Ama Parts for Brushcutter PLAYCUT NBC260

Name: Ama Parts for Brushcutter PLAYCUT NBC260
Brand: A.M.A. S.p.A.
SKU: Ama PLAYCUT NBC260 98961
Availability: InStock

SKU: Ama PLAYCUT NBC260 98961

€0.10

VAT included

Ama Spare Parts for Brushcutter PLAYCUT NBC260 - code - 98961

AMA Garden Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Brushcutter PLAYCUT NBC260 - code - 98961.

Ama Parts for Brushcutter PLAYCUT NBC260

Online only
New
Out-of-Stock

Ama Parts for Brushcutter PLAYCUT NBC260

SKU: Ama PLAYCUT NBC260 98961 Condition: New

€0.10

VAT included

Ama Spare Parts for Brushcutter PLAYCUT NBC260 - code - 98961

39 Spare parts

4 exploded views

Download Exploded PDF

Quantity

Out-of-Stock

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS

MORE INFO:: [email protected]

Original Product Manufacturer warranty included

Technical Support Our team helps you choose

Secure and guaranteed payments

39 spare parts

Page 1 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	97436 Front engine cover assy	€16.07
1.6	Image coming soon	99837 Clutch drum	€5.44
1.1		99842 Ignition Coil for Hedge Trimmer Valex TSS266	€34.85
4	Image coming soon	99856 Screw axes	€2.39
6	Image coming soon	97394 Tank Cap	€9.36
15	Image coming soon	97393 Hardware Kit	€15.01
16	Image coming soon	89430 Oil seal	€3.73
17	Image coming soon	16217 CUSC.RADIALE / SFERA 6001-2RS	€2.59
20	Image coming soon	79818 Needle bearing-small head	€2.89
21	Image coming soon	97448 Piston pin check ring	€4.48
22	Image coming soon	97444 Piston pin	€4.48
23	Image coming soon	97443 Piston	€8.95
24	Image coming soon	97442 Piston ring	€4.48
26	Image coming soon	97446 Cylinder	€14.18
27	Image coming soon	99843 Muffler gasket	€3.92
28	Image coming soon	99836 Muffler	€17.19
29	Image coming soon	99857 Muffler metal cover	€3.92
34	Image coming soon	97458 Inlet pipe	€4.71
37	Image coming soon	99839 Crankcase gasket	€3.21
40	Image coming soon	97427 Starter catch plate assy	€4.48
41		97435 Ignition Coil for Motorpump Papillon PT 843	€30.02
45	Image coming soon	97426 Carburetor	€18.84
46	Image coming soon	99858 Chock lever	€3.21
48	Image coming soon	99859 Choke valve	€3.21
50	Image coming soon	99823 Anti-spray separator	€4.32
54	Image coming soon	97453 Air filter knob	€4.48
56.2		97434 Recoil Starter Assy for Motorpump Papillon PT 843	€19.17
56	Image coming soon	97437 Fuel Tap	€10.90
56.3	Image coming soon	99729 Fuel tube including the fuel filter	€2.56

Page 2 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	99795 Aluminum shaft assy Ø24x1500	€5.53
3	Image coming soon	99796 Hard shaft Ø7x1543	€5.44
4	Image coming soon	99735 Rear handle S	€14.40
5	Image coming soon	97490 Belt connecter	€3.21
7	Image coming soon	99733 Front handle	€7.92
15	Image coming soon	99852 Plastic safety guard fixed board	€3.92
16	Image coming soon	99802 Cutting head plastic safety guard	€2.39
20	Image coming soon	99731 Gear box assy	€17.58

Page 3 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
4	Image coming soon	99735 Rear handle S	€14.40
5	Image coming soon	97490 Belt connecter	€3.21
7	Image coming soon	99733 Front handle	€7.92

Page 4 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	99851 Aluminum working shaft Ø24x735	€7.20
6	Image coming soon	99852 Plastic safety guard fixed board	€3.92
9	Image coming soon	99731 Gear box assy	€17.58
10	Image coming soon	99802 Cutting head plastic safety guard	€2.39
14	Image coming soon	18185 3T blade	€11.09

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Ama Spare Parts for Brushcutter PLAYCUT NBC260 - code - 98961

AMA BRUSHCUTTER-PLAYCUT-98961 (NBC260) Parts List Pag.1
Motore / Engine
#	Part Num.	Description
1	97436	Front engine cover assy
1.1	99842	Damping rubber
1.2	89534	Shaft ring
1.4		M5x25 screw
1.5		Front engine cover
1.6	99837	Clutch drum
1.7		M5 nut
2		MT4x18 screw
3		M5x16 screw
4	99856	Screw axes
5	79802	Wave washer
6	97394	Clutch
7	79804	Flat washer
8		M8x1 nut
9		Spring washer 8
10		Flat washer 8
11	37399	Flywheel
12		M5x30 screw
13	99822	Front-half crankcase
14		M5x20 screw
15	97393	Ignition coil
16	89430	Oil seal
17	16217	Bearing 6001
18	98832	Crankshaft assy
19	99792	Half-round key
20	79818	Needle bearing
21	97448	Piston pin check ring
22	97444	Piston pin
23	97443	Piston
24	97442	Piston ring
25	97469	Cylinder gasket
26	97446	Cylinder
27	99843	Muffler gasket
28	99836	Muffler
29	99857	Muffler metal cover
30		Flat washer 5
31		M5x60 screw
32	10600	Spark plug
33	97498	Inlet pipe gasket
34	97458	Inlet pipe
35		M5x25 screw
36	97499	Carburetor gasket
37	99839	Crankcase gasket
38		Round pin 44x10
39	99821	Back-half crankcase
40	97427	Starter catch plate assy
41	97435	Back engine cover assy
41.3	99860	Out start wheel
41.4	99861	Easy start torsion spring
41.6	99862	Inner start wheel
41.7	99863	Easy starter coil ring
42	97465	Top cover
43		M5x14 screw
44		M4x16 screw
45	97426	Carburetor
46	99858	Chock lever
47	97460	Air filter inner cover
48	99859	Choke valve
49		ST4.2x12 Self-tapping screw
50	99823	Anti-spray separator
51		M5x50 screw
52	97501	Air filter sponge
53	97459	Air filter cover
54	97453	Air filter knob
55		M5x16 screw
56	97437	Fuel tank assy
56.2	97434	Fuel tank cap assy
56.3	99729	Fuel tube including the fuel filter
Asta / Shaft Pag.2
#	Part Num.	Description
1	99795	Aluminum shaft assy Ø24x1500
3	99796	Hard shaft Ø7x1543
4	99735	Rear handle S
5	97490	Belt connecter
6		M5x10 screw
7	99733	Front handle
13		ST4.8x12-H-F screw
14		M6x25 screw
15	99852	Plastic safety guard fixed board
16	99802	Cutting head plastic safety guard
17		M5x12 screw
18	99853	Nylon line knife
19		M5 nut
20	99731	Gear box assy
21		M5x14 screw
22	99847	Nylon head
23	99738	Harness
Asta / Shaft (Prima serie - Sezione 1) Pag.3
#	Part Num.	Description
1	99864	Aluminum working shaft Ø24x760
3	99865	Hardness axes Ø7x806
4	99735	Rear handle S
5	97490	Hand ring
6		M5x10 screw
7	99733	Loop handle
8		Bland rivets
9	99854	Shaft connector
10		M6x20 screw
11	99855	Knob
Asta / Shaft (Prima serie - Sezione 2) Pag.4
#	Part Num.	Description
1	99851	Aluminum working shaft Ø24x735
2	99824	Shaft connector pin
3		Shaft connector reviet
5	99825	Rigid axle
6	99852	Ø24 Protection guard upper cover
7		M6x25 screw
8		M5x14 screw
9	99731	Gearcase
10	99802	Protection guard assy
11		M5x12 screw
12	99853	Nylon line knife
13		M5 nut
14	18185	3T blade
15		3T blade cover
16	99847	Nylon head
