Annovi Reverberi Parts for Pressure Washer AR 4.1 WI-TOUCH

SKU: 15180
€0.11
VAT included

Annovi Reverberi Parts for Pressure Washer AR 4.1 WI-TOUCH

We have the original Annovi Reverberi Parts for Pressure Washer AR 4.1 WI-TOUCH, the diagram, parts list and tool repair that help you need to get your tools running like new again

Fix Your Pressure Washer Annovi Reverberi AR 4.1 WI-TOUCH - 15180. All Spares are original and can be supplied at Low prices. Our Spares are Guarantee

AR 4.1 WI-TOUCH - 15180

Annovi & Reverberi Parts for Pressure Washer AR 4.1 WI-TOUCH
  • New
  • Out-of-Stock
  • Annovi & Reverberi Parts for Pressure Washer AR 4.1 WI-TOUCH
  • AR 15180 Drawing
  • AR 15180 Drawing - 1
  • AR 15180 Drawing - 2
  • AR 15180 Drawing - 3
  • AR 15180 Drawing - 4
  • AR 15180 Drawing - 5
  • AR 15180 Drawing - 6
Annovi Reverberi S.p.A.

Annovi Reverberi Parts for Pressure Washer AR 4.1 WI-TOUCH

SKU: 15180 Condition: New
€0.11
VAT included

Annovi Reverberi Parts for Pressure Washer AR 4.1 WI-TOUCH

We have the original Annovi Reverberi Parts for Pressure Washer AR 4.1 WI-TOUCH, the diagram, parts list and tool repair that help you need to get your tools running like new again

Fix Your Pressure Washer Annovi Reverberi AR 4.1 WI-TOUCH - 15180. All Spares are original and can be supplied at Low prices. Our Spares are Guarantee

AR 4.1 WI-TOUCH - 15180

settings 91 Spare parts
description 7 exploded views
picture_as_pdf Download Exploded PDF
Quantity
Out-of-Stock

SHIPPING IN: Usually Ships in 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR: AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
Machine Type: Pressure Washer
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal PayPal Pay in 3 Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
91 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4581230 Guard €0.00 Not available for order
2
 photo_cameraImage coming soon 4581220 Guard €0.00 Not available for order
3
 photo_cameraImage coming soon 4582020 Screw €0.34
4
 photo_cameraImage coming soon 4581200 Guard €1.50
5
 photo_cameraImage coming soon 4581190 Base €2.21
6
 photo_cameraImage coming soon 4581210 Lever €1.20
7
 photo_cameraImage coming soon 5480500 Screw €0.23
8
 photo_cameraImage coming soon 4580500 Casing €23.34
9
 Annovi Accessory Holder for AR589 4580590 Annovi Accessory Holder for AR589 €6.56
10
 photo_cameraImage coming soon 5480500 Screw €0.23
11
 photo_cameraImage coming soon 4381640 Rubber foot €1.65
12
 photo_cameraImage coming soon 3080580 cable clamp €1.37
Page 2 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4820410 Cover €1.04
2
 photo_cameraImage coming soon 4580540 Bracket €7.65
3
 photo_cameraImage coming soon 4101680 Plate €11.18
4
 photo_cameraImage coming soon 4102120 Support €4.12
5
 photo_cameraImage coming soon 50943 Screw €1.85
6
 photo_cameraImage coming soon 4580550 Bracket €7.65
7
 photo_cameraImage coming soon 50943 Screw €1.85
8
 photo_cameraImage coming soon 4101750 Hub pin €2.54
9
 photo_cameraImage coming soon 5460700 Screw €0.35
10
 photo_cameraImage coming soon 4101660 Lever €3.68
11
 Knob 4101673 Knob €2.54
12
 photo_cameraImage coming soon 4581980 Screw €0.23
Page 3 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4580610 Knob €4.89
2
 photo_cameraImage coming soon 4581490 Accessories carrier €2.62
3
 photo_cameraImage coming soon 4581480 Accessories carrier €2.62
4
 photo_cameraImage coming soon 50943 Screw €1.85
5
 photo_cameraImage coming soon 4580600 Handle €10.69
6
 photo_cameraImage coming soon 4581990 Screw €0.51
7
 photo_cameraImage coming soon 50943 Screw €1.85
8
 photo_cameraImage coming soon 4580770 Pipe €17.80
9
 photo_cameraImage coming soon 3081390 Screw €1.04
10
 photo_cameraImage coming soon 4821080 Guide €4.34
11
 photo_cameraImage coming soon 50943 Screw €1.85
12
 photo_cameraImage coming soon 4821110 Hook €1.11
13
 photo_cameraImage coming soon 4821020 Spring €0.35
14
 photo_cameraImage coming soon 4220271 Lever €0.45
15
 photo_cameraImage coming soon 4580560 base €24.63
16
 photo_cameraImage coming soon 4580620 Accessories carrier €9.16
17
 photo_cameraImage coming soon 2180330 Rubber €3.86
18
 photo_cameraImage coming soon 50943 Screw €1.85
19
 photo_cameraImage coming soon 4580760 Accessories carrier €7.81
20
 photo_cameraImage coming soon 50943 Screw €1.85
21
 photo_cameraImage coming soon 4384880 Washer €0.33
22
 photo_cameraImage coming soon 4582010 Screw €0.51
23
 photo_cameraImage coming soon 4100181 Lever €0.77
24
 photo_cameraImage coming soon 4220280 Accessories carrier €1.31
25
 photo_cameraImage coming soon 4240590 SCREW €0.77
26
 photo_cameraImage coming soon 4580780 Guard €1.63
27
 photo_cameraImage coming soon 50943 Screw €1.85
28
 photo_cameraImage coming soon 4580570 Cover €1.31
29
 photo_cameraImage coming soon 4580880 Axle €15.03
30
 photo_cameraImage coming soon 4381100 Wheel €23.34
31
 photo_cameraImage coming soon 4980170 Washer €0.81
32
 photo_cameraImage coming soon 4980160 Pin €1.04
33
 photo_cameraImage coming soon 4381631 Guard €10.64
Page 4 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4580640 Conveyor €8.63
2
 Gland 4580660 Gland €2.12
3
 photo_cameraImage coming soon 5480500 Screw €0.23
4
 Suction Kit for Pressure Washer ARBC 4.0 Twin Flow 4580900 Suction Kit for Pressure Washer ARBC 4.0 Twin Flow €11.50
5
 photo_cameraImage coming soon 4380180 Protection €3.07
6
 photo_cameraImage coming soon 4580910 Delivery kit €20.62
7
 photo_cameraImage coming soon 4580650 Conveyor €8.20
8
 photo_cameraImage coming soon 4580870 Rubber foot €5.76
9
 photo_cameraImage coming soon 4580840 Guard €5.04
10
 photo_cameraImage coming soon 5480500 Screw €0.23
Page 5 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
A
 Valves + Oil Seal Kit for Pressure Washers B&D BXPW 1300 E-1400 E 3480140 Valves + Oil Seal Kit for Pressure Washers B&D BXPW 1300 E-1400 E €6.51
B
 Pistons + Oil Seal Kit for Pressure Washers B&D BXPW 1300 E-1400 E 3480150 Pistons + Oil Seal Kit for Pressure Washers B&D BXPW 1300 E-1400 E €21.86
D2
 photo_cameraImage coming soon 3480570 Engine brush kit €7.44
C
 photo_cameraImage coming soon 4384500 TSS box kit Da XXXXX-38250001 €14.26
E2
 photo_cameraImage coming soon 4580950 TSS plug kit €12.20
E1
 photo_cameraImage coming soon 4581860 TSS kit €10.25
C
 photo_cameraImage coming soon 4581870 TSS kit €16.76
D1
 photo_cameraImage coming soon 5000800 Engine brush kit €8.36
E1
 photo_cameraImage coming soon 5480560 TSS valve kit €11.68
1
 AR Blue Clean 4.0 Twin Flow Electric Pump Assy 4580970 AR Blue Clean 4.0 Twin Flow Electric Pump Assy €143.23
1
 photo_cameraImage coming soon 5480540 Electric pump assembly Da XXXXX-38250001 €121.52
2
 photo_cameraImage coming soon 4580960 Electric pump assembly €128.04
Page 6 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 6
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 4380840 Cover €3.75
2
 photo_cameraImage coming soon 2180670 O RING €1.99
3
 AR Blue Clean 4.0 Twin Flow Switch 4580050 AR Blue Clean 4.0 Twin Flow Switch €19.15
4
 photo_cameraImage coming soon 3086000 Capacitor kit €14.98
5
 Gland 4580660 Gland €2.12
6
 photo_cameraImage coming soon 4580681 Base €0.00 Not available for order
7
 photo_cameraImage coming soon 2021480 Grommet €2.54
8
 photo_cameraImage coming soon 50943 Screw €1.85
9
 photo_cameraImage coming soon 5140060 Box €0.00 Not available for order
10
 photo_cameraImage coming soon 5140080 Board €31.79
11
 photo_cameraImage coming soon 5140260 Gasket €0.00 Not available for order
12
 photo_cameraImage coming soon 5140070 Cover €0.00 Not available for order
13
 photo_cameraImage coming soon 5480800 EMC Interference filter €6.03
14
 photo_cameraImage coming soon 4580930 Cable €24.63
Page 7 zoom_in View exploded local_shipping Usually Ships in 10 BUSYNESS DAYS
Esploso pagina 7
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 5140270 Gun €72.70
2
 O-Ring for Pressure Washers Black & Decker 3083700 O-Ring for Pressure Washers Black & Decker €0.40
3
 photo_cameraImage coming soon 5140280 Extension (Lance) €17.63
4
 photo_cameraImage coming soon 4580980 Tank €16.38
5
 O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker 3083370 O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker €0.40
6
 photo_cameraImage coming soon 4581010 Lanceheads-holder €13.68
7
 Suction Kit for Pressure Washer ARBC 4.0 Twin Flow 4580900 Suction Kit for Pressure Washer ARBC 4.0 Twin Flow €11.50
8
 Lance head 4581000 Lance head €12.53
9
 O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker 3083400 O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker €0.40
10
 High pressure hose 4581030 High pressure hose €38.31
500
 Head 46342 Head €36.69

Shipping and delivery information will be available shortly.

Annovi Reverberi Parts for Pressure Washer AR 4.1 WI-TOUCH

We have the original Annovi Reverberi Parts for Pressure Washer AR 4.1 WI-TOUCH, the diagram, parts list and tool repair that help you need to get your tools running like new again

In the following tables, look for the spare part and its respective code.
AR 4.1 WI-TOUCH

Pressure Washer  AR 4.1 WI-TOUCH - 15180
Casing Pag.1
# Part Num. Description
1 4581230 Guard
2 4581220 Guard
3 4582020 Screw
4 4581200 Guard
5 4581190 Base
6 4581210 Lever
7 5480500 Screw
8 4580500 Casing
9 4580590 Accessories carrier
10 5480500 Screw
11 4381640 Rubber foot
12 3080580 Cable gland
Hose reel Pag.2
# Part Num. Description
1 4820410 Cover
2 4580540 Bracket
3 4101680 Plate
4 4102120 Support
5 50943 Screw
6 4580550 Bracket
7 50943 Screw
8 4101750 Hub pin
9 5460700 Screw
10 4101660 Lever
11 4101673 Knob
12 4581980 Screw
Carriage Pag.3
# Part Num. Description
1 4580610 Knob
2 4581490 Accessories carrier
3 4581480 Accessories carrier
4 50943 Screw
5 4580600 Handle
6 4581990 Screw
7 50943 Screw
8 4580770 Pipe
9 3081390 Screw
10 4821080 Guide
11 50943 Screw
12 4821110 Hook
13 4821020 Spring
14 4220271 Lever
15 4580560 Base
16 4580620 Accessories carrier
17 2180330 Rubber foot
18 50943 Screw
19 4580760 Accessories carrier
20 50943 Screw
21 4384880 Washer
22 4582010 Screw
23 4100181 Lever
24 4220280 Accessories carrier
25 4240590 Screw
26 4580780 Guard
27 50943 Screw
28 4580570 Cover
29 4580880 Axle
30 4381100 Wheel
31 4980170 Washer
32 4980160 Pin
33 4381631 Guard
Guard Pag.4
# Part Num. Description
1 4580640 Conveyor
2 4580660 Gland
3 5480500 Screw
4 4580900 Suction kit
5 4380180 Guard
6 4580910 Delivery kit
7 4580650 Conveyor
8 4580870 Rubber foot
9 4580840 Guard
10 5480500 Screw
Electric pump Pag.5
# Part Num. Description
1 4580970 Electric pump assembly
1 5480540 Electric pump assembly
2 4580960 Electric pump assembly
A 3480140 Valves + seals kit
B 3480150 Piston + seals kit
C 4581870 TSS box kit
C 4384500 TSS kit
D1 5000800 Brush kit for motor
D2 3480570 Brush kit for motor
E1 4581860 Valve kit TSS
E1 5480560 Valve kit TSS
E2 4580950 TSS plug kit
Electric circuit Pag.6
# Part Num. Description
1 4380840 Cover
2 2180670 O-ring
3 4580050 Switch
4 3086000 Capacitor kit
5 4580660 Gland
6 4580681 Base
7 2021480 Gland
8 50943 Screw
9 5140060 Box
10 5140080 Board
11 5140260 Gasket
12 5140070 Cover
13 5480800 EMC Interference filter
14 4580930 Cable
Standard accessories Pag.7
# Part Num. Description
1 5140270 Gun
2 3083700 O-ring
3 5140280 Extension (Lance)
4 4580980 High pressure foam lance
5 3083370 O-ring
6 4581010 Lanceheads-holder
7 4580900 Suction kit
8 4581000 Lance head (Adjustable jet)
9 3083400 O-ring
10 4581030 High pressure hose
500 46342 Head
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
15180

Data sheet

SHIPPING IN
Usually Ships in 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR
AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
Machine Type
Pressure Washer

Specific References

New

Download

AR 15180 Drawing

AR 15180 Drawing

Download (2.32MB)

You might also like

O-Ring for Pressure Washers Black & Decker
Annovi Reverberi S.p.A. SKU: 3083700
O-Ring for Pressure Washers Black & Decker
O-Ring for Pressure Washers Black & Decker Original Spare Parts Annovi & Rverberi, O-Ring For the Following Products: - Black & Decker - BXPW 1300 E - 14107 - Black & Decker - BXPW 1300 PE - 14117 - Black & Decker...
AVAILABLE €0.40
Details
Kit Motor Brushes for Pressure Washers B&D PW 1300S - 1400S
Annovi Reverberi S.p.A. SKU: 3480170
Kit Motor Brushes for Pressure Washers B&D PW 1300S - 1400S
Kit Motor Brushes for Pressure Washers B&D PW 1300S - 1400S Genuine part Black & Decker, Kit Motor Brushes for Pressure Washers B&D PW 1300 S-TD-TDW - 1400 S-TDK - TDK PLUS - PW 1500 S - S PLUS - BXPW 1300-1400-1500 E...
AVAILABLE €8.00
Details
O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker
Annovi Reverberi S.p.A. SKU: 3083400
O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker
O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker Original part Annovi & Rverberi, HP Hose O-Ring mm 5.1x1.6 80 SHORE for Pressure Washers Black & Decker - Michelin - AR BC - ARSG - Stanley. Part for the...
Usually Ships in: 7/10 Business Days Approx. €0.40
Details
O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker
Annovi Reverberi S.p.A. SKU: 3083370
O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker
O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker Original part Annovi & Rverberi, HP Hose O-Ring mm 6x2 80 SHORE C for Pressure Washers Black & Decker - Michelin - AR BC - ARSG - Stanley. Part for the...
AVAILABLE €0.40
Details
Suction Kit for Pressure Washer ARBC 4.0 Twin Flow
Annovi Reverberi S.p.A. SKU: 4580900
Suction Kit for Pressure Washer ARBC 4.0 Twin Flow
Suction Kit for Pressure Washer ARBC 4.0 Twin Flow Original Part Annovi Reverberi, Suction Kit for Pressure Washers Twin-Flow > 4.0 ARBC - 14792 - Stanley > SXPW25DTS-E - 14796 . Replacement for the Following Products: -  AR...
Usually Ships in: 7/10 Business Days Approx. €11.50
Details
TSS-Kit for Pressure Washer AR Blue Clean DTS 4.0 - 5.0
Annovi Reverberi S.p.A. SKU: 4580940
TSS-Kit for Pressure Washer AR Blue Clean DTS 4.0 - 5.0
TSS-Kit for Pressure Washer AR Blue Clean DTS 4.0 - 5.0 Genuine part Annovi Reverberi, TSS-Kit for Pressure Washers AR Blue Clean Series DTS 4.0 - 5.0. Part for the following products: -  Cleaning - AR Blue Clean - HOME&GARDEN -...
Usually Ships in: 10 Business Days Approx. €19.49
Details
AR Blue Clean 4.0 Twin Flow Switch
Annovi Reverberi S.p.A. SKU: 4580050
AR Blue Clean 4.0 Twin Flow Switch
AR Blue Clean 4.0 Twin Flow Switch Genuine part Annovi Reverberi, 3-Way Square Rotary Switch for Twin Flow Pressure Washers. Parts For the Following Products: - Annovi Reverberi 4.0 Twin Flow 14792 - Stanley SXPW25DTS-E 14796 -...
Usually Ships in: 10/15 Business Days Approx. €19.15
Details
AR Blue Clean 4.0 Twin Flow Electric Pump Ass'y
Annovi Reverberi S.p.A. SKU: 4580970
AR Blue Clean 4.0 Twin Flow Electric Pump Assy
AR Blue Clean 4.0 Twin Flow Electric Pump Ass'y Genuine part Annovi Reverberi, Electric Pump Assembly for Twin Flow Pressure Washers. Parts For the Following Products: - Annovi Reverberi 4.0 Twin Flow 14792 - Stanley SXPW25DTS-E...
Usually Ships in: 10/15 Business Days Approx. €143.23
Details
AR Rev. 4.0 Rotopower head
Annovi Reverberi S.p.A. SKU: 4580990
AR Rev. 4.0 Rotopower head
AR Rev. 4.0 Twin Flow Rotopower Head Original spare part by Annovi & Reverberi, Rotopower Head for pressure washers Rev. 4.0 Twin Flow – Stanley SXPW25DTS-E – Twin-Flow 4.M – Annovi Rev. DTS4K. Parts for the following products: -...
Usually Ships in 10 Business Days Approx. €15.21
Details
Annovi Accessory Holder for AR589
Annovi Reverberi S.p.A. SKU: 4580590
Annovi Accessory Holder for AR589
Annovi Accessory Holder for Pressure Washer AR589 Genuine part Annovi Reverberi, Accessory Holder for Pressure Washer AR589 - AR 4.0 Twin Flow. Part for the Following Products: -  Pressure Washer Pressure Washer Annovi Reverberi...
Usually Ships in: 7/10 Business Days Approx. €6.56
Details
Comments (0)
No customer reviews for the moment.
