Ama Parts for Brushcutter PLAYCUT NBC530

Name: Ama Parts for Brushcutter PLAYCUT NBC530
Brand: A.M.A. S.p.A.
SKU: Ama PLAYCUT NBC530 98803
Availability: InStock

SKU: Ama PLAYCUT NBC530 98803

€0.10

VAT included

Ama Spare Parts for Brushcutter PLAYCUT NBC530 - code - 98803

AMA Garden Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Brushcutter PLAYCUT NBC530 - code - 98803.

Ama Parts for Brushcutter PLAYCUT NBC530

Online only
New
Out-of-Stock

Ama Parts for Brushcutter PLAYCUT NBC530

SKU: Ama PLAYCUT NBC530 98803 Condition: New

€0.10

VAT included

Ama Spare Parts for Brushcutter PLAYCUT NBC530 - code - 98803

38 Spare parts

2 exploded views

Download Exploded PDF

Quantity

Out-of-Stock

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS

MORE INFO:: [email protected]

Original Product Manufacturer warranty included

Technical Support Our team helps you choose

Secure and guaranteed payments

38 spare parts

Page 1 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	99820 Screw axes	€2.56
3		AMA97395 Clutch Assy	€15.81
6	Image coming soon	99838 FLYWHEEL COVER	€4.32
9	Image coming soon	97433 Double layer flywheel	€13.43
12	Image coming soon	97391 Ignition coil	€16.59
18	Image coming soon	79810 Oil seal TC12x22x7	€4.99
20	Image coming soon	99841 Crankcase gasket	€4.00
22	Image coming soon	97452 Piston pin check ring	€4.48
23	Image coming soon	99807 Piston pin	€4.48
24	Image coming soon	100544 Piston	€7.20
25	Image coming soon	97450 Piston ring	€4.48
27	Image coming soon	100545 Cilindro NBC530	€35.18
28	Image coming soon	99844 Muffler gasket	€4.17
29	Image coming soon	99835 Muffler	€18.39
40	Image coming soon	10660 Spark plug	€3.66
44	Image coming soon	97429 Carburetor	€17.96
45	Image coming soon	97392 Fan	€4.48
46	Image coming soon	99945 Starter assy	€8.95
47	Image coming soon	99802 Cutting head plastic safety guard	€2.39
48	Image coming soon	97457 Inner cover of air filter	€2.32
49	Image coming soon	99815 Anti-spray separator	€2.39
50	Image coming soon	99812 Chock valve	€2.42
53	Image coming soon	97497 Air filter sponge	€5.20
54	Image coming soon	97456 Outer cover of air filter	€4.00
55.3		97434 FUEL TANK CAP	€4.48
55	Image coming soon	99946 Fuel tank assy	€9.10
55.2		AMA97439 Fuel pipe set NB350	€4.48

Page 2 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	99813 Transission support assy	€14.40
4	Image coming soon	99850 Aluminum working shaft assy Ø26	€11.04
6	Image coming soon	99794 Hard shaft Ø8x1540	€8.80
7	Image coming soon	99736 K stype loop handle	€6.41
8	Image coming soon	99803 Belt connecter	€2.32
11	Image coming soon	99734 Front handle S set	€9.99
13	Image coming soon	99816 Protection guard fixed board	€2.24
15	Image coming soon	99798 Cutting head plastic safety guard	€4.40
18	Image coming soon	99799 Nylon line knife support	€2.23
19	Image coming soon	99849 Nylon line knife	€2.56
21	Image coming soon	99737 Gear box M assy	€18.29

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

For the following items, it is strongly recommended that you contact us by email or phone before purchasing.

Our customer service team is at your complete disposal to provide dedicated assistance and all the information you need for these products.

99841
97452
97451
100378
97449
100379
97428
97456
99850
99794

Ama Spare Parts for Brushcutter PLAYCUT NBC530 - code - 98803

In the following table, look for the model of the Brushcutter and the respective parts of the code.

Ama Brushcutter-PLAYCUT-98803 (NBC530)
Engine
#	Part Num.	Description
1	99820	Screw axes
2	99826	Wave washer
3	AMA97395	Clutch
4	99827	Washer B
5	80700026-14	M5x20 screw Discontinued
6	99838	Flywheel cover
7	80700185-01	Pin Ø 4x10 Discontinued
8	80700052-11	M8 nut Discontinued
9	97433	Double layer flywheel
10	80700026-24	M5x30 screw Discontinued
11	99828	Front-half crankcase
12	97391	Ignition coil
13	80700179-02	Oil seal TC15x30x7 Discontinued
14	80700205-01	Bearing 6202 Discontinued
15	100543	Crankshaft & connecting rod set
16	99793	Half-round key 3x13x5
17	99708	Needle bearing KBK10x13x15.5
18	79810	Oil seal TC12x22x7
19	80700186-01	Pin Ø 5x10 Discontinued
20	99841	Crankcase gasket
21	99829	Back-half crankcase
22	97452	Piston pin check ring
23	99807	Piston pin
24	100544	Piston
25	97450	Piston ring
26	97496	Cylinder gasket
27	100545	Cylinder (overhead)
28	99844	Muffler gasket
29	99835	Muffler
30	xxxxx	Muffler steel cover
31	80700026-09	M5x16 screw Discontinued
32	80700136-03	Flat washer 6 Discontinued
33	80700046-15	M6x60 screw Discontinued
34	80700028-02	M5x14 screw Discontinued
35	80700135-01	Flat washer 5 Discontinued
36	97466	Engine cover
37	97467	Air guide plate
38	80700074-02	ST3x9-H-C screw Discontinued
39	80700026-17	M5x25 screw Discontinued
40	10660	Spark plug
41	97494	Inlet pipe gasket
42	97455	Inlet pipe
43	100546	Carburetor gasket
44	97429	Carburetor
45	97392	Easy starter drive plate
46	99945	Starter assy
47	99802	Chock lever
48	97457	Inner cover of air filter
49	99815	Anti-spray separator
50	99812	Chock valve
51	80700101-01	Spring washer 5 Discontinued
52	80700023-22	M5x55 screw Discontinued
53	97497	Air filter sponge
54	97456	Outer cover of air filter
55	99946	Fuel tank assy
55.2	AMA97439	Fuel pipe set
55.3	97434	Fuel tank cap set
56	80700026-07	M5x16 screw 4 Discontinued
Pag.2
Shaft
#	Part Num.	Description
1	99813	Transission support assy
2	80700048-10	M6x30 screw Discontinued
3	80700026-02	M5x12 screw Discontinued
4	99850	Aluminum working shaft assy Ø26
6	99794	Hard shaft Ø8x1540
7	99736	K stype loop handle
8	99803	Belt connecter
9	80700015-09	M5 nut Discontinued
10	80700024-19	M5x16 screw Discontinued
11	99734	Front handle S set
12	80700048-04	M6x25 screw Discontinued
13	99816	Protection guard fixed board
14	80700079-03	ST4.8x20-H-F screw Discontinued
15	99798	Cutting head plastic safety guard
16	99848	Down plate of plastic safety guard
17	80700075-01	ST4.2x10-H-F screw Discontinued
18	99799	Nylon line knife support
19	99849	Nylon line knife
20	80700075-06	ST4.2x16-H-F screw Discontinued
21	99737	Gear box M assy
22	99846	Nylon head 1
