| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
1
|
|
TRC-001 Hoop(25) | €9.51 | |
|
2
|
|
TRC-002 Throtte Lever | €11.08 | |
|
3
|
|
TRC-003 Throrte Cable | €11.81 | |
|
6
|
|
TRC-006 Handle bracket | €11.08 | |
|
7
|
|
TRC-007 Expansion Pulley Brake Cable for Transporter AMA TAG 300N on Demand Only Call Us Before | €18.99 | |
|
9
|
|
TRC-009 ON/OFF Switch for Transporter AMA TAG 300N - TAG 500N on Reservation Only | €21.60 | |
|
10
|
|
TRC-010 Direction Change Cable for Transporters AMA TAG 300N - TAG 500N | €23.59 | |
|
18
|
|
TRC-018 Safety Contro! Handle | €8.88 | |
|
19
|
|
TRC-019 Safety cap | €8.55 | |
|
21
|
|
TRC-021 Cylindrical pin 4X25 | €8.55 | |
|
22
|
|
TRC-022 Handle Frame Assembly | €104.43 | |
|
24
|
|
TRC-024 Bolt M8x16 | €0.00 | Not available for order |
|
25
|
|
TRC-025 Bolt M8X20 | €0.00 | Not available for order |
|
34
|
|
TRC-034 Washer a8 | €8.55 | |
|
37
|
|
TRC-037 Transporter AMA TAG 300N V-Betl B762 X 300 | €17.74 | |
|
40
|
|
TRC-MOT6,5HP Engine (G200F LONCIN) 6,5HP -79723 ENQUIRE | €0.12 | Not available for order |
|
43
|
|
TRC-043 Clutch Set Assy for Transporter AMA TAG 300N - TAG 500N Available on Order Only | €84.25 | |
|
53
|
|
TRC-053 Sring | €9.51 | |
|
56
|
|
TRC-056 Washer mm 10 | €0.00 | Not available for order |
|
57
|
|
TRC-057 Bearing 6204-2RS | €9.51 | |
|
58
|
|
TRC-058 Circlip 47 | €0.00 | Not available for order |
|
59
|
|
TRC-059 Support Wheel Weldment | €58.05 | |
|
60
|
|
TRC-060 Gasket 25x47x7 | €8.55 | |
|
61
|
|
TRC-061 Hopper Base Frame | €8.55 | |
|
62
|
|
TRC-062 Bolt M16X100 | €0.00 | Not available for order |
|
63
|
|
TRC-063 Nut M16 | €9.51 | |
|
66
|
|
TRC-066 Ø 47 Axle Head Cover (Guide Wheel) | €8.55 | |
|
67
|
|
TRC-067 Circlip 42 | €0.00 | Not available for order |
|
68
|
|
TRC-068 Bearing 61905 | €9.51 | |
|
69
|
|
TRC-069 Guide Wheel | €62.71 | |
|
70
|
|
TRC-070 Gasket 42x30x7 | €8.55 | |
|
71
|
|
TRC-071 Caterpillar Chain 180x60 | €274.29 | |
|
73
|
|
TRC-073 Support Bracket | €62.71 | |
|
77
|
|
TRC-077 Gas Spring | €22.02 | |
|
79
|
|
TRC-079 Lever Knob | €8.55 | |
|
80
|
|
TRC-080 Gear Shift Lever Weldment | €22.02 | |
|
155
|
|
TRC-155 Drive Wheel for Transporter AMA TAG 300N - TAG 500N on Reservation Only | €62.71 | |
|
171
|
|
TRC-171 Bolt M6x16 | €0.00 | Not available for order |
|
501
|
|
TRC-LEVADX Kit lever + cable RIGHT | €0.12 | Not available for order |
|
502
|
|
TRC-LEVASX Kit lever + cable LEFT | €0.12 | Not available for order |
|
503
|
|
TRC-043 Clutch Set Assy for Transporter AMA TAG 300N - TAG 500N Available on Order Only | €84.25 | |
|
504
|
|
TRC-GEARBOX Kit Gearbox | €895.40 | |
|
505
|
|
88221 Complete Agricultural container | €531.05 | |
|
506
|
|
88222 Complete Dumper container | €531.05 |
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
157
|
|
TRC-157 Hopper Cable for Transporters AMA TAG 300N - TAG 500N Available on Order | €23.98 | |
|
159
|
|
TRC-159 Handle Weldment | €31.41 | |
|
160
|
|
TRC-160 Handle Sleeve(cp28) | €8.55 | |
|
161
|
|
TRC-161 Body Weldment(back) | €130.53 | |
|
162L
|
|
TRC-162L Body Weldment(side) Left | €73.14 | |
|
162R
|
|
TRC-162R Body Weldment(side) Right | €73.14 | |
|
163
|
|
TRC-163 Body Weldment(front) | €79.11 | |
|
164
|
|
TRC-164 Body Weldment(bottom) | €62.71 | |
|
165
|
|
TRC-165 Star Grip Knob | €6.70 | |
|
166
|
|
TRC-166 Backstop spring | €8.55 | |
|
169
|
|
TRC-169 Torsional Spring | €0.00 | Not available for order |
|
170
|
|
TRC-170 Plug 25 | €0.00 | Not available for order |
| Pos. | Item | Price | Buy | |
|---|---|---|---|---|
|
84
|
|
TRC-084 Pin 5x30 | €14.87 | |
|
90
|
|
TRC-090 Vent-Plug | €8.55 | |
|
91
|
|
TRC-091 Obturating Ring Assembly 14 | €8.55 | |
|
95
|
|
TRC-095 Seal FB17X40X7 | €9.51 | |
|
96
|
|
TRC-096 Gear Box Case (L) | €115.98 | |
|
98
|
|
TRC-098 Gear Box Underlay | €13.50 | |
|
100
|
|
TRC-100 Gear Shaft III | €0.12 | Not available for order |
|
101
|
|
TRC-101 Gear III-2 | €39.55 | |
|
103
|
|
TRC-103 Gear III-4 | €28.28 | |
|
104
|
|
TRC-104 Gear III-3 | €27.03 | |
|
107
|
|
TRC-107 Gear II-1 | €27.03 | |
|
109
|
|
TRC-109 Gear II-2 | €27.03 | |
|
112
|
|
TRC-112 Gear II-4 | €27.03 | |
|
113
|
|
TRC-113 Gear II-5 | €22.02 | |
|
114
|
|
TRC-114 Gear Box Case ( R) | €94.91 | |
|
115
|
|
TRC-115 Big Pulley Weldment | €28.28 | |
|
116
|
|
TRC-116 Slip Duplex Pulley | €43.92 | |
|
117
|
|
TRC-117 Shaft I | €34.56 | |
|
118
|
|
TRC-118 Gear | €43.92 | |
|
125
|
|
TRC-125 Plug | €8.55 | |
|
129
|
|
TRC-129 Rivet Assembly | €22.02 | |
|
130
|
|
TRC-130 Brake Pad for Transporters AMA TAG 300N - TAG 500N Available on Order | €30.01 | |
|
131
|
|
TRC-131 Expansion Brake Cover Weldment | €18.36 | |
|
133
|
|
TRC-133 Output Gear Bush Gasket | €9.90 | |
|
134
|
|
TRC-134 Gasket 1 | €0.00 | Not available for order |
|
136
|
|
TRC-136 Spring Gasket | €0.00 | Not available for order |
|
139
|
|
TRC-139 Clutch Bush | €50.19 | |
|
140
|
|
TRC-140 Output Gear | €0.12 | Not available for order |
|
141
|
|
TRC-141 Joint Bush | €43.92 | |
|
142
|
|
TRC-142 Steel Ball 5 | €7.49 | |
|
147
|
|
TRC-147 Bolt M 1 0x60 | €0.00 | Not available for order |
|
149
|
|
TRC-149 Seal FB42x25x7 | €9.60 | |
|
150
|
|
TRC-150 Output Shaft Composite Bushing | €8.88 | |
|
151
|
|
TRC-151 Output Shaft House | €65.33 | |
|
152
|
|
TRC-152 Guard Cover | €56.46 | |
|
156
|
|
TRC-156 Seal FB16x22x4 | €12.76 |
Shipping and delivery information will be available shortly.
Ama genuine spare parts or replacements parts for to repair TRANSPORTER TAG300N/TAG300ND - 79900/79901.
Fix Your TRANSPORTER TAG300N. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Lawnmower and the respective parts of the code.![]()
| TRANSPORTER TAG300N/TAG300ND - 79900/79901 Pag.1 | ||
| # | Part Num. | Description |
| 1 | TRC-001 | Hoop(@25) |
| 2 | TRC-002 | Throtte Lever |
| 3 | TRC-003 | Throrte Cable |
| 6 | TRC-006 | Handle bracket |
| 7 | TRC-007 | Expansion Pulley Brake Cable |
| B | TRC-008 | Handle Sleeve |
| 9 | TRC-009 | ON/OFF Switch |
| 10 | TRC-010 | Direction Change Cable |
| 18 | TRC-018 | Safety Contro! Handle |
| 19 | TRC-019 | Safety cap |
| 21 | TRC-021 | Cylindrical pin 4X25 |
| 22 | TRC-022 | Handle Frame Assembly |
| 24 | TRC-024 | Bolt M8x16 |
| 25 | TRC-025 | Bolt M8X20 |
| 34 | TRC-034 | Washer a8 |
| 37 | TRC-037 | Belt B762 X 300 |
| 40 | TRC-MOT6,5HP | Engine (G200F LONCIN) 6,5HP -79723 ENQUIRE |
| 43 | TRC-043 | Clutch |
| 53 | TRC-053 | Sring |
| 56 | TRC-056 | Washer 010 |
| 57 | TRC-057 | Bearing 6204-2RS |
| 58 | TRC-058 | Circlip 47 |
| 59 | TRC-059 | Support Wheel Weldment |
| 60 | TRC-060 | Gasket 25x47x7 |
| 61 | TRC-061 | Hopper Base Frame |
| 62 | TRC-062 | Bolt M16X100 |
| 63 | TRC-063 | Nut M16 |
| 66 | TRC-066 | @47 Axle Head Cover (Guide Wheel) |
| 67 | TRC-067 | Circlip 42 |
| 68 | TRC-068 | Bearing 61905 |
| 69 | TRC-069 | Guide Wheel |
| 70 | TRC-070 | Gasket 42x30x7 |
| 71 | TRC-071 | Caterpillar Chain 180x60 |
| 73 | TRC-073 | Support Bracket |
| 75 | TRC-075 | Innesto Frizione |
| 77 | TRC-077 | Gas Spring |
| 79 | TRC-079 | Lever Knob |
| 80 | TRC-080 | Gear Shift Lever Weldment |
| 84 | TRC-084 | Pin 5x30 |
| 90 | TRC-090 | Vent-Plug |
| 91 | TRC-091 | Obturating Ring Assembly 14 |
| 95 | TRC-095 | Seal FB17X40X7 |
| 96 | TRC-096 | Gear Box Case (L) |
| 98 | TRC-098 | Gear Box Underlay |
| 100 | TRC-100 | Gear Shaft III |
| 101 | TRC-101 | Gear III-2 |
| 103 | TRC-103 | Gear III-4 |
| 104 | TRC-104 | Gear III-3 |
| 107 | TRC-107 | Gear II-1 |
| 109 | TRC-109 | Gear II-2 |
| 11D | TRC-110 | Gear II-3 |
| 112 | TRC-112 | Gear II-4 |
| 113 | TRC-113 | Gear II-5 |
| 114 | TRC-114 | Gear Box Case ( R) |
| 115 | TRC-115 | Big Pulley Weldment |
| 116 | TRC-116 | Slip Duplex Pulley |
| 117 | TRC-117 | Shaft I |
| 118 | TRC-118 | Gear |
| 125 | TRC-125 | Plug |
| 129 | TRC-129 | Rivet Assembly |
| 130 | TRC-130 | Brake Pad Assembly |
| 131 | TRC-131 | Expansion Brake Cover Weldment |
| 133 | TRC-133 | Output Gear Bush Gasket |
| 134 | TRC-134 | Gasket 1 |
| 136 | TRC-136 | Spring Gasket |
| 139 | TRC-139 | Clutch Bush |
| 140 | TRC-140 | Output Gear |
| 141 | TRC-141 | Joint Bush |
| 142 | TRC-142 | Steel Ball 5 |
| 147 | TRC-147 | Bolt M 1 0x60 |
| 149 | TRC-149 | Seal FB42x25x7 |
| 150 | TRC-150 | Output Shaft Composite Bushing |
| 151 | TRC-151 | Output Shaft House |
| 152 | TRC-152 | Guard Cover |
| 155 | TRC-155 | Driving Wheel |
| 156 | TRC-156 | Seal FB16x22x4 |
| 157 | TRC-157 | Hopper Cable |
| 159 | TRC-159 | Handle Weldment |
| 160 | TRC-160 | Handle Sleeve(cp28) |
| 161 | TRC-161 | Body Weldment(back) |
| 162L | TRC-162L | Body Weldment(side) Left |
| 162R | TRC-162R | Body Weldment(side) Right |
| 163 | TRC-163 | Body Weldment(front) |
| 164 | TRC-164 | Body Weldment(bottom) |
| 165 | TRC-165 | Star Grip Knob |
| 166 | TRC-166 | Backstop spring |
| 169 | TRC-169 | Torsional Spring |
| 170 | TRC-170 | Plug 25 |
| 171 | TRC-171 | Bolt M6x16 |
| KIT Pag.2 | ||
| 501 | TRC-LEVA DX | Kit lever + cable RIGHT |
| 502 | TRC-LEVA SX | Kit lever + cable LEFT |
| 503 | TRC-043 | Kit complete clutch |
| 504 | TRC-GEARBOX | Kit Gearbox |
| 505 | 88221 | Complete Agricultural container |
| 506 | 88222 | Complete Dumper container |
