBH...
AVAILABLE €3.08
Details
Retaining Ring for Rotary Hammer Bosch GBH 2-24 DFR
Bosch SKU: 1614601011
Retaining Ring for Rotary Hammer Bosch GBH 2-24 DFR
Retaining Ring for Rotary Hammer Bosch GBH 2-24 DFR Bosch original replacement, Retaining Ring for Rotary Hammer Bosch GBH 2-24 DFR - PBH 220 RE - PBH 300 E - PBH 240 RE. Parts for the following products: - Rotary Hammer GBH 2-24...
AVAILABLE €1.56
Details
Supporting Disc for Rotary Hammer Bosch GBH 2-24 DFR
Bosch SKU: 1610102026
Supporting Disc for Rotary Hammer Bosch GBH 2-24 DFR
Supporting Disc for Rotary Hammer Bosch GBH 2-24 DFR Bosch original replacement, Supporting Disc for Rotary Hammers GBH 2-24 DFR - 0611238703 - PBH 220 RE - 0603336 03 - PBH 240 RE - 0603326703. Parts for the following products: -...
Last items in stock €2.58
Details
O-Ring 17,0x3,0 MM Green for Rotary Hammer Bosch GBH 3-28 DFR
Bosch SKU: 1610210121
O-Ring 17,0x3,0 MM Green for Rotary Hammer Bosch GBH 3-28 DFR
O-Ring 17,0x3,0 MM Green for Rotary Hammer Bosch GBH 3-28 DFR Bosch original part, O-Ring 17,0x3,0 MM Green for Rotary Hammer GBH 3-28 DFR - 3-28 DRE - PBH 300 E Part for the following products: -  3611B4A000 GBH 3-28 DFR - Rotary...
on 7/10 Business Days Approx. €2.76
Details
Comments (0)
