Annovi Reverberi S.p.A.

AR Farmer's Division Parts for Pressure Washer WIND 120 TSS

SKU: ARSG WIND 120 TSS - 12314
€23.25
VAT included

AR Farmer's Division Parts for Pressure Washer WIND 120 TSS

We are AR Farmer's Division original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance or repair issues for Pressure Washer WIND 120 TSS - 12314.
AR Farmer's Division Parts for Pressure WIND
  • AR Farmer's Division Parts for Pressure WIND
  • AR Farmer's Division Parts for Pressure WIND
Annovi Reverberi S.p.A.

AR Farmer's Division Parts for Pressure Washer WIND 120 TSS

SKU: ARSG WIND 120 TSS - 12314 Condition: New
€23.25
VAT included

AR Farmer's Division Parts for Pressure Washer WIND 120 TSS

We are AR Farmer's Division original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance or repair issues for Pressure Washer WIND 120 TSS - 12314.
settings 64 spare parts
description 4 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10 Business Days Approx

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:: AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
64 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 2180740 Ferrule €2.09
2
 photo_cameraImage coming soon 2440040 Yellow Casing €21.21
3
 photo_cameraImage coming soon 2440260 Handle €10.11
4
 photo_cameraImage coming soon 2440070 Wheel €7.86
5
 screw 2100300 screw €4.72
6
 photo_cameraImage coming soon 2440020 Black Casing €24.61
7
 photo_cameraImage coming soon 2440120 Stirrup €7.89
8
 photo_cameraImage coming soon 2440010 Black Casing €24.61
9
 photo_cameraImage coming soon 2440170 Holders Accessories €17.14
10
 photo_cameraImage coming soon 2440150 Holder €7.75
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
B
 Piston Kit S.210 for Pressure Washer A&R ARSG HOT 120 2508 Piston Kit S.210 for Pressure Washer A&R ARSG HOT 120 €16.82
D
 Water Seals for Pressure Washers AR Farmer's Event 131-141 2575 Water Seals for Pressure Washers AR Farmer's Event 131-141 €9.62
A
 Kit Valves S.202/232 for Pressure Washers AR-AR Farmer's Division 2577 Kit Valves S.202/232 for Pressure Washers AR-AR Farmer's Division €14.62
1
 Water Filter for Pressure Washers AR Blue Clean and Farmer's Division 1340260 Water Filter for Pressure Washers AR Blue Clean and Farmer's Division €1.52
2
 photo_cameraImage coming soon 2101000 Screw €4.80
3
 photo_cameraImage coming soon 2100630 Junction €6.91
4
 photo_cameraImage coming soon 390180 O-ring €1.58
5
 AR O-RING for Pressure Washer AR8880 550350 AR O-RING for Pressure Washer AR8880 €0.62
6
 photo_cameraImage coming soon 2440200 Extension €7.03
7
 Valve for Pressure Washers AR-AR Farmer's Division Mirage - 120 TSS 2109050 Valve for Pressure Washers AR-AR Farmer's Division Mirage - 120 TSS €2.41
9
 photo_cameraImage coming soon 2100030 Piston Guide €12.30
10
 O-Ring 9,25x1,78 for Pressure Washers AR-AR Farmer's Division-Black&Decker 880840 O-Ring 9,25x1,78 for Pressure Washers AR-AR Farmer's Division-Black&Decker €0.53
11
 Head + O-Ring for Pressure Washers AR Farmer's Event 131-141 2122 Head + O-Ring for Pressure Washers AR Farmer's Event 131-141 €19.40
15
 Water Seal for Pressure Washers ARSG FRESH FOG 2200140 Water Seal for Pressure Washers ARSG FRESH FOG €1.37
16
 AR Seal Support Ring D.12 2020040 AR Seal Support Ring D.12 €5.14
17
 O-Ring 12,42x1,78 for Pressure Washers AR BC 210 - 333 - 353 394280 O-Ring 12,42x1,78 for Pressure Washers AR BC 210 - 333 - 353 €0.53
18
 photo_cameraImage coming soon 2560480 Bushing €1.40
20
 Oil Seal mm 12x2x5/7" for Pressure Washers ARSG 1683500 Oil Seal mm 12x2x5/7" for Pressure Washers ARSG €2.54
22
 Piston Spring for Pressure Washers AR Wash Top 100 T-EXTREME 150 TSS 2020150 Piston Spring for Pressure Washers AR Wash Top 100 T-EXTREME 150 TSS €6.90
23
 photo_cameraImage coming soon 2100130 Piston €9.67
24
 photo_cameraImage coming soon 2020140 Ring €5.00
25
 Pump Bearing for Pressure Washer AR2590 2021570 Pump Bearing for Pressure Washer AR2590 €9.62
26
 photo_cameraImage coming soon 2021960 Fork €4.94
28
 O-Ring 62x2 for Pressure Washer AR BC 2590 850840 O-Ring 62x2 for Pressure Washer AR BC 2590 €2.34
30
 photo_cameraImage coming soon 1461470 junction €3.26
33
 TSS Pump Ass'y for Pressure Washer Black&Decker PW 1800 N WR 42089 TSS Pump Ass'y for Pressure Washer Black&Decker PW 1800 N WR €140.56
35
 photo_cameraImage coming soon 2440440 Extension €21.34
37
 photo_cameraImage coming soon 2101450 Flange €6.77
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
B
 Piston Kit S.210 for Pressure Washer A&R ARSG HOT 120 2508 Piston Kit S.210 for Pressure Washer A&R ARSG HOT 120 €16.82
D
 Water Seals for Pressure Washers AR Farmer's Event 131-141 2575 Water Seals for Pressure Washers AR Farmer's Event 131-141 €9.62
A
 Kit Valves S.202/232 for Pressure Washers AR-AR Farmer's Division 2577 Kit Valves S.202/232 for Pressure Washers AR-AR Farmer's Division €14.62
1
 photo_cameraImage coming soon 2100280 Headphones €5.13
2
 photo_cameraImage coming soon 1682270 Switch €6.38
3
 AR Capacitor Box for AR 111 2100060 AR Capacitor Box for AR 111 €6.13
da 2 pz: €0.50
4
 Annovi Reverberi O-Ring for Pressure Washer 2590 390201 Annovi Reverberi O-Ring for Pressure Washer 2590 €0.87
6
 photo_cameraImage coming soon 2022150 Cable €10.07
7
 photo_cameraImage coming soon 2020570 screw €1.59
8
 photo_cameraImage coming soon 1262400 washer €1.73
9
 photo_cameraImage coming soon 2100110 Fairlead €5.09
11
 photo_cameraImage coming soon 2101710 Disk €6.52
12
 photo_cameraImage coming soon 2109270 Pre-Assembly Body Pump €26.29
13
 photo_cameraImage coming soon 2100980 Screw €4.53
14
 Seal for Pressure Washers FRESH FOG-HOT 1308-EVENT 131 N TSS 1340350 Seal for Pressure Washers FRESH FOG-HOT 1308-EVENT 131 N TSS €3.57
15
 photo_cameraImage coming soon 2020850 Washer €5.08
16
 photo_cameraImage coming soon 1680250 Fan €7.11
17
 photo_cameraImage coming soon 4866 Engine €99.39
19
 Capacitor 16 μF for Pressure Washer ARSG Wind - 120 TSS 2200290 Capacitor 16 μF for Pressure Washer ARSG Wind - 120 TSS €17.48
21
 photo_cameraImage coming soon 2440160 Plate €5.13
23
 photo_cameraImage coming soon 2100070 Conveyor €1.71
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 40350 Gun->40925+3082750+3780492 €36.26
2
 O-Ring 8X2 for Pressure Washers AR DRIVE 100 TSS-Top Wash S 120 T-WIND 1680220 O-Ring 8X2 for Pressure Washers AR DRIVE 100 TSS-Top Wash S 120 T-WIND €0.45
3
 Hobby Line Lance with Spring for Pressure Washers AR Blue Clean 410 40667 Hobby Line Lance with Spring for Pressure Washers AR Blue Clean 410 €16.78
4
 photo_cameraImage coming soon 40371 HAEAD €12.75
5
 photo_cameraImage coming soon 40352 Tank €18.87
6
 O-Ring mm 7,66x1,78 for Pressure Washers Black & Decker 600180 O-Ring mm 7,66x1,78 for Pressure Washers Black & Decker €0.38
8
 OR 10x2 for Pressure Washer Annovi & Reverberi AR-ARSG HOT 2000570 OR 10x2 for Pressure Washer Annovi & Reverberi AR-ARSG HOT €1.78
8
 O-Ring 8x2 for Pressure Washers AR-AR Farmer's Division-Black&Decker 2000770 O-Ring 8x2 for Pressure Washers AR-AR Farmer's Division-Black&Decker €0.53

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

AR Farmer's Division Parts for Pressure Washer WIND 120 TSS

We are AR Farmer's Division original spare parts Worldwide Dealers

 at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance or repair issues for Pressure Washer WIND 120 TSS - 12314.

In the following tables, look for the spare part and its respective code.
ARSG WIND 120 TSS - 12314

>ARSG Pressure Washer WIND 120 TSS - 12314
Casing 120 TSS - 12314 Pag.1
# part Num. Description
1 2180740 Ring Nut
2 2440040 Yellow Casing
3 2440260 Handle
4 2440070 Wheel
5 2100300 Screw
6 2440020 Black Casing
7 2440120 Stirrup
8 2440010 Black Casing
9 2440170 Accessory Cases
10 2440150 Support
Pump 120 TSS - 12314 Pag.2
1 1340260 Filter
2 2101000 Screw
3 2100630 Junction
4 390180 O-Ring
5 550350 O-Ring
6 2440200 Extension
7 2109050 Valve
8 850850 Screw
9 2100030 Piston Guide
10 880840 O-Ring
11 2122 Head + OR
13 1260760 Screw
14 2256 Preassembly Fitting
15 2200140 Water Seal
16 2020040 Ring
17 394280 O-Ring
18 2560480 Bush
20 1683500 Oil Seal
22 2020150 Spring
23 2100130 Piston
24 2020140 Ring
25 2021570 Bearing
26 2021960 Fork
28 850840 O-Ring
30 1461470 Junction
33 42089 Preassembly Pump TSS
35 2440440 Extension
37 2101450 Flange
A 2577 Valve Kit
B 2508 Piston Kit
D 2575 Water Seal Kit
Engine 120 TSS - 12314 Pag.3
1 2100280 Headphones
2 1682270 Switch
3 2100060 Capacitor Box
4 390201 O-Ring
6 2022150 Cable
7 2020570 Screw
8 1262400 Washer
9 2100110 Fairlead
11 2101710 Disk
12 2109270 Preassembly The Pump Body
13 2100980 Screw
14 1340350 Seal
15 2020850 Washer
16 1680250 Fan
17 4866 Engine
19 2200290 Capacitor
21 2440160 Plate
22 2029721 Preassembly Box TSS
23 2100070 Conveyor
Accessories 120 TSS - 12314 Pag.4
1 40350 Gun->40925+3082750+3780492
3 40667 Lance
2 1680220 O-Ring
4 40371 HAEAD
5 40352 Tank
6 600180 O-Ring
7 2620400
=
3020151		 High Pressure Hose
8 2000770 O-Ring
8 2000570 OR 10x2 Parker
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
ARSG WIND 120 TSS - 12314
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:
AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS

Specific References

New

Download

Diagram AR Farmer's 120 TSS

Diagram AR Farmer's 120 TSS

Download (487.08KB)

You might also like

Cold Water High Pressure Washer 130 bar AR388 -5% Sale
Annovi Reverberi S.p.A. SKU: AR388
Cold Water High Pressure Washer 130 bar AR388
Cold Water High Pressure Washer 130 bar AR388 Three-piston pump hardened stainless. Aluminum head, safety valve for automatic reset of the pressure in the pump head. Electric motor with overheating protection.
Last items in stock €182.71 €192.33
Details
Cold Water High Pressure Washer 120 bar AR142 Sale
Annovi Reverberi S.p.A. SKU: AR142
Cold Water High Pressure Washer 120 bar AR142
Cold Water High Pressure Washer 120 bar AR142 3 Axial piston pump driven by the oscillating plate, hardened stainless steel pistons, an automatic safety valve with pressure in the pump head, water filter. Complete kit with foam tank of...
AVAILABLE €108.09
Details
Cold Water High Pressure Washer 145 bar AR491 -5% Sale
Annovi Reverberi S.p.A. SKU: AR491
Cold Water High Pressure Washer 145 bar AR491
Cold Water High Pressure Washer 145 bar AR491 Two-wheel trolley with handle and hose reel. 3 Axial stainless steel pistons wobble-plate pump with aluminium head, tempered stainless steel pistons.
AVAILABLE €330.09 €347.46
Details
Cold Water High Pressure Washer 135 bar AR391 -5% Sale
Annovi Reverberi S.p.A. SKU: AR391
Cold Water High Pressure Washer 135 bar AR391
Cold Water High Pressure Washer 135 bar AR391 Two-wheel trolley with handle and hose reel. 3 Axial stainless steel pistons wobble-plate pump with aluminim head, tempered stainless steel pistons. Automatic by-pass valve with pump head...
Last items in stock €207.38 €218.29
Details
Cold Water High Pressure Washer 160 bar AR590 -5% Sale
Annovi Reverberi S.p.A. SKU: AR590
Cold Water High Pressure Washer 160 bar AR590
Cold Water High Pressure Washer 160 bar AR590 Three-piston pump hardened stainless. Brass head, safety valve for automatic reset of the pressure in the pump head. Electric motor with overheating protection. Total stop to halt. Water...
Last items in stock €424.26 €446.59
Details
Water Cleaning Hose
Ferritalia SKU: DES91914
Hight Pressure Washers Hose 8 mt
Hight Pressure Washers Hose 8 mt Original spare part for high pressure washer with a maximum pressure of about 180 bar. - Diameter connections F-F: M14x1,5 mm - Max Pressure: 18 MPa - about 180 bar - Maximum temperature: 60 ° C. -...
Last items in stock €32.35
Details
Water Cleaning Hose
Valex s.p.a. SKU: 1520117
Hight Pressure Washers Hose 7,5 mt
Hight Pressure Washers Hose 7,5 mt Original spare part for high pressure washer with a maximum pressure of about 300 bar. Part for the following products:  - HIGHT PRESSURE HOSE FOR PRESSURE WASHER CARRY 2500 - Tech Info: -...
Last items in stock €36.30
Details
Hose for Pressure Washer Annovi & Reverberi Blue Clean 142
Annovi Reverberi S.p.A. SKU: 3082290
Hose for Pressure Washer Annovi & Reverberi Blue Clean 142
Hose for Pressure Washer Annovi & Reverberi Blue Clean 142 Genuine part Annovi & Reverberi, High pressure Hose for Pressure Washers AR BC 141 - 142 - Black & Decker - PW 1400 K - K PLUS - Michelin MPX 100 - 110 - 120....
AVAILABLE €18.90
Details
Hose AP for Pressure Washer Annovi & Reverberi Blue Clean AR 410
Annovi Reverberi S.p.A. SKU: 2620400
Hose AP for Pressure Washer Annovi & Reverberi Blue Clean AR 410
Hose AP for Pressure Washer Annovi Reverberi Blue Clean AR410 Genuine part Annovi Reverberi, Hose AP for Pressure Washers, diameter 1/4'' - Joints M22x1,5 Female + Female M20x2 Max BAR 160 - Length 7.6 M. Part for the following...
Last items in stock €42.00
Details
OR 10x2 for Pressure Washer Annovi & Reverberi AR-ARSG HOT
Annovi Reverberi S.p.A. SKU: 2000570
OR 10x2 for Pressure Washer Annovi & Reverberi AR-ARSG HOT
OR 10x2 for Pressure Washer Annovi & Reverberi AR-ARSG HOT Original spare part Annovi & Reverberi, OR mm 10x2 Parker V1 1010 P5008 for Pressure Washers ARSG HOT 120-1106-1308-1309-1490N-1713-2015N-2021N-K-PRO 1508. Part for the...
AVAILABLE €1.78
Details
O-Ring mm 7,66x1,78 for Pressure Washers Black & Decker
Annovi Reverberi S.p.A. SKU: 600180
O-Ring mm 7,66x1,78 for Pressure Washers Black & Decker
O-Ring mm 7,66x1,78 for Pressure Washers Black & Decker Original Spare Parts Annovi & Rverberi, O-Ring mm 7,66x1,78 For the Following Products: - Black & Decker - PW 1700 WB - 12344 - Black & Decker - PW 1700 WB - 2007...
AVAILABLE €0.38
Details
Piston Kit S.210 for Pressure Washer A&R ARSG HOT 120
Annovi Reverberi S.p.A. SKU: 2508
Piston Kit S.210 for Pressure Washer A&R ARSG HOT 120
Piston Kit S.210 for Pressure Washer A&R ARSG HOT 120 Original part Annovi & Rverberi, Piston Kit S.210 for Pressure Washers Series HOT - HOT 120 - 1106 - Event - 131 N TSS - Event - 141 N TSS PRO - Event...
AVAILABLE €16.82
Details
Head + O-Ring for Pressure Washers AR Farmer's Event 131-141
Annovi Reverberi S.p.A. SKU: 2122
Head + O-Ring for Pressure Washers AR Farmer's Event 131-141
Head + O-Ring for Pressure Washers AR Farmer's Event 131-141 Original Part Annovi & Reverberi, Head + O-Ring for Pressure Washers ARSG Event - 131 N TSS - Event - 141 N TSS PRO - Synthesis - 141 TSS...
on 7/10 Business Days Approx €19.40
Details
Pump Bearing for Pressure Washer AR2590
Annovi Reverberi S.p.A. SKU: 2021570
Pump Bearing for Pressure Washer AR2590
Pump Bearing for Pressure Washer AR2590 Genuine part Annovi & Reverberi, Pump Bearing for Pressure Washer Annovi & Reverberi AR BC - Model 50 Hz - Series 25 - 2590 - 24424. Parts For the Following Products: - AR BC - 50 Hz...
AVAILABLE €9.62
Details
Water Seal for Pressure Washers ARSG FRESH FOG
Annovi Reverberi S.p.A. SKU: 2200140
Water Seal for Pressure Washers ARSG FRESH FOG
Water Seal for Pressure Washers ARSG FRESH FOG Genuine Part Annovi & Reverberi, Water Seal for Pressure Washers FRESH FOG - 12519 - FRESH FOG - 13672 - FRESH FOG - 12930 - RESH FOG - 13276 - FRESH FOG - 14036. Part for the...
AVAILABLE €1.37
Details
Oil Seal mm 12x2x5/7" for Pressure Washers ARSG
Annovi Reverberi S.p.A. SKU: 1683500
Oil Seal mm 12x2x5/7" for Pressure Washers ARSG
Oil Seal mm 12x2x5/7" for Pressure Washers ARSG Genuine Part for Annovi & Reverberi, Oil Seal mm 12x2x5/7" for Pressure Washers ARSG EVENT - EXTREME - MR CLEAN - NRG - PRO CLEAN...
AVAILABLE €2.54
Details
Capacitor 16 μF for Pressure Washer ARSG Wind - 120 TSS
Annovi Reverberi S.p.A. SKU: 2200290
Capacitor 16 μF for Pressure Washer ARSG Wind - 120 TSS
Capacitor 16 μF for Pressure Washer ARSG Wind - 120 TSS Genuine Parts Annovi & Reverberi, Capacitor 16 μF for Pressure Washer ARSG Wind - 120 TSS - 12314. Part for the following items:  -  ARSG - Models 50 Hz - Wind - 120 TSS -...
Last items in stock €17.48
Details
AR O RING for Pressure Washer AR8880
Annovi Reverberi S.p.A. SKU: 550350
AR O-RING for Pressure Washer AR8880
AR O-RING for Pressure Washer AR8880 Genuine spare part Annovi Reverberi, O-RING for Pressure Washers AR8880 - AR8840 - AR8860 - AR1120. Part for the following products: -  Pressure Washer Annovi Reverberi 8880 - 22915 - ...
AVAILABLE €0.62
Details
Annovi Reverberi O-R for Pressure Washer 2590
Annovi Reverberi S.p.A. SKU: 390201
Annovi Reverberi O-Ring for Pressure Washer 2590
Annovi Reverberi O-Ring for Pressure Washer 2590 Genuine spare part Annovi Reverberi, O-R 39,34x2,62 for Pressure Washers AR2590 - AR111. Part for the following products: -  Pressure Washer Annovi Reverberi 2590 - 24424 - ...
AVAILABLE €0.87
Details
AR Capacitor Box for AR 111
Annovi Reverberi S.p.A. SKU: 2100060
AR Capacitor Box for AR 111
Annovi Reverberi Capacitor Box for Pressure Washer AR 111 Genuine spare part Annovi Reverberi, Capacitor Box for Pressure Washer AR 111. Part for the following products: -  Pressure Washer ARSG EVENT 131 N TSS - 12487...
AVAILABLE €6.13
Details
Comments (0)
