| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
M
|
|
4100990 Screw kit | €12.43 | |
|
1
|
|
4100270 Handle | €22.37 | |
|
2
|
|
4100490 Knob | €10.53 | |
|
3
|
|
4100280 Handle | €8.74 | |
|
4
|
|
3081390 Screw | €1.04 | |
|
5
|
|
3081390 Screw | €1.04 | |
|
6
|
|
4100222 Casing | €21.15 | |
|
7
|
|
4100500 Knob | €5.88 | |
|
8
|
|
4100533 Protection Grey RAL 9006 | €11.84 | |
|
9
|
|
4100250 Guard | €10.18 | |
|
10
|
|
3081390 Screw | €1.04 | |
|
11
|
|
3086100 Screw | €0.11 | Not available for order |
|
12
|
|
3080580 cable clamp | €1.37 | |
|
13
|
|
4100230 Guard | €5.79 | |
|
14
|
|
3086100 Screw | €0.11 | Not available for order |
|
15
|
|
3441170 Support | €13.18 | |
|
16
|
|
3086080 Screw | €3.08 | |
|
17
|
|
3086090 Screw | €0.11 | Not available for order |
|
18
|
|
4100860 Bracket | €6.20 | |
|
19
|
|
3086080 Screw | €3.08 | |
|
20
|
|
4100870 Bracket | €6.20 | |
|
21
|
|
4100880 Bracket | €6.03 | |
|
22
|
|
4100600 base | €29.81 | |
|
23
|
|
4100630 Holder | €9.67 | |
|
24
|
|
5480500 Screw | €0.23 | |
|
25
|
|
4101000 Holder | €15.14 | |
|
26
|
|
3086120 Screw | €0.11 | Not available for order |
|
27
|
|
4100640 Holder | €7.44 | |
|
28
|
|
3081390 Screw | €1.04 | |
|
29
|
|
4100930 Protection | €5.88 | |
|
30
|
|
3086120 Screw | €0.11 | Not available for order |
|
31
|
|
5460570 Screw | €0.11 | Not available for order |
|
32
|
|
4100610 Guard | €7.24 | |
|
33
|
|
3086100 Screw | €0.11 | Not available for order |
|
34
|
|
4100010 Wheel for Pressure Washers AR Blu Clean Series 3 - 381-391 | €18.73 | |
|
35
|
|
4101010 Stop Ring | €5.88 | |
|
36
|
|
4101020 Washer | €5.88 | |
|
37
|
|
4100510 Protection | €7.64 | |
|
38
|
|
4100620 Guard | €7.24 | |
|
39
|
|
3440710 Tank | €6.25 | |
|
40
|
|
3440720 Filter | €0.35 | |
|
41
|
|
4100950 Hose | €4.94 | |
|
42
|
|
4100960 Junction | €4.94 | |
|
43
|
|
4100970 Hose | €6.56 |
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
1
|
|
4100340 Stirrup | €5.88 | |
|
2
|
|
3081390 Screw | €1.04 | |
|
3
|
|
3081650 fork | €1.65 | |
|
4
|
|
4101250 "L" Fitting for Washer Annovi & Reverberi Blue Clean AR391 | €21.88 | |
|
5
|
|
4382530 OR-seal | €0.00 | Not available for order |
|
6
|
|
4101030 Straight Fitting for Washer Annovi & Reverberi Blue Clean AR391 | €21.88 | |
|
7
|
|
4101520 Fork | €0.40 | |
|
8
|
|
3083390 O-Ring mm 4,8x1,8 for Pressure Washers Black & Decker | €0.46 | |
|
9
|
|
3083380 O-Ring mm 10x2,5 for Pressure Washers Black & Decker | €0.46 | |
|
10
|
|
4101120 High Pressure Hose for Washer Annovi & Reverberi Blue Clean AR391 | €33.37 | |
|
11
|
|
4101040 Disc | €18.72 | |
|
12
|
|
3081390 Screw | €1.04 | |
|
13
|
|
4100330 Stirrup | €5.88 | |
|
14
|
|
4101050 Lever | €8.99 | |
|
15
|
|
5460700 Screw | €0.35 | |
|
16
|
|
4101060 Knob | €2.82 |
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
B
|
|
3081270 Kit Pistons for Pressure Washers Annovi & Reverberi AR142-AR260-AR388 | €17.80 | |
|
A
|
|
3081290 Kit Inlet-Outlet Valves for Pressure Washers Blue Clean AR142/490 | €6.08 | |
|
E
|
|
4384310 TSS valve kit | €15.41 | |
|
C
|
|
4384420 TSS kit | €11.55 | |
|
D
|
|
4720810 Brush kit for motor | €7.43 | |
|
1
|
|
4383680 Pre-assembly of electric pump | €0.11 | Not available for order |
|
2
|
|
4100890 Conveyor | €14.92 | |
|
3
|
|
4101930 Plate | €6.56 | |
|
4
|
|
5480770 Inductance | €6.03 | |
|
5
|
|
3082360 Power Cord for Pressure Washer Black&Decker PW 1400 E | €20.62 |
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
1
|
|
4102740 Cover | €0.11 | Not available for order |
|
2
|
|
3086170 OR gasket | €0.11 | Not available for order |
|
3
|
|
4102750 Rod | €0.12 | Not available for order |
|
4
|
|
3081450 Switch | €9.11 | |
|
5
|
|
4102730 Box | €11.73 | |
|
6
|
|
4100850 Switch | €13.47 | |
|
7
|
|
5340420 Gland | €0.00 | Not available for order |
|
8
|
|
3086110 Screw | €0.11 | Not available for order |
|
9
|
|
3086010 Capacitor kit | €12.75 |
Shipping and delivery information will be available shortly.
We have the original Annovi Reverberi Parts for Pressure Washer AR396, the diagram and parts list and tool repair that help you need to get your tools running like new again.
In the following tables, look for the spare part and its respective code.
| Pressure Cleaner AR 396 - 14815 | ||
| Chassis Pag.1 | ||
| # | Part Num | Description |
| 1 | 4100270 | Handle |
| 2 | 4100490 | Knob Blue RAL 5002 |
| 3 | 4100280 | Handle |
| 4 | 3081390 | Screw |
| 5 | 3081390 | Screw |
| 6 | 4100222 | Hood Blue RAL 5002 |
| 7 | 4100500 | Knob Grey RAL 9006 |
| 8 | 4100533 | Protection Grey RAL 9006 |
| 9 | 4100250 | Protection |
| 10 | 3081390 | Screw |
| 11 | 3086100 | Screw |
| 12 | 3080580 | Cable gland |
| 13 | 4100230 | Protection |
| 14 | 3086100 | Screw |
| 15 | 3441170 | Support |
| 16 | 3086080 | Screw |
| 17 | 3086090 | Screw |
| 18 | 4100860 | Bracket |
| 19 | 3086080 | Screw |
| 20 | 4100870 | Bracket |
| 21 | 4100880 | Bracket |
| 22 | 4100600 | Base |
| 23 | 4100630 | Support |
| 24 | 5480500 | Screw |
| 25 | 4101000 | Support |
| 26 | 3086120 | Screw |
| 27 | 4100640 | Support |
| 28 | 3081390 | Screw |
| 29 | 4100930 | Protection |
| 30 | 3086120 | Screw |
| 31 | 5460570 | Screw |
| 32 | 4100610 | Protection |
| 33 | 3086100 | Screw |
| 34 | 4100010 | Wheel |
| 35 | 4101010 | Washer |
| 36 | 4101020 | Stop |
| 37 | 4100510 | Protection Grey RAL 9006 |
| 38 | 4100620 | Protection |
| 39 | 3440710 | Tank |
| 40 | 3440720 | Filter |
| 41 | 4100950 | Tube |
| 42 | 4100960 | Connection |
| 43 | 4100970 | Tube |
| M | 4100990 | Screw kit |
| Hose Reel Pag.2 | ||
| 1 | 4100340 | Bracket |
| 2 | 3081390 | Screw |
| 3 | 3081650 | Fork |
| 4 | 4101250 | Connector |
| 5 | 4382530 | OR-seal |
| 6 | 4101030 | Connector |
| 7 | 4101520 | Fork |
| 8 | 3083390 | OR-seal |
| 9 | 3083380 | OR-seal |
| 10 | 4101120 | High pressure tube |
| 11 | 4101040 | Disc |
| 12 | 3081390 | Screw |
| 13 | 4100330 | Bracket |
| 14 | 4101050 | Lever |
| 15 | 5460700 | Screw |
| 16 | 4101060 | Knob |
| Elettropompa Pag.3 | ||
| 1 | 4383680 | Pre-assembly of electric pump |
| 2 | 4100890 | Conveyor |
| 3 | 4101930 | Disc |
| 4 | 5480770 | Inductance |
| 5 | 3082360 | Cable |
| A | 3081290 | Valve + seal kit |
| B | 3081270 | Piston + seal kit |
| C | 4384420 | TSS kit |
| D | 4720810 | Brush kit for motor |
| E | 4384310 | TSS valve kit |
| Circuito Elettrico Pag.4 | ||
| 1 | 4102740 | Cover |
| 2 | 3086170 | OR gasket |
| 3 | 4102750 | Rod |
| 4 | 3081450 | Switch |
| 5 | 4102730 | Box |
| 6 | 4100850 | Box kit [Switch] |
| 7 | 5340420 | Cable gland |
| 8 | 3086110 | Screw |
| 9 | 3086010 | Capacitor kit |
| Accessori Pag.5 | ||
| 1 | 4100781 | Gun |
| 2 | 3083700 | OR Seal |
| 3 | 4100771 | Extension (Lance) |
| 4 | 4100730 | Head |
| 5 | 3083370 | OR Seal |
| 6 | 4100800 | Head (Rotopower) |
| 7 | 4101550 | Head (Adjustable jet) |
| 8 | 3085530 | Mini Patio Blue RAL 5002 |
| 9 | 3083380 | OR Seal |
| 10 | 3083390 | OR Seal |
| 11 | 4101940 | High pressure hose |
| 12 | 3082130 | Water connection kit |
