Annovi & Reverberi Parts for Low Pressure Pump AR 75 LFP C
€0.74
VAT included
Annovi & Reverberi Parts for Low Pressure Pump AR 75 LFP C
Annovi & Reverberi Genuine spare parts or replacement parts for to repair Low Pressure Pump AR 75 LFP C Liquid Fertilizer Proof cod. 33156.
Annovi & Reverberi Parts for Low Pressure Pump AR 75 LFP C
€0.74
VAT included
Annovi & Reverberi Parts for Low Pressure Pump AR 75 LFP C
Annovi & Reverberi Genuine spare parts or replacement parts for to repair Low Pressure Pump AR 75 LFP C Liquid Fertilizer Proof cod. 33156.
settings
56 spare parts
description
1 exploded view
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
56 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Informazioni sulle spedizioni e consegne saranno disponibili a breve.
Annovi & Reverberi Parts for Low Pressure Pump AR 75 LFP C
Annovi & Reverberi Genuine spare parts or replacement parts for to repair Low Pressure Pump AR 75 LFP C Liquid Fertilizer Proof cod. 33156.In the following tables, look for the spare part and its respective code.
| Position | Code | Description | Note |
| 1 | 4800110 | Line | |
| 2 | 3120230 | Gasket | bp model |
| 2 | 3120680 | Gasket | Viton LFP model |
| 3 | 3129050 | Complete valve | bp model |
| 3 | 3129051 | Complete valve | LFP model |
| 4 | 550040 | O-ring | bp model |
| 4 | 880311 | O-ring | Viton LFP model |
| 5 | 651100 | Ring nut | |
| 6 | 4800360 | Hose tail | |
| 7 | 1140431 | Screw | Geomet C20 bp m. |
| 7 | 1140432 | Screw | Inox C20 LFP mod. |
| 8 | 390314 | Washer | Geomet bp model |
| 8 | 390315 | Washer | Inox LFP model |
| 9 | 3120511 | Nut | Geomet bp model |
| 9 | 3120510 | Nut | Inox LFP model |
| 10 | 4800030 | Head | |
| 11 | 4800010 | Pump body | |
| 12 | 800862 | Screw | Geomet C25 bp m. |
| 12 | 800861 | Screw | Inox C25 LFP model |
| 13 | 390314 | Washer | Geomet bp model |
| 13 | 390315 | Washer | Inox LFP model |
| 14 | 380080 | Ring | |
| 15 | 4800040 | Connecting-rod | |
| 16 | 380300 | Pin | |
| 17 | 4800190 | Piston | |
| 18 | 4800200 | Piston ring | |
| 19 | 4800210 | Sleeve | |
| 20 | 3120082 | Diaphragm | BlueFlex |
| 21 | 4800020 | Plate | |
| 22 | 3120760 | Washer | Inox |
| 23 | 3120100 | Hub pin | C35 bp model |
| 23 | 3120101 | Hub pin | C35 LFP model |
| 24 | 3120110 | Nut | C30 bp model |
| 24 | 3120790 | Nut | C30 LFP model |
| 25 | 4800050 | Cardan protection | |
| 26 | 4240590 | Screw | |
| 27 | 390180 | O-ring | |
| 28 | 4700030 | Tank | |
| 29 | 380243 | Washer | Geomet bp model |
| 29 | 380245 | Washer | Inox LFP model |
| 30 | 620611 | Screw | Geomet C10 bp m. |
| 30 | 620612 | Screw | Inox C10 LFP model |
| 31 | 1040060 | O-ring | |
| 32 | 750050 | Plug | |
| 33 | 650640 | Screw | Geomet C50 bp m. |
| 33 | 650642 | Screw | Inox C50 LFP mod. |
| 34 | 4800060 | Foot | |
| 35 | 4800130 | Line | |
| 36 | 1140450 | O-ring | bp model |
| 36 | 1140451 | O-ring | Viton LFP model |
| 37 | 3120440 | Ring nut | |
| 39 | 3120690 | Plug | C2 |
| 38 | 3120460 | Elbow | |
| 41 | 2440230 | O-ring | |
| 42 | 1260790 | Ring | |
| 43 | 1320370 | Bearing | |
| 44 | 3460090 | Ring | |
| 45 | 4800180 | Shaft | versione C |
| 46 | 621130 | Bearing | |
| 47 | 230380 | Ring | |
| 48 | 200390 | Ring | |
| 50 | 2840890 | O-ring | bp model |
| 50 | 2840891 | O-ring | Viton LFP model |
| 51 | 820510 | O-ring | |
| 52 | 3460330 | Fitting | |
| 53 | 180101 | O-ring | bp model |
| 53 | 180102 | O-ring | Viton LFP model |
| 54 | 1609000 | Safety valve | 20 bar |
| 55 | 550450 | Ring nut | |
| 56 | 880831 | O-ring | Viton |
| 57 | 550460 | Elbow | |
| 58 | 880581 | Plug | C30 |
| 59 | 4800320 | Shaft | versione SP |
| 60 | 2460480 | Key | (a) |
| 61 | 680350 | Screw | C20 |
| 62 | 961340 | Washer | |
| 63 | 650300 | Coupling | |
| 64 | 4800350 | Ring | |
| 65 | 800200 | Ring | |
| 66 | 4800011 | Pump body | C/C model |
| 67 | 1300050 | Ring | |
| 68 | 650250 | Key | |
| 69 | 4800330 | Shaft | versione C/C |
| Parts Kit | |||
| Model | Position | Quantity | |
| KIT 43080 | 20 | 3 | |
| Membrane BlueFlex | |||
| BlueFlex diaphragms | |||
| KIT 42816 | 2-3 | 6+6 | |
| Valvole / Valves | |||
| AR75LFP | |||
| KIT 42524 | 2-3 | 6+6 | |
| Valvole / Valves | |||
| AR75bp | |||
| KIT 46142 | 4-27-31-36-41-50-51 | 1+1+1+1+1+1+1 | |
| OR /O-Rings | |||
| AR75LFP | |||
| KIT 46143 | 4-27-31-36-41-50-51 | 1+1+1+1+1+1+1 | |
| OR /O-Rings | |||
| AR75bp | |||
| Service Kit | |||
| KIT 46144 - AR75LFP | |||
| KIT 46145 - AR75bp | |||
| Posizione | Quantità | ||
| 2 | 6 | ||
| 3 | 6 | ||
| 4 | 1 | ||
| 5 | 1 | ||
| 6 | 1 | ||
| 20 | 3 | ||
| 21 | 3 | ||
| 22 | 3 | ||
| 23 | 3 | ||
| 24 | 3 | ||
| 27 | 1 | ||
| 28 | 1 | ||
| 31 | 1 | ||
| 32 | 1 | ||
| 36 | 1 | ||
| 37 | 1 | ||
| 38 | 1 | ||
| 41 | 1 | ||
| 47 | 1 | ||
| 50 | 1 | ||
| 51 | 1 | ||
