Annovi Reverberi S.p.A.

Annovi & Reverberi Parts for Pressure Washer AR 420 N - 12498

SKU: Annovi Reverberi 420 N - 12498
€29.46
VAT included

Annovi Reverberi Parts for Pressure Washer AR 420 N - 12498

We are Annovi Reverberi original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Pressure Washer AR 420 N - 12498.

Annovi Reverberi 420 N - 12498
Annovi & Reverberi Parts for Pressure Washer AR 420 N - 12498
  • Annovi & Reverberi Parts for Pressure Washer AR 420 N - 12498
  • Annovi & Reverberi Parts for Pressure Washer AR 420 N - 12498
  • Annovi & Reverberi Parts for Pressure Washer AR 420 N - 12498
  • Annovi & Reverberi Parts for Pressure Washer AR 420 N - 12498
  • Annovi & Reverberi Parts for Pressure Washer AR 420 N - 12498
  • Annovi & Reverberi Parts for Pressure Washer AR 420 N - 12498
Annovi Reverberi S.p.A.

Annovi & Reverberi Parts for Pressure Washer AR 420 N - 12498

SKU: Annovi Reverberi 420 N - 12498 Condition: New
€29.46
VAT included

Annovi Reverberi Parts for Pressure Washer AR 420 N - 12498

We are Annovi Reverberi original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Pressure Washer AR 420 N - 12498.

Annovi Reverberi 420 N - 12498
settings 75 spare parts
description 5 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Shipped in about 10/15 working days

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:: AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
75 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 2860048 Blue casing €20.00
3
 photo_cameraImage coming soon 2440075 Wheel €9.56
4
 screw 2100300 screw €4.72
5
 photo_cameraImage coming soon 2860030 Black Bonnet €24.38
6
 photo_cameraImage coming soon 2860060 Bracket €20.10
7
 photo_cameraImage coming soon 50055 SWITCH €13.21
9
 photo_cameraImage coming soon 2860020 Black Bonnet €24.38
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
B
 Piston Kit S.210 for Pressure Washer A&R ARSG HOT 120 2508 Piston Kit S.210 for Pressure Washer A&R ARSG HOT 120 €16.82
A
 Kit Parts Valves for Pressure Washers AR-AR Farmer's Division-Black&Decker 2574 Kit Parts Valves for Pressure Washers AR-AR Farmer's Division-Black&Decker €9.62
D
 Water Seals for Pressure Washers AR Farmer's Event 131-141 2575 Water Seals for Pressure Washers AR Farmer's Event 131-141 €9.62
1
 Water Filter for Pressure Washers AR Blue Clean and Farmer's Division 1340260 Water Filter for Pressure Washers AR Blue Clean and Farmer's Division €1.52
2
 photo_cameraImage coming soon 2101000 Screw €4.80
3
 photo_cameraImage coming soon 2100630 Junction €6.91
5
 AR O-RING for Pressure Washer AR8880 550350 AR O-RING for Pressure Washer AR8880 €0.62
7
 Valve for Pressure Washers AR-AR Farmer's Division Mirage - 120 TSS 2109050 Valve for Pressure Washers AR-AR Farmer's Division Mirage - 120 TSS €2.41
9
 photo_cameraImage coming soon 2100030 Piston Guide €12.30
10
 O-Ring 9,25x1,78 for Pressure Washers AR-AR Farmer's Division-Black&Decker 880840 O-Ring 9,25x1,78 for Pressure Washers AR-AR Farmer's Division-Black&Decker €0.53
11
 Head + O-Ring for Pressure Washers AR Farmer's Event 131-141 2122 Head + O-Ring for Pressure Washers AR Farmer's Event 131-141 €19.40
15
 O-R mm 12x20 for Pressure Washers AR BC 210 - 333 - 353 2200141 O-R mm 12x20 for Pressure Washers AR BC 210 - 333 - 353 €2.41
16
 Holder Seal for Pressure Washer AR BC Serie 1 - 2 2020041 Holder Seal for Pressure Washer AR BC Serie 1 - 2 €1.40
17
 O-Ring 12,42x1,78 for Pressure Washers AR BC 210 - 333 - 353 394280 O-Ring 12,42x1,78 for Pressure Washers AR BC 210 - 333 - 353 €0.53
18
 photo_cameraImage coming soon 2560480 Bushing €1.40
20
 Oil Seal mm 12x2x5/7" for Pressure Washers ARSG 1683500 Oil Seal mm 12x2x5/7" for Pressure Washers ARSG €2.54
22
 Piston Spring for Pressure Washers AR Wash Top 100 T-EXTREME 150 TSS 2020150 Piston Spring for Pressure Washers AR Wash Top 100 T-EXTREME 150 TSS €6.90
23
 photo_cameraImage coming soon 2100130 Piston €9.67
24
 photo_cameraImage coming soon 2020140 Ring €5.00
25
 Pump Bearing for Pressure Washer AR2590 2021570 Pump Bearing for Pressure Washer AR2590 €9.62
26
 photo_cameraImage coming soon 2021960 Fork €4.94
28
 O-Ring 62x2 for Pressure Washer AR BC 2590 850840 O-Ring 62x2 for Pressure Washer AR BC 2590 €2.34
30
 photo_cameraImage coming soon 1461470 junction €3.26
33
 photo_cameraImage coming soon 42359 Pre-assembly pump TSS €88.21
37
 photo_cameraImage coming soon 2101450 Flange €6.77
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 2100280 Headphones €5.13
2
 photo_cameraImage coming soon 1682270 Switch €6.38
3
 AR Capacitor Box for AR 111 2100060 AR Capacitor Box for AR 111 €6.13
da 2 pz: €0.50
4
 Annovi Reverberi O-Ring for Pressure Washer 2590 390201 Annovi Reverberi O-Ring for Pressure Washer 2590 €0.87
6
 photo_cameraImage coming soon 1272600 Cable €25.01
7
 photo_cameraImage coming soon 2020570 screw €1.59
8
 photo_cameraImage coming soon 1262400 washer €1.73
9
 photo_cameraImage coming soon 2100110 Fairlead €5.09
11
 photo_cameraImage coming soon 2102180 Disk €12.09
12
 photo_cameraImage coming soon 2109270 Pre-Assembly Body Pump €26.29
13
 photo_cameraImage coming soon 2100980 Screw €4.53
14
 Seal for Pressure Washers FRESH FOG-HOT 1308-EVENT 131 N TSS 1340350 Seal for Pressure Washers FRESH FOG-HOT 1308-EVENT 131 N TSS €3.57
15
 photo_cameraImage coming soon 2020850 Washer €5.08
16
 photo_cameraImage coming soon 1680250 Fan €7.11
17
 photo_cameraImage coming soon 44190 Engine €160.30
19
 photo_cameraImage coming soon 1680670 Capacitor €20.65
21
 photo_cameraImage coming soon 2440160 Plate €5.13
23
 photo_cameraImage coming soon 2102110 Conveyor €12.81
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 40658 Hose reel assembly €105.11
2
 photo_cameraImage coming soon 2360150 Lever €3.04
3
 screw 2100300 screw €4.72
4
 screw 2100300 screw €4.72
5
 photo_cameraImage coming soon 2440490 Stirrup €11.26
6
 photo_cameraImage coming soon 2440500 Pin €8.89
7
 photo_cameraImage coming soon 2560720 Lives €4.72
8
 photo_cameraImage coming soon 2360230 Disk €12.57
10
 photo_cameraImage coming soon 2620551 High pressure hose €30.05
11
 photo_cameraImage coming soon 2440510 Pin €24.60
12
 photo_cameraImage coming soon 391000 O-Ring €4.73
13
 photo_cameraImage coming soon 2440540 Junction €6.35
15
 photo_cameraImage coming soon 2440480 Stirrup €6.58
16
 photo_cameraImage coming soon 820510 O-ring €5.63
17
 photo_cameraImage coming soon 2360310 Junction €4.23
18
 photo_cameraImage coming soon 2860150 High Pressure Hose €27.75
19
 photo_cameraImage coming soon 2360510 Protection €3.29
20
 photo_cameraImage coming soon 2360460 Disk €10.50
21
 photo_cameraImage coming soon 2440532 Handle €21.88
22
 photo_cameraImage coming soon 2440290 SCREW €4.72
Page 5 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Lance Head for Pressure Washer ARSG EVENT 131 N TSS 40359 Lance Head for Pressure Washer ARSG EVENT 131 N TSS €19.40
2
 O-Ring 8X2 for Pressure Washers AR DRIVE 100 TSS-Top Wash S 120 T-WIND 1680220 O-Ring 8X2 for Pressure Washers AR DRIVE 100 TSS-Top Wash S 120 T-WIND €0.45
3
 Rotopower Head for Pressure Washer Black&Decker PW 1300-1500 40344 Rotopower Head for Pressure Washer Black&Decker PW 1300-1500 €28.07 Not available for order
4
 Hobby Line Lance with Spring for Pressure Washers AR Blue Clean 410 40667 Hobby Line Lance with Spring for Pressure Washers AR Blue Clean 410 €16.78
5
 photo_cameraImage coming soon 40352 Tank €18.87
6
 photo_cameraImage coming soon 40350 Gun->40925+3082750+3780492 €36.26
7
 Fixed Brush for Pressure Washers Black & Decker PW 1300-1400-1500 40417 Fixed Brush for Pressure Washers Black & Decker PW 1300-1400-1500 €12.42
8
 O-Ring 9,25x1,78 for Pressure Washers AR-AR Farmer's Division-Black&Decker 880840 O-Ring 9,25x1,78 for Pressure Washers AR-AR Farmer's Division-Black&Decker €0.53

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Annovi Reverberi Parts for Pressure Washer AR 420 N - 12498

We are Annovi Reverberi original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Pressure Washer AR 420 N - 12498.

In the following tables, look for the spare part and its respective code.
Annovi Reverberi 420 N - 12498

Pressure Washer AR 420 N - 12498 - CASING Pag.1
# Part Num. Description
1 2860048 Blue casing
3 2440075 Wheel
4 2100300 Screw
5 2860030 Black casing
6 2860060 Bracket
7 50055 Clamp
9 2860020 Black casing
Pressure Washer AR 420 N - 12498 - PUMP Pag.2
1 1340260 Filter
2 2101000 Screw
3 2100630 Fitting
5 550350 O-ring
7 2109050 Valve
8 850850 Screw
9 2100030 Piston guide
10 880840 O-ring
11 2122 O-ring + head
13 1260760 Screw
14 2256 Fitting assembly
15 2200141 Water seal
16 2020041 Ring
17 394280 O-ring
18 2560480 Bushing
20 1683500 Oil seal
22 2020150 Spring
23 2100130 Piston
24 2020140 Ring
25 2021570 Bearing
26 2021960 Fork
28 850840 O-ring
30 1461470 Fitting
33 342359 TSS pump assembly
37 2101450 Flange
A 2574 Valve kit
B 2508 Piston kit
D 2575 Seal kit
Pressure Washer AR 420 N - 12498 - MOTOR Pag.3
1 2100280 Guard
2 1682270 Switch
3 2100060 Capacitor Box
4 390201 O-ring
6 1272600 Cable
7 2020570 Screw
8 1262400 Washer
9 2100110 Gland
11 2102180 Wobble plate
12 2109270 Pump body assembly
13 2100980 Screw
14 1340350 Seal
15 2020850 Washer
16 1680250 Fan
17 44190 Motor
19 1680670 Capacitor
21 2440160 Plate
22 2029721 TSS box assembly
23 2102110 Conveyor
Pressure Washer AR 420 N - 12498 - RLW 8M Pag.4
1 40658 Hose reel assembly
2 2360150 Lever
3 2100300 Screw
4 2100300 Screw
5 2440490 Bracket
6 2440500 Hub pin
7 2560720 Screw
8 2360230 Plate
9 380420 Ring
10 2620551 High pressure hose
11 2440510 Hub pin
12 391000 O-ring
13 2440540 Fitting
14 2360320 Ring
15 2440480 Bracket
16 820510 O-ring
17 2360310 Fitting
18 2860150 High pressure hose
19 2360510 Guard
20 2360460 Plate
21 2440532 Handle
22 2440290 Screw
Pressure Washer AR 420 N - 12498 - STANDARD ACCESSORIES Pag.5
1 40359 Lance Head
2 1680220 Guarnizione OR
3 40344 Rotopower head
4 40667 Lance
5 40352 Tank
6 40350 Gun->40925+3082750+3780492
7 40417 Fixed brush
8 880840 O-Ring
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Annovi Reverberi 420 N - 12498
11 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:
AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS

Specific References

New

Download

Drawing AR 420 N - 12498

Drawing AR 420 N - 12498

Download (1.4MB)

You might also like

O-R mm 12x20 for Pressure Washers AR BC 210 - 333 - 353
Annovi Reverberi S.p.A. SKU: 2200141
O-R mm 12x20 for Pressure Washers AR BC 210 - 333 - 353
O-R mm 12x20 for Pressure Washers AR BC 210 - 333 - 353 Genuine Parts for Annovi & Reverberi, O-Ring mm 12x20 for Pressure Washer AR BC 210 - 333 - 353 - Mirage - 120 TSS - HOT 120 - PW 1700 WB - MPX 140 HL. Part for...
on 7/10 Business Days Approx. €2.41
Details
Pump Bearing for Pressure Washer AR2590
Annovi Reverberi S.p.A. SKU: 2021570
Pump Bearing for Pressure Washer AR2590
Pump Bearing for Pressure Washer AR2590 Genuine part Annovi & Reverberi, Pump Bearing for Pressure Washer Annovi & Reverberi AR BC - Model 50 Hz - Series 25 - 2590 - 24424. Parts For the Following Products: - AR BC - 50 Hz...
Last items in stock €9.62
Details
Capacitor 25 μF 425V for Pressure Washer AR Blu Clean 410
Annovi Reverberi S.p.A. SKU: 1682640
Capacitor 25 μF 425V for Pressure Washer AR Blu Clean 410
Capacitor 25 μF 425V for Pressure Washer AR Blu Clean 410 Genuine part Annovi & Reverberi, 25 μF 425V - 10000h/cl.B - 475V 3000 h/cl.C, Capacitor for Pressure Washers AR BC Series 4 - 410 - Series 15 - 1550 - Series 25 - 2550....
AVAILABLE €15.03
Details
Lance Head for Pressure Washer ARSG EVENT 131 N TSS
Annovi Reverberi S.p.A. SKU: 40359
Lance Head for Pressure Washer ARSG EVENT 131 N TSS
Lance Head for Pressure Washer ARSG EVENT 131 N TSS Genuine part Annovi & Reverberi, Lance Head for Pressure Washers ARSG EVENT 131 N TSS - 141 N TSS RLW - AR 410 - AR 420-N - B&D PW 1800 W. Part for the following products: -...
Last items in stock €19.40
Details
AR O RING for Pressure Washer AR8880
Annovi Reverberi S.p.A. SKU: 550350
AR O-RING for Pressure Washer AR8880
AR O-RING for Pressure Washer AR8880 Genuine spare part Annovi Reverberi, O-RING for Pressure Washers AR8880 - AR8840 - AR8860 - AR1120. Part for the following products: -  Pressure Washer Annovi Reverberi 8880 - 22915 - ...
AVAILABLE €0.62
Details
Annovi Reverberi O-R for Pressure Washer 2590
Annovi Reverberi S.p.A. SKU: 390201
Annovi Reverberi O-Ring for Pressure Washer 2590
Annovi Reverberi O-Ring for Pressure Washer 2590 Genuine spare part Annovi Reverberi, O-R 39,34x2,62 for Pressure Washers AR2590 - AR111. Part for the following products: -  Pressure Washer Annovi Reverberi 2590 - 24424 - ...
AVAILABLE €0.87
Details
AR Capacitor Box for AR 111
Annovi Reverberi S.p.A. SKU: 2100060
AR Capacitor Box for AR 111
Annovi Reverberi Capacitor Box for Pressure Washer AR 111 Genuine spare part Annovi Reverberi, Capacitor Box for Pressure Washer AR 111. Part for the following products: -  Pressure Washer ARSG EVENT 131 N TSS - 12487...
AVAILABLE €6.13
Details
Comments (0)
