Annovi Reverberi S.p.A.

Annovi Reverberi DTS 5.0 XE Parts

SKU: Annovi Rev. DTS 5.0 XE
€8.53
VAT included

Annovi Reverberi DTS 5.0 XE

We have the original Annovi Reverberi Parts for Pressure Washer Series DTS - 5.0 XE - 15002-V, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Pressure Washer Annovi Reverberi Series DTS - 5.0 XE - 15002-V. All Spares are original and can be supplied at Low and discounted prices.

Pressure Washer Annovi Reverberi Series DTS 5.0 XE - 15002-V

Annovi Reverberi DTS 5.0 XE Parts
  • Annovi Reverberi DTS 5.0 XE Parts
  • Annovi Reverberi DTS - 5.0 - 14793 Spare Parts
  • Annovi Reverberi DTS - 5.0 - 14793 Spare Parts
  • Annovi Reverberi DTS - 5.0 - 14793 Spare Parts
  • Annovi Reverberi DTS - 5.0 - 14793 Spare Parts
  • Annovi Reverberi DTS - 5.0 - 14793 Spare Parts
  • Annovi Reverberi DTS - 5.0 - 14793 Spare Parts
  • Annovi Reverberi DTS - 5.0 - 14793 Spare Parts
Annovi Reverberi S.p.A.

Annovi Reverberi DTS 5.0 XE Parts

SKU: Annovi Rev. DTS 5.0 XE Condition: New
€8.53
VAT included

Annovi Reverberi DTS 5.0 XE

We have the original Annovi Reverberi Parts for Pressure Washer Series DTS - 5.0 XE - 15002-V, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Pressure Washer Annovi Reverberi Series DTS - 5.0 XE - 15002-V. All Spares are original and can be supplied at Low and discounted prices.

Pressure Washer Annovi Reverberi Series DTS 5.0 XE - 15002-V

settings 97 Spare parts
description 7 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN: Usually Ships in 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR: AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
Machine Type: Pump
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
97 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 4580530 Guard €10.44
2
 Image coming soon 4580520 Guard €18.04
3
 Image coming soon 4580800 Plug €1.92
4
 Image coming soon 4580672 Grey RAL 7042 knob €9.26
5
 Image coming soon 4580630 Lock €1.42
6
 Image coming soon 4580500 Casing €23.34
7
 Annovi Accessory Holder for AR589 4580590 Annovi Accessory Holder for AR589 €6.56
8
 Image coming soon 4582020 Screw €0.34
9
 Image coming soon 4381640 Rubber foot €1.65
10
 Image coming soon 4582020 Screw €0.34
11
 Image coming soon 3080580 cable clamp €1.37
Page 2 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 4820410 Cover €1.04
2
 Image coming soon 4581950 Screw €0.51
3
 Image coming soon 4581960 Washer €0.35
4
 Image coming soon 4580540 Bracket €7.65
5
 Image coming soon 4101710 Ring €0.83
6
 Image coming soon 4200060 Ring €0.35
7
 Image coming soon 5460660 O-ring €0.12
8
 Image coming soon 4101760 Fitting €19.15
9
 Image coming soon 4101520 Fork €0.40
10
 Image coming soon 4582180 Fitting €16.34
11
 Image coming soon 4581970 O-ring €0.35
12
 Image coming soon 4580450 Screw €0.57
13
 Image coming soon 4101770 Plate €11.18
14
 Image coming soon 4102120 Support €4.12
15
 Image coming soon 4101680 Plate €11.18
16
 Image coming soon 50943 Screw €1.85
17
 Image coming soon 4580550 Bracket €7.65
18
 Image coming soon 50943 Screw €1.85
19
 Image coming soon 4101750 Hub pin €2.54
20
 Image coming soon 5460700 Screw €0.35
21
 Image coming soon 4101660 Lever €3.68
22
 Knob 4101673 Knob €2.54
23
 Image coming soon 4581980 Screw €0.23
24
 Image coming soon 4382520 O-ring €0.48
25
 O-Ring mm 10x2,5 for Pressure Washers Black & Decker 3083380 O-Ring mm 10x2,5 for Pressure Washers Black & Decker €0.46
26
 Image coming soon 4581060 High pressure hose €26.12
Page 3 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 4580610 Knob €4.89
2
 Image coming soon 4580600 Handle €10.69
3
 Image coming soon 50943 Screw €1.85
4
 Image coming soon 4581990 Screw €0.51
5
 Image coming soon 4582000 Nut €0.35
6
 Image coming soon 4580770 Pipe €17.80
7
 Image coming soon 50943 Screw €1.85
8
 Image coming soon 4821080 Guide €4.34
9
 Image coming soon 50943 Screw €1.85
10
 Image coming soon 4821110 Hook €1.11
11
 Image coming soon 4821020 Spring €0.35
12
 Image coming soon 4220271 Lever €0.45
13
 Image coming soon 4580560 base €24.63
14
 Image coming soon 4580620 Accessories carrier €9.16
15
 Image coming soon 2180330 Rubber €3.86
16
 Image coming soon 50943 Screw €1.85
17
 Image coming soon 4580760 Accessories carrier €7.81
18
 Image coming soon 50943 Screw €1.85
19
 Image coming soon 4581960 Washer €0.35
20
 Image coming soon 50943 Screw €1.85
21
 Image coming soon 4580790 Plug €1.49
22
 Image coming soon 4220280 Accessories carrier €1.31
23
 Image coming soon 5460700 Screw €0.35
24
 Image coming soon 4580570 Cover €1.31
25
 Image coming soon 4580780 Guard €1.63
26
 Image coming soon 50943 Screw €1.85
27
 Image coming soon 4580880 Axle €15.03
28
 Image coming soon 4381100 Wheel €23.34
29
 Image coming soon 4980170 Washer €0.81
30
 Image coming soon 4980160 Pin €1.04
31
 Image coming soon 4381631 Guard €10.64
Page 4 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 4580640 Conveyor €8.63
2
 Gland 4580660 Gland €2.12
3
 Image coming soon 5480500 Screw €0.23
4
 Suction Kit for Pressure Washer ARBC 4.0 Twin Flow 4580900 Suction Kit for Pressure Washer ARBC 4.0 Twin Flow €11.50
5
 Image coming soon 4380180 Protection €3.07
6
 Image coming soon 4580911 Delivery kit €23.09
7
 Image coming soon 4580650 Conveyor €8.20
8
 Image coming soon 4580870 Rubber foot €5.76
9
 Image coming soon 4580840 Guard €5.04
10
 Image coming soon 5480500 Screw €0.23
Page 5 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
A
 Valves + Oil Seal Kit for Pressure Washers B&D BXPW 1300 E-1400 E 3480140 Valves + Oil Seal Kit for Pressure Washers B&D BXPW 1300 E-1400 E €6.51
B
 Pistons + Oil Seal Kit for Pressure Washers B&D BXPW 1300 E-1400 E 3480150 Pistons + Oil Seal Kit for Pressure Washers B&D BXPW 1300 E-1400 E €21.86
D2
 Image coming soon 3480570 Engine brush kit €7.44
C
 Image coming soon 4384500 TSS box kit Da XXXXX-38250001 €14.26
E2
 Image coming soon 4580950 TSS plug kit €12.20
E1
 TSS kit 4581860 TSS kit €10.25
C
 Image coming soon 4581870 TSS kit €16.76
D1
 Image coming soon 5000800 Engine brush kit €8.36
E1
 Image coming soon 5480560 TSS valve kit €11.68
1
 AR Blue Clean 4.0 Twin Flow Electric Pump Assy 4580970 AR Blue Clean 4.0 Twin Flow Electric Pump Assy €143.23
1
 Image coming soon 5480540 Electric pump assembly Da XXXXX-38250001 €121.52
2
 Image coming soon 4580960 Electric pump assembly €128.04
Page 6 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 6
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 4380840 Cover €3.75
2
 Image coming soon 2180670 O RING €1.99
3
 AR Blue Clean 4.0 Twin Flow Switch 4580050 AR Blue Clean 4.0 Twin Flow Switch €19.15
4
 Image coming soon 3086000 Capacitor kit €14.98
5
 Gland 4580660 Gland €2.12
6
 Image coming soon 4580680 Box €5.33
7
 Image coming soon 50943 Screw €1.85
8
 Image coming soon 2021480 Grommet €2.54
9
 Image coming soon 5480800 EMC Interference filter €6.03
10
 Image coming soon 4580930 Cable €24.63
Page 7 zoom_in View exploded local_shipping Usually Ships in 10/15 BUSINESS DAYS
Esploso pagina 7
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Image coming soon 4381482 Gun €22.79
2
 O-Ring for Pressure Washers Black & Decker 3083700 O-Ring for Pressure Washers Black & Decker €0.40
3
 Image coming soon 4381492 Extension €19.36
4
 O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker 3083370 O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker €0.40
5
 Image coming soon 4581010 Lanceheads-holder €13.68
6
 AR Rev. 4.0 Rotopower head 4580990 AR Rev. 4.0 Rotopower head €15.21
7
 Image coming soon 4102370 Lance head €35.65
8
 Image coming soon 4580980 Tank €16.38
9
 O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker 3083400 O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker €0.40
10
 Image coming soon 4581180 High pressure hose €39.46
11
 Kit Water Inlet for Pressure Washer Blue Clean AR395-490-588-590 3082130 Kit Water Inlet for Pressure Washer Blue Clean AR395-490-588-590 €4.94

Shipping and delivery information will be available shortly.

Annovi Reverberi DTS 5.0 XE

We have the original Annovi Reverberi Parts for Pressure Washer Series DTS - 5.0 XE - 15002-V, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Pressure Washer Annovi Reverberi Series DTS - 5.0 XE - 15002-V. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.
Annovi Reverberi Series DTS - 5.0 XE - 15002-V

5.0 XE - 15002-V
Casing Pag.1
Pos. Codice Descrizione
1 4580530 Guard
2 4580520 Guard
3 4580800 Plug
4 4580672 Knob
5 4580630 Lock
6 4580500 Casing
7 4580590 Accessories carrier
8 4582020 Screw
9 4381640 Rubber foot
10 4582020 Screw
11 3080580 Cable gland
Hose Reel Pag.2
1 4820410 Cover
2 4581950 Screw
3 4581960 Washer
4 4580540 Bracket
5 4101710 Ring
6 4200060 Ring
7 5460660 O-ring
8 4101760 Fitting
9 4101520 Fork
10 4582180 Fitting
11 4581970 O-ring
12 4580450 Screw
13 4101770 Plate
14 4102120 Support
15 4101680 Plate
16 50943 Screw
17 4580550 Bracket
18 50943 Screw
19 4101750 Hub pin
20 5460700 Screw
21 4101660 Lever
22 4101673 Knob
23 4581980 Screw
24 4382520 O-ring
25 3083380 O-ring
26 4581060 High pressure hose
Carriage Pag.3
1 4580610 Knob
2 4580600 Handle
3 50943 Screw
4 4581990 Screw
5 4582000 Nut
6 4580770 Pipe
7 50943 Screw
8 4821080 Guide
9 50943 Screw
10 4821110 Hook
11 4821020 Spring
12 4220271 Lever
13 4580560 Base
14 4580620 Accessories carrier
15 2180330 Rubber foot
16 50943 Screw
17 4580760 Accessories carrier
18 50943 Screw
19 4581960 Washer
20 50943 Screw
21 4580790 Plug
22 4220280 Accessories carrier
23 5460700 Screw
24 4580570 Cover
25 4580780 Guard
26 50943 Screw
27 4580880 Axle
28 4381100 Wheel
29 4980170 Washer
30 4980160 Pin
31 4381631 Guard
Guard Pag.4
1 4580640 Conveyor
2 4580660 Gland
3 5480500 Screw
4 4580900 Suction kit
5 4380180 Guard
6 4580911 Delivery kit
7 4580650 Conveyor
8 4580870 Rubber foot
9 4580840 Guard
10 5480500 Screw
Electric Pump Pag.5
1 4580970 Electric pump assembly Fino a XXXXX-37259999
1 5480540 Electric pump assembly Da XXXXX-38250001
2 4580960 Electric pump assembly
A 3480140 Valves + seals kit
B 3480150 Piston + seals kit
C 4581870 TSS box kit Fino a XXXXX-37259999
C 4384500 TSS box kit Da XXXXX-38250001
D1 5000800 Brush kit for motor
D2 3480570 Brush kit for motor
E1 4581860 Valve kit TSS Fino a XXXXX-37259999
E1 5480560 Valve kit TSS Da XXXXX-38250001
E2 4580950 TSS plug kit
Electric Circuit Pag.6
1 4380840 Cover
2 2180670 O-ring
3 4580050 Switch
4 3086000 Capacitor kit
5 4580660 Gland
6 4580680 Box
7 50943 Screw
8 2021480 Gland
9 5480800 EMC Interference filter
10 4580930 Cable
Accessories Pag.7
1 4381482 Gun
2 3083700 O-ring
3 4381492 Extension
4 3083370 O-ring
5 4581010 Lanceheads-holder
6 4580990 Lance head (Rotopower)
7 4102370 Lance head
8 4580980 High pressure foam lance
9 3083400 O-ring
10 4581180 High pressure hose
11 3082130 Water coupling kit
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Annovi Rev. DTS 5.0 XE
6 Items

Data sheet

Machine Type
Pump
CHECK S/N AR
AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
SHIPPING IN
Usually Ships in 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT

Specific References

New

Download

AR AR DTS 5.0 XE Parts Drawing

AR AR DTS 5.0 XE Parts Drawing

Download (390.77KB)

You might also like

O-Ring for Pressure Washers Black & Decker
Annovi Reverberi S.p.A. SKU: 3083700
O-Ring for Pressure Washers Black & Decker
O-Ring for Pressure Washers Black & Decker Original Spare Parts Annovi & Rverberi, O-Ring For the Following Products: - Black & Decker - BXPW 1300 E - 14107 - Black & Decker - BXPW 1300 PE - 14117 - Black & Decker...
AVAILABLE €0.40
Details
Kit Motor Brushes for Pressure Washers B&D PW 1300S - 1400S
Annovi Reverberi S.p.A. SKU: 3480170
Kit Motor Brushes for Pressure Washers B&D PW 1300S - 1400S
Kit Motor Brushes for Pressure Washers B&D PW 1300S - 1400S Genuine part Black & Decker, Kit Motor Brushes for Pressure Washers B&D PW 1300 S-TD-TDW - 1400 S-TDK - TDK PLUS - PW 1500 S - S PLUS - BXPW 1300-1400-1500 E...
AVAILABLE €8.00
Details
O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker
Annovi Reverberi S.p.A. SKU: 3083400
O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker
O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker Original part Annovi & Rverberi, HP Hose O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker - Michelin - AR BC - ARSG - Stanley. Part for the...
Usually Ships in: 7/10 Business Days Approx. €0.40
Details
O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker
Annovi Reverberi S.p.A. SKU: 3083370
O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker
O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker Original part Annovi & Rverberi, HP Hose O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker - Michelin - AR BC - ARSG - Stanley. Part for the...
AVAILABLE €0.40
Details
Suction Kit for Pressure Washer ARBC 4.0 Twin Flow
Annovi Reverberi S.p.A. SKU: 4580900
Suction Kit for Pressure Washer ARBC 4.0 Twin Flow
Suction Kit for Pressure Washer ARBC 4.0 Twin Flow Original Part Annovi Reverberi, Suction Kit for Pressure Washers Twin-Flow > 4.0 ARBC - 14792 - Stanley > SXPW25DTS-E - 14796 . Replacement for the Following Products: -  AR...
Usually Ships in: 7/10 Business Days Approx. €11.50
Details
TSS-Kit for Pressure Washer AR Blue Clean DTS 4.0 - 5.0
Annovi Reverberi S.p.A. SKU: 4580940
TSS-Kit for Pressure Washer AR Blue Clean DTS 4.0 - 5.0
TSS-Kit for Pressure Washer AR Blue Clean DTS 4.0 - 5.0 Genuine part Annovi Reverberi, TSS-Kit for Pressure Washers AR Blue Clean Series DTS 4.0 - 5.0. Part for the following products: -  Cleaning - AR Blue Clean - HOME&GARDEN -...
Usually Ships in: 10 Business Days Approx. €19.49
Details
AR Blue Clean 4.0 Twin Flow Switch
Annovi Reverberi S.p.A. SKU: 4580050
AR Blue Clean 4.0 Twin Flow Switch
AR Blue Clean 4.0 Twin Flow Switch Genuine part Annovi Reverberi, 3-Way Square Rotary Switch for Twin Flow Pressure Washers. Parts For the Following Products: - Annovi Reverberi 4.0 Twin Flow 14792 - Stanley SXPW25DTS-E 14796 -...
Usually Ships in: 10/15 Business Days Approx. €19.15
Details
AR Blue Clean 4.0 Twin Flow Electric Pump Ass'y
Annovi Reverberi S.p.A. SKU: 4580970
AR Blue Clean 4.0 Twin Flow Electric Pump Assy
AR Blue Clean 4.0 Twin Flow Electric Pump Ass'y Genuine part Annovi Reverberi, Electric Pump Assembly for Twin Flow Pressure Washers. Parts For the Following Products: - Annovi Reverberi 4.0 Twin Flow 14792 - Stanley SXPW25DTS-E...
Usually Ships in: 10/15 Business Days Approx. €143.23
Details
AR Rev. 4.0 Rotopower head
Annovi Reverberi S.p.A. SKU: 4580990
AR Rev. 4.0 Rotopower head
AR Rev. 4.0 Twin Flow Rotopower Head Original spare part by Annovi & Reverberi, Rotopower Head for pressure washers Rev. 4.0 Twin Flow – Stanley SXPW25DTS-E – Twin-Flow 4.M – Annovi Rev. DTS4K. Parts for the following products: -...
Usually Ships in 10 Business Days Approx. €15.21
Details
Annovi Accessory Holder for AR589
Annovi Reverberi S.p.A. SKU: 4580590
Annovi Accessory Holder for AR589
Annovi Accessory Holder for Pressure Washer AR589 Genuine part Annovi Reverberi, Accessory Holder for Pressure Washer AR589 - AR 4.0 Twin Flow. Part for the Following Products: -  Pressure Washer Pressure Washer Annovi Reverberi...
Usually Ships in: 7/10 Business Days Approx. €6.56
Details
Comments (0)
No customer reviews for the moment.
