Alpina Lawnmower AL5 51 SAQ Parts

SKU: AL5 51 SAQ - 2L0536844/A21
€22.20
VAT included

Alpina Lawnmower AL5 51 SAQ Spare Parts

For the maintenance and repair of your Self-propelled Lawnmower AL5 51 SAQ - 2L0536844/A21 - 2021, it is advisable to purchase original spare parts only. Buy Alpina spare parts at best prices with confidence. Open the PDF on the page to see all the components of the lawnmower. Live your garden by taking care of the lawn.
Alpina Lawnmower AL5 51 SAQ Spare Parts
Alpina Lawnmower AL5 51 SAQ Parts
  • Alpina Lawnmower AL5 51 SAQ Parts
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing - 1
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing - 2
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing - 3
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing - 4
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing - 5
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing - 6
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing - 7
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing - 8
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing - 9
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing - 10
  • Alpina Lawnmower AL5 51 SAQ Parts Drawing - 11
GGP Italy

Alpina Lawnmower AL5 51 SAQ Parts

SKU: AL5 51 SAQ - 2L0536844/A21 Condition: New
€22.20
VAT included

Alpina Lawnmower AL5 51 SAQ Spare Parts

For the maintenance and repair of your Self-propelled Lawnmower AL5 51 SAQ - 2L0536844/A21 - 2021, it is advisable to purchase original spare parts only. Buy Alpina spare parts at best prices with confidence. Open the PDF on the page to see all the components of the lawnmower. Live your garden by taking care of the lawn.
Alpina Lawnmower AL5 51 SAQ Spare Parts
settings 183 spare parts
description 13 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N ALPINA:: STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
183 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 381005195/2 RIGHT HANDLE BRACKET Black From 01-September-2018 €7.25
2
 photo_cameraImage coming soon 381005197/2 LEFT HANDLE BRACKET Black From 01-September-2018 €7.25
3
 photo_cameraImage coming soon 112727802/0 Screw €1.63
4
 photo_cameraImage coming soon 322545213/0 Plate €2.04
5
 photo_cameraImage coming soon 322600310/0 REAR DOOR (Not For Electric Start Models) €5.12
6
 photo_cameraImage coming soon 322108329/0 Rear Conveyor €20.11
7
 photo_cameraImage coming soon 112728697/0 Screw €1.63
8
 Belt Protection Guard for Lawnmower Alpina BL 510 SHQ 322060250/1 Belt Protection Guard for Lawnmower Alpina BL 510 SHQ €12.62
9
 photo_cameraImage coming soon 112728903/0 Screw €1.49
10
 photo_cameraImage coming soon 322140251/0 Mulching Deflector €13.42
11
 photo_cameraImage coming soon 381005618/0 Grey Deck €195.31
12
 photo_cameraImage coming soon 322820077/1 Cap From 01-september-2016 €1.66
13
 photo_cameraImage coming soon 119035000/0 Ring Or €5.26
14
 photo_cameraImage coming soon 112728450/0 Screw €1.54
15
 photo_cameraImage coming soon 322034002/0 Washing Connection €1.76
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 381302947/0 Axle, Front Wheels €29.25
2
 photo_cameraImage coming soon 322785305/1 Support From 01-September-2015 €2.74
3
 photo_cameraImage coming soon 112728697/0 Screw €1.63
4
 photo_cameraImage coming soon 322869735/0 Rod, Height Adjustment €15.51
5
 Alpina Rod Pin for BL 510 SHQ 122519823/0 Alpina Rod Pin for BL 510 SHQ €2.44
6
 photo_cameraImage coming soon 112436050/0 Plate €1.91
7
 photo_cameraImage coming soon 122450494/0 Spring €4.82
8
 photo_cameraImage coming soon 381302849/0 Rear Wheel Axle €52.41
9
 photo_cameraImage coming soon 381003458/0 Wheels Rear Adj. Lever From 01-september-2017 €10.79
10
 Alpina AL3 46 B Pin 122534131/0 Alpina AL3 46 B Pin €1.65
11
 photo_cameraImage coming soon 122446192/0 Spring €2.20
12
 photo_cameraImage coming soon 112154510/0 Nut €1.66
13
 photo_cameraImage coming soon 322785500/0 Support €1.91
15
 Gear Box Pin for Self Propelled Lawnmover Alpina BL 510 SHQ 122753000/0 Gear Box Pin for Self Propelled Lawnmover Alpina BL 510 SHQ €1.72
16
 photo_cameraImage coming soon 122570133/0 Right Pinion €8.09
17
 Left Pinion Gear for Self Propelled Lawnmover Alpina BL 510 SHQ 122570134/0 Left Pinion Gear for Self Propelled Lawnmover Alpina BL 510 SHQ €7.53
18
 Seeger D.12 for Self Propelled Lawnmower Alpina BL 510 SHQ 112608600/0 Seeger D.12 for Self Propelled Lawnmower Alpina BL 510 SHQ €1.58
19
 Axle Bush for Self Propelled Lawnmower Alpina BL 510 SB 322042067/0 Axle Bush for Self Propelled Lawnmower Alpina BL 510 SB €4.10
20
 photo_cameraImage coming soon 112521371/0 Washer €1.66
22
 photo_cameraImage coming soon 1111-9296-01 Belt €14.85
22
 V-Belt for Self Propelled Lawnmower Alpina BL 510 SB 135064196/0 V-Belt for Self Propelled Lawnmower Alpina BL 510 SB €9.20
23
 photo_cameraImage coming soon 122430254/0 Spring €4.13
24
 photo_cameraImage coming soon 322778473/1 Bracket From 01-September-2018 €2.20
25
 photo_cameraImage coming soon 112728699/0 Screw €1.66
28
 photo_cameraImage coming soon 112728697/0 Screw €1.63
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 112735410/0 Screw €1.63
2
 photo_cameraImage coming soon 322226313/0 Mask, Black €8.14
3
 photo_cameraImage coming soon 322393780/0 Front Handle €5.36
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 381006785/0 Handle Lower Part €25.35
2
 photo_cameraImage coming soon 112155000/0 Nut €1.66
3
 photo_cameraImage coming soon 112521350/0 Washer €1.74
4
 photo_cameraImage coming soon 112369500/0 Elastic Washer €1.67
5
 photo_cameraImage coming soon 112760605/0 Screw €3.52
6
 photo_cameraImage coming soon 381008691/0 Outfit, Screws €8.86
7
 photo_cameraImage coming soon 133320504/0 Cable clamp €2.04
8
 Cable Clip for Petrol Lawnmower Alpina AL3 46 B - AL5 51 G 118390020/0 Cable Clip for Petrol Lawnmower Alpina AL3 46 B - AL5 51 G €1.85
Page 5 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 5
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 381006739/2 Handle, Upper Part Black without Sponge;From 01-September-2011 To 31-August-2017 €24.91
1
 photo_cameraImage coming soon 381006745/3 Handle, Upper Part with Sponge Black with Sponge;From 01-september-2018 €41.74
2
 photo_cameraImage coming soon 122430313/0 Guide Spring €4.06
3
 photo_cameraImage coming soon 112521330/0 Washer €1.70
4
 photo_cameraImage coming soon 112154510/0 Nut €1.66
5
 Cable Clip for Petrol Lawnmower Alpina AL3 46 B - AL5 51 G 118390020/0 Cable Clip for Petrol Lawnmower Alpina AL3 46 B - AL5 51 G €1.85
6
 Engine Brake Lever for Self Propelled Lawnmower Alpina AL3 46 B 181003363/1 Engine Brake Lever for Self Propelled Lawnmower Alpina AL3 46 B €16.33
7
 photo_cameraImage coming soon 181030087/0 Motor Brake Cable €13.35
8
 photo_cameraImage coming soon 112727783/0 Screw €1.83
9
 photo_cameraImage coming soon 112154510/0 Nut €1.66
10
 photo_cameraImage coming soon 181003364/0 Cable Rear Drive €15.08
11
 photo_cameraImage coming soon 381030139/0 Cable Rear Drive €19.12
12
 photo_cameraImage coming soon 322551640/0 Plate €7.99
12
 Cable Plate for Lawn Mower DINO 47 322551685/0 Cable Plate for Lawn Mower DINO 47 €7.97
Page 6 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 6
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 381007483/1 Wheel Ø 200 €18.28
1
 photo_cameraImage coming soon 381007483/2 Wheel Ø 200 €18.28
2
 photo_cameraImage coming soon 119216035/0 Bearing €4.51
3
 photo_cameraImage coming soon 112521350/0 Washer €1.74
4
 photo_cameraImage coming soon 112155000/0 Nut €1.66
5
 photo_cameraImage coming soon 322110643/0 Hub Cap Grey €2.51
6
 photo_cameraImage coming soon 381007479/2 Wheel Ø 280 €33.42
7
 Alpina AL3 46 SG Screw 112728706/0 Alpina AL3 46 SG Screw €1.65
9
 photo_cameraImage coming soon 322600145/0 Protection, Wheel €1.91
10
 Inner wheel Cover for Lawnmower Alpina BL 510 SHQ 322600240/0 Inner wheel Cover for Lawnmower Alpina BL 510 SHQ €5.77
11
 photo_cameraImage coming soon 322110644/0 Hub Cap Grey €3.44
Page 7 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 7
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Alpina Conveyor for BL 510 SHQ 322108309/1 Alpina Conveyor for BL 510 SHQ €11.56
2
 photo_cameraImage coming soon 381008161/1 Side Discharge Assy €13.91
3
 photo_cameraImage coming soon 112727803/0 Screw €1.66
4
 photo_cameraImage coming soon 322806659/0 Pin €5.32
5
 photo_cameraImage coming soon 112154510/0 Nut €1.66
6
 photo_cameraImage coming soon 118203853/0 Hood €2.84
7
 photo_cameraImage coming soon 122450456/1 Spring €3.30
8
 photo_cameraImage coming soon 122517869/1 Pin €3.86
9
 photo_cameraImage coming soon 112604896/0 Crown Fixator €1.66
10
 photo_cameraImage coming soon 122517876/0 Pin €1.61
11
 photo_cameraImage coming soon 322783013/0 Safety €2.20
12
 photo_cameraImage coming soon 122450493/0 Spring €1.42
Page 8 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 8
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 Telf-Form Screw 3/8"x 1"1/4 for Lawnmower Alpina BL 510 SHQ 112735108/1 Telf-Form Screw 3/8"x 1"1/4 for Lawnmower Alpina BL 510 SHQ €2.19
2
 photo_cameraImage coming soon 1111-9120-01 BLADE BOSS Stiga Packed into 122465607/4 €21.56
2
 Blade Boss for Petrol Lawnmower Alpina AL3 46 SBQ 122465607/4 Blade Boss for Petrol Lawnmower Alpina AL3 46 SBQ €9.20
3
 photo_cameraImage coming soon 1111-9293-01 Mulching Blade (STIGA Pack) €23.90
3
 Mulching Blade for Lawnmower Alpina BL 510 SB 181004459/0 Mulching Blade for Lawnmower Alpina BL 510 SB €18.86
4
 Spring Washer 50x2x10.2 for Lawnmover Alpina BL 510 SHQ 122160400/0 Spring Washer 50x2x10.2 for Lawnmover Alpina BL 510 SHQ €3.71
5
 Alpina Washer M 10 for BL 510 SHQ 112523080/0 Alpina Washer M 10 for BL 510 SHQ €1.59
6
 Hex-Head Screw 3/8" X 2" for Lawnmowers Alpina - Stiga 112735698/0 Hex-Head Screw 3/8" X 2" for Lawnmowers Alpina - Stiga €1.92
7
 Woodruff Key for Petrol Lawnmower Alpina AL3 46 SBQ 112139100/0 Woodruff Key for Petrol Lawnmower Alpina AL3 46 SBQ €2.09
Page 9 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 9
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 322486497/0 Rear door €1.63
2
 photo_cameraImage coming soon 322486496/0 Grass-Box, Upper Part €30.64
3
 photo_cameraImage coming soon 181102422/0 Black Fabric Box €41.74
5
 photo_cameraImage coming soon 122450479/0 DEFLECTOR SPRING €3.44
6
 photo_cameraImage coming soon 122608525/1 Box, Fabric €13.02
6
 photo_cameraImage coming soon 122608525/2 Stiffening Lower €13.02
7
 photo_cameraImage coming soon 122517884/0 DEFLECTOR ROD €5.09
8
 photo_cameraImage coming soon 322109594/0 Stone Guard Support, Black €6.07
9
 photo_cameraImage coming soon 112728697/0 Screw €1.63
10
 photo_cameraImage coming soon 322600355/1 Stone Guard, Black €12.17
12
 photo_cameraImage coming soon 381008735/0 Kit plastic pin €2.32
13
 photo_cameraImage coming soon 381008639/0 Outfit, Screws €2.04
Page 10 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 10
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
2
 photo_cameraImage coming soon 112292102/0 Nut €1.86
3
 photo_cameraImage coming soon 118551468/0 Starter Assy €71.57
4
 photo_cameraImage coming soon 118551619/0 Starter handle €8.98
5
 photo_cameraImage coming soon 118550779/0 Starting Rope €7.18
6
 photo_cameraImage coming soon 118551621/0 Starter Spring €10.10
7
 photo_cameraImage coming soon 118551620/0 Starter Pulley €15.36
8
 photo_cameraImage coming soon 118551626/0 Spring €2.46
9
 photo_cameraImage coming soon 118551622/0 Starter ratchet €3.02
10
 photo_cameraImage coming soon 118551625/0 Spring €3.15
11
 photo_cameraImage coming soon 118551623/0 Cover €7.88
13
 photo_cameraImage coming soon 118551624/0 Pulley pin €4.26
14
 photo_cameraImage coming soon 118551788/0 Blower Housing €38.97
15
 photo_cameraImage coming soon 118550907/0 Pin €5.22
16
 photo_cameraImage coming soon 118550906/0 Pin €4.82
17
 photo_cameraImage coming soon 112791500/0 Screw €1.64
18
 photo_cameraImage coming soon 118551474/0 Elettronic Coil €49.45
20
 photo_cameraImage coming soon 1111-9206-01 Spark Plug (Rc12Yc) €6.38
21
 photo_cameraImage coming soon 112789000/0 Screw €1.77
22
 photo_cameraImage coming soon 118551456/0 Starter control €23.41
23
 photo_cameraImage coming soon 118551459/0 Rod €8.36
24
 photo_cameraImage coming soon 118551352/0 Stopper €3.72
25
 photo_cameraImage coming soon 118551450/1 Carburettor €75.05
26
 photo_cameraImage coming soon 118550930/0 Stud Bolt €5.79
27
 photo_cameraImage coming soon 118550929/0 Gasket €1.64
28
 photo_cameraImage coming soon 118550928/0 Insulator, Carburettor €3.02
29
 photo_cameraImage coming soon 118550927/0 Gasket €4.82
30
 photo_cameraImage coming soon 118551124/0 Packing Carburetor €4.82
31
 photo_cameraImage coming soon 118550893/0 Rocker Valve Arm €13.08
31
 photo_cameraImage coming soon 118551462/0 Air Cleaner Assy €33.42
33
 photo_cameraImage coming soon 118550257/0 Air Filter €11.58
34
 photo_cameraImage coming soon 118551463/0 Air Cleaner Cover €23.83
35
 photo_cameraImage coming soon 112292102/0 Nut €1.86
36
 photo_cameraImage coming soon 118551480/0 Fuel Pipe €7.71
37
 photo_cameraImage coming soon 118550918/0 Clamp €1.64
38
 photo_cameraImage coming soon 118550314/0 Fuel Filter €4.41
39
 photo_cameraImage coming soon 118551453/0 Tank €41.74
40
 photo_cameraImage coming soon 118551455/0 Fuel Cap €13.31
41
 photo_cameraImage coming soon 112791400/0 Screw €1.62
42
 photo_cameraImage coming soon 118551479/0 Breather Fuel Pipe €7.66
43
 photo_cameraImage coming soon 118550933/0 Throttle Lever €6.21
46
 photo_cameraImage coming soon 118551458/0 Spring €1.91
49
 photo_cameraImage coming soon 118551457/0 Governor Link €7.60
50
 photo_cameraImage coming soon 118550898/0 Muffler gasket €2.47
51
 photo_cameraImage coming soon 118551465/0 Muffler €32.02
52
 photo_cameraImage coming soon 118550930/0 Stud Bolt €5.79
53
 photo_cameraImage coming soon 118551466/0 Muffler Guard €23.56
54
 photo_cameraImage coming soon 118550806/0 Nut €1.63
Page 11 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 11
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 118550336/0 Nut €6.07
2
 photo_cameraImage coming soon 118550905/0 Flywheel Assy €82.72
3
 photo_cameraImage coming soon 118551277/0 Bolt €1.42
4
 photo_cameraImage coming soon 112791500/0 Screw €1.64
5
 photo_cameraImage coming soon 118551486/0 Flywheel Brake/Stop Switch Assy €37.58
6
 photo_cameraImage coming soon 118551522/0 Spring €2.46
7
 photo_cameraImage coming soon 118550300/0 Oil Seal €7.25
13
 photo_cameraImage coming soon 118551484/0 Crankshaft €129.18
14
 photo_cameraImage coming soon 118550288/0 Woodruff Key €6.20
16
 photo_cameraImage coming soon 118551448/0 Camshaft Assy €36.18
18
 photo_cameraImage coming soon 112789000/0 Screw €1.77
19
 photo_cameraImage coming soon 118551460/0 Speed Governor €16.47
22
 photo_cameraImage coming soon 118550935/0 Oil Seal €4.57
23
 photo_cameraImage coming soon 118550856/0 Cotter Pin €1.55
24
 photo_cameraImage coming soon 118550379/0 Oil Seal €6.76
27
 photo_cameraImage coming soon 112791500/0 Screw €1.64
28
 photo_cameraImage coming soon 118551276/0 Bolt €3.44
29
 photo_cameraImage coming soon 118550891/0 Valve Cover €13.35
30
 photo_cameraImage coming soon 118550892/0 Screw €3.30
31
 photo_cameraImage coming soon 118550893/0 Rocker Valve Arm €13.08
32
 photo_cameraImage coming soon 118550894/0 Plate €4.13
33
 photo_cameraImage coming soon 118550895/0 Retainer €4.57
34
 photo_cameraImage coming soon 118550896/0 Spring €2.87
35
 photo_cameraImage coming soon 118550910/0 Valve Assy, Intake + Exhaust €21.34
36
 photo_cameraImage coming soon 118551449/0 Valve Lifter €9.60
37
 photo_cameraImage coming soon 118551251/0 Push Rod €4.13
38
 photo_cameraImage coming soon 118551485/0 Piston ass.y €49.52
39
 photo_cameraImage coming soon 118551445/0 Piston Ring Assy €26.75
40
 photo_cameraImage coming soon 118550915/0 Piston Pin €5.38
41
 photo_cameraImage coming soon 118550914/0 Washer, Piston Pin €1.63
42
 photo_cameraImage coming soon 118551446/0 Connecting Rod Assy €37.58
43
 photo_cameraImage coming soon 112791500/0 Screw €1.64
44
 photo_cameraImage coming soon 118551444/0 Oil Filler Assy €12.59
Page 12 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 12
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 118551442/0 Engine Assembled €247.57
11
 photo_cameraImage coming soon 322055631/0 Grey Cover €5.18
12
 photo_cameraImage coming soon 322055632/0 Hood, Yellow €6.76
13
 photo_cameraImage coming soon 322055628/0 Grey Cover €5.09
201
 photo_cameraImage coming soon 1111-9234-01 Sae 30 4 Stroke Oil 0.6 Litre 16 €6.70
201
 photo_cameraImage coming soon 1111-9237-01 10w-30 4 Stroke Oil 0.6 Litre €7.01
201
 photo_cameraImage coming soon 1111-9244-01 Motor Oil 4 Stroke Stiga SAE 30 0,600 €8.08
203
 photo_cameraImage coming soon 1111-9236-01 Sae 30 4 Stroke Oil 1.4 Litre €11.87
203
 photo_cameraImage coming soon 1111-9238-01 10w-30 4 Stroke Oil 1.4 Litre €13.61
203
 photo_cameraImage coming soon 1111-9245-01 Sae 30 4 Stroke Oil (For Italy) 1,4 Lt €10.90

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Alpina Lawnmower AL5 51 SAQ Spare Parts

For the maintenance and repair of your Self-propelled Lawnmower AL5 51 SAQ - 2L0536844/A21 - 2021, it is advisable to purchase original spare parts only. Buy Alpina spare parts at best prices with confidence. Open the PDF on the page to see all the components of the lawnmower. Live your garden by taking care of the lawn.

In the following table, look for the model of the Petrol Lawn Mower and the respective parts of the code.
Alpina Lawnmower AL5 51 SAQ Spare Parts

Lawnmower AL5 51 SAQ - 2L0536844/A21 Deck pag.1
# Part Num. Description
1 381005195/2 Bracket-Rh
2 381005197/2 Left Bracket
3 112727802/0 Screw
4 322545213/0 Plate
5 322600310/0 Rear door
6 322108329/0 Rear Conveyor
7 112728697/0 Screw
8 322060250/1 Belt Protection
9 112728903/0 Screw
10 322140251/0 Mulching Deflector
11 381005618/0 Grey Deck
12 322820077/1 Cap
13 119035000/0 Or Ring
14 112728450/0 Screw
15 322034002/0 Washing Connection
Lawnmower AL5 51 SAQ - 2L0536844/A21 Height Adjusting pag.2
1 381302947/0 Axle, Front Wheels
2 322785305/1 Support
3 112728697/0 Screw
4 322869735/0 Rod, Height Adjustment
5 122519823/0 Pin
6 112436050/0 Plate
7 122450494/0 Spring
8 381302849/0 Rear Wheel Axle
8 381302849/1 Rear Wheel Axle
9 381003458/0 Wheels Rear Adj. Lever
9 381003458/1 Wheels Rear Adj. Lever
10 122534131/0 Pin
11 122446192/0 Spring
12 112154510/0 Nut
13 322785500/0 Support
14 181003134/0 Gear Box
15 122753000/0 Pin
16 122570133/0 Right Pinion
17 122570134/0 Left Pinion
18 112608600/0 Seeger
19 322042067/0 Bushing
20 112521371/0 Washer
22 1111-9296-01 Belt
22 135064196/0 Belt
23 122430254/0 Spring
24 322778473/1 Bracket
25 112728699/0 Screw
28 112728697/0 Screw
Lawnmower AL5 51 SAQ - 2L0536844/A21 Mask pag.3
1 112735410/0 Screw
2 322226313/0 Mask, Black
3 322393780/0 Front Handle
Lawnmower AL5 51 SAQ - 2L0536844/A21 Handle, Lower Part pag.4
1 381006785/0 Handle, Lower Part Black
2 112155000/0 Nut
3 112521350/0 Washer
4 112369500/0 Elastic Washer
5 112760605/0 Screw
6 381008691/0 Outfit, Screws
7 133320504/0 Fairlead
8 118390020/0 Conduit Clip
Lawnmower AL5 51 SAQ - 2L0536844/A21 Handle, Upper Part pag.5
1 381006739/2 Handle,Black Upper Part without sponge handgrip
1 381006745/3 Handle,Black Upper Part with sponge handgrip
2 122430313/0 Guide Spring
3 112521330/0 Washer
4 112154510/0 Nut
5 118390020/0 Conduit Clip
6 181003363/1 Lever, Engine Brake Black
7 181030087/0 Cable, Thread Engine Brake
8 112727783/0 Screw
9 112154510/0 Nut
10 181003364/0 Drive Control Lever
11 381030139/0 Cable Rear Drive
12 322551640/0 Cable Holder
12 322551685/0 Cable Holder ø22
Lawnmower AL5 51 SAQ - 2L0536844/A21 Wheel and Hub Cap pag.6
1 381007483/1 Wheel Ø 200
1 381007483/2 Wheel Ø 200
2 119216035/0 Bearing
3 112521350/0 Washer
4 112155000/0 Nut
5 322110643/0 Hub Cap Grey
6 381007479/2 Wheel Ø 280
7 112728706/0 Screw
8 322120115/0 Wheels Crown
9 322600145/0 Protection, Wheel
10 322600240/0 Protection, Wheel
11 322110644/0 Hub Cap Grey
Lawnmower AL5 51 SAQ - 2L0536844/A21 Ejection-Guard pag.7
1 322108309/1 Side Ejection Conveyor
2 381008161/1 Stone Guard Side Discharge Assy
3 112727803/0 Screw
4 322806659/0 Fulcrum Pin
5 112154510/0 Nut
6 118203853/0 Cap
7 122450456/1 Spring
8 122517869/1 Pin
9 112604896/0 Crown Fastener
10 122517876/0 Pin
11 322783013/0 Safety Button
12 122450493/0 Spring
Lawnmower AL5 51 SAQ - 2L0536844/A21 Blade pag.8
1 112735108/1 Screw
2 1111-9120-01 Blade Holder (Ø 22.2)
2 122465607/4 Hub With Pulley, Crankshaft Ø 22.2
3 1111-9293-01 Mulching Blade (STIGA Pack)
3 181004459/0 Blade
4 122160400/0 Elastic Disc
5 112523080/0 Washer
6 112735698/0 Screw
7 112139100/0 Key
Lawnmower AL5 51 SAQ - 2L0536844/A21 Grass-Catcher pag.9
1 322486497/0 Rear door
2 322486496/0 Grass-Box, Upper Part
3 181102422/0 Black Fabric Box
5 122450479/0 Spring
6 122608525/1 Lower Stiffening
6 122608525/2 Lower Stiffening
7 122517884/0 Pin
8 322109594/0 Stone Guard Support, Black
9 112728697/0 Screw
10 322600355/1 Stone Guard, Black
12 381008735/0 Outfit, Plastic Pin
13 381008639/0 Outfit, Screws
Lawnmower AL5 51 SAQ - 2L0536844/A21 Engine - Carburettor, Tank pag.10
2 112292102/0 Nut
3 118551468/0 Starter Assy
4 118551619/0 Starter Handle
5 118550779/0 Starting Rope
6 118551621/0 Starter Spring
7 118551620/0 Starter Pulley
8 118551626/0 Spring
9 118551622/0 Ratchet, Starter
10 118551625/0 Spring
11 118551623/0 Cover
13 118551624/0 Stud
14 118551788/0 Blower Housing
15 118550907/0 Pin
16 118550906/0 Pin
17 112791500/0 Screw
18 118551474/0 Elettronic Coil
20 1111-9206-01 Spark Plug (Rc12Yc)
21 112789000/0 Screw
22 118551456/0 Choke Control
23 118551459/0 Control Rod
24 118551352/0 Retainer
25 118551450/1 Carburettor
26 118550930/0 Stud Bolt
27 118550929/0 Gasket
28 118550928/0 Insulator, Carburettor
29 118550927/0 Gasket
30 118551124/0 Gasket
31 118551462/0 Air Cleaner Assy
33 118550257/0 Air Filter
34 118551463/0 Air Cleaner Cover
35 112292102/0 Nut
36 118551480/0 Fuel Pipe
37 118550918/0 Pipe Clip
38 118550314/0 Fuel Filter
39 118551453/0 Tank
40 118551455/0 Fuel Cap
41 112791400/0 Screw
42 118551479/0 Breather Fuel Pipe
43 118550933/0 Arm Governor
46 118551458/0 Spring
49 118551457/0 Governor Link
50 118550898/0 Gasket, Muffler
51 118551465/0 Muffler
52 118550930/0 Stud Bolt
53 118551466/0 Muffler Guard
54 118550806/0 Nut
Lawnmower AL5 51 SAQ - 2L0536844/A21 Engine - Piston, Crankshaft pag.11
1 118550336/0 Nut
2 118550905/0 Flywheel Ass.Y
3 118551277/0 Bolt
4 112791500/0 Screw
5 118551486/0 Flywheel Brake/Stop Switch Assy
6 118551522/0 Spring
7 118550300/0 Oil Seal
13 118551484/0 Crankshaft
14 118550288/0 Woodruff Key
16 118551448/0 Camshaft Assy
18 112789000/0 Screw
19 118551460/0 Speed Governor Assy
22 118550935/0 Oil Seal
23 118550856/0 Cotter Pin
24 118550379/0 Oil Seal
25 118552520/0 Crankase
27 112791500/0 Screw
28 118551276/0 Bolt
29 118550891/0 Cover Comp., Head
30 118550892/0 Packing Head Cover
31 118550893/0 Valve Arm Set
32 118550894/0 Plate
33 118550895/0 Retainer
34 118550896/0 Spring
35 118550910/0 Valve Assy, Intake + Exhaust
36 118551449/0 Valve Lifter
37 118551251/0 Push Rod
38 118551485/0 Piston ass.y
39 118551445/0 Piston, Ring Set
40 118550915/0 Piston Pin
41 118550914/0 Washer, Piston Pin
42 118551446/0 Connecting Rod Assy
43 112791500/0 Screw
44 118551444/0 Oil Filler Assy
Lawnmower AL5 51 SAQ - 2L0536844/A21 Engine, Engine Cover pag.12
1 118551442/0 Engine Assembled
11 322055631/0 Grey Cover
12 322055632/0 Hood, Yellow
13 322055628/0 Grey Cover
201 1111-9234-01 Engine oil, SAE 30 - 0,6 L
201 1111-9237-01 Engine oil, 10W-30 - 0,6 L
201 1111-9244-01 Only for Italian Market
201 1111-9244-01 Only for Italian Market
202 1111-9235-01 Engine oil, SAE 30 - 1 L
203 1111-9236-01 Engine oil, SAE 30 - 1,4 L
203 1111-9238-01 Engine oil, 10W-30 - 1,4 L
203 1111-9245-01 Only for Italian Market
203 1111-9245-01 Only for Italian Market
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
AL5 51 SAQ - 2L0536844/A21
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N ALPINA:
STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS

Specific References

New

Download

Alpina AL5 51 SAQ Parts Drawing

Alpina AL5 51 SAQ Parts Drawing

Download (598.88KB)

You might also like

V-Belt for Self Propelled Lawnmower Alpina BL 510 SB
GGP Italy SKU: 135064196/0
V-Belt for Self Propelled Lawnmower Alpina BL 510 SB
V-Belt for Self Propelled Lawnmower Alpina BL 510 SB Original replacement part Alpina, V-Belt for Self Propelled Lawnmowers BL 510 SB (2016) 295546024/A12 - BL 510 SHQ - 295546934/A15-2018. Part for the following products: -  Self...
Last items in stock €9.20
Details
Engine Brake Lever for Self Propelled Lawnmower Alpina AL3 46 B
GGP Italy SKU: 181003363/1
Engine Brake Lever for Self Propelled Lawnmower Alpina AL3 46 B
Engine Brake Lever for Self Propelled Lawnmower Alpina AL3 46 B Original replacement part Alpina, Engine Brake Lever Black From 01-september-2010 for Self Propelled Lawnmower AL3 46 B - AL3 46 G - AL3 46 SG. Part for the following...
AVAILABLE €16.33
Details
Blade Boss for Petrol Lawnmower Alpina AL3 46 SBQ
GGP Italy SKU: 122465607/4
Blade Boss for Petrol Lawnmower Alpina AL3 46 SBQ
Blade Boss for Petrol Lawnmower Alpina AL3 46 SBQ Original replacement part Alpina, Blade Boss, Crankshaft Ø 22,2mm for Petrol Lawnmowers AL3 46 SBQ - NTL 534 WTR/Q - BL 460 SB - AL3 51 SBQ. Part for the following products: -  Petrol...
AVAILABLE €9.20
Details
Woodruff Key for Petrol Lawnmower Alpina AL3 46 SBQ
GGP Italy SKU: 112139100/0
Woodruff Key for Petrol Lawnmower Alpina AL3 46 SBQ
Woodruff Key for Petrol Lawnmower Alpina AL3 46 SBQ Original replacement part Alpina, Woodruff Key 4x6,5 D.16 UNI6606 C40 for Petrol Lawnmowers AL3 46 SBQ - NTL 534 WTR/Q - BL 460 SB - AL3 51 SBQ....
on 7/10 Business Days Approx. €2.09
Details
Mulching Blade for Lawnmower Alpina BL 510 SB
GGP Italy SKU: 181004459/0
Mulching Blade for Lawnmower Alpina BL 510 SB
Mulching Blade for Lawnmower Alpina BL 510 SB Original replacement part Alpina, Mulching Blade CR53 for Self Propelled Lawnmower BL 510 SB - BL 510 SHQ. Part for the following products: -  Self Propelled Lawnmower BL 510 SB -  Self...
Usually Ships in: 10 Business Days Approx. €18.86
Details
Seeger D.12 for Self Propelled Lawnmower Alpina BL 510 SHQ
GGP Italy SKU: 112608600/0
Seeger D.12 for Self Propelled Lawnmower Alpina BL 510 SHQ
Seeger D.12 for Self Propelled Lawnmower Alpina BL 510 SHQ Original replacement part Alpina,Seeger D.12 for Self Propelled Lawnmowers BL 510 SHQ - BL 510 SB (2016) 295546024/A12 - Season 2016. Part for the following products: -  Self...
AVAILABLE €1.58
Details
Inner wheel Cover for Lawnmower Alpina BL 510 SHQ
GGP Italy SKU: 322600240/0
Inner wheel Cover for Lawnmower Alpina BL 510 SHQ
Inner wheel Cover for Lawnmower Alpina BL 510 SHQ Original part Alpina, Inner wheel Cover d.280MM, for Self-Propelled Lawnmower BL 510 SHQ - AL3 51 SBQ - AL4 51 SBQ - BL 510 SBQ. Part for the following products: -  Self-Propelled...
on 7/10 Business Days Approx €5.77
Details
Telf-Form Screw 3/8"x 1"1/4 for Lawnmower Alpina BL 510 SHQ
GGP Italy SKU: 112735108/1
Telf-Form Screw 3/8"x 1"1/4 for Lawnmower Alpina BL 510 SHQ
Telf-Form Screw 3/8"x 1"1/4 for Lawnmower Alpina BL 510 SHQ Original part Alpina, Telf-Form Screw 3/8"x 1"1/4 UNC I.F., for Self-Propelled Lawnmower BL 510 SHQ - AL3 51 SBQ - AL4 51 SBQ - BL 510 SBQ. Part for the following products: -...
on 7/10 Business Days Approx €2.19
Details
Cable Plate for Lawn Mower DINO 47
GGP Italy SKU: 322551685/0
Cable Plate for Lawn Mower DINO 47
Cable Plate for Lawn Mower DINO 47 Original spare part Alpina, Cable Plate ø22 From S/N 20AA2WBH066504 for Lawn Mower DINO 47 - BL 450. Parts for the following products: -  LAWNMOWER CASTELGARDEN XC 48 GSW4 - L AWNMOWER ALPINA BL 460...
on 7/10 Business Days Approx €7.97
Details
Axle Bush for Self Propelled Lawnmower Alpina BL 510 SB
GGP Italy SKU: 322042067/0
Axle Bush for Self Propelled Lawnmower Alpina BL 510 SB
Axle Bush for Self Propelled Lawnmower Alpina BL 510 SB Original replacement part Alpina, Rear Wheels Axle Bush TR CRUISER for Self Propelled Lawnmowers BL 510 SB - BL 510 SHQ - AL3 51 SBQ....
Usually Ships in: 7/10 Business Days Approx. €4.10
Details
Hex-Head Screw 3/8" X 2" for Lawnmowers Alpina - Stiga
GGP Italy SKU: 112735698/0
Hex-Head Screw 3/8" X 2" for Lawnmowers Alpina - Stiga
Hex-Head Screw 3/8" X 2" for Lawnmowers Alpina - Stiga Original replacement part Alpina, Hex-Head Screw 3/8" X 2" for Lawnmowers Alpina - Stiga - Mountfield - Castelgarden - ATCO. Part for the following products: -  Self Propelled...
AVAILABLE €1.92
Details
Alpina TB 32 Support Transmission Assy Yellow
GGP Italy SKU: 383785001/0
Alpina TB 32 Support Transmission Assy Yellow
Alpina TB 32 Support Transmission Assy Yellow Original replacement part Alpina, Support Transmission Assy Yellow for Brushcutters Alpina TB32 - TB32D. Part for the following products: -  Brushcutter Alpina TB...
AVAILABLE €49.14
Details
Alpina Washer M 10 for BL 510 SHQ
GGP Italy SKU: 112523080/0
Alpina Washer M 10 for BL 510 SHQ
Alpina Washer M 10 for Lawnmower BL 510 SHQ Original part Alpina, Washer M 10 - 11 x 30 x 2,5 for Lawnmowers BL 510 SHQ - BL 410 - AL3 46 G - AL5 51 G. Part for the following products: -  Traction Lawnmower BL 510 SHQ BL 510 SHQ...
AVAILABLE €1.59
Details
Alpina Conveyor for BL 510 SHQ
GGP Italy SKU: 322108309/1
Alpina Conveyor for BL 510 SHQ
Alpina Conveyor for Lawnmower BL 510 SHQ Original part Alpina, Black Rear Conveyor for Lawnmowers BL 510 SHQ - AL3 46 SBQ - FL 46 SQH. Part for the following products: -  Lawnmower Alpina BL 510 SHQ - 295546934 - ...
Last items in stock €11.56
Details
Alpina Rod Pin for BL 510 SHQ
GGP Italy SKU: 122519823/0
Alpina Rod Pin for BL 510 SHQ
Alpina Rod Pin for Lawnmower BL 510 SHQ Original part Alpina, Wheel Control Rod Pin for Lawnmowers BL 510 SHQ - AL3 51 SBQ. Part for the following products: -  Lawnmower Alpina BL 510 SHQ - 295546934 -  Lawnmower Alpina...
AVAILABLE €2.44
Details
Alpina AL3 46 SG Screw
GGP Italy SKU: 112728706/0
Alpina AL3 46 SG Screw
Alpina Lawnower AL3 46 SG Screw Genuine replacement part Alpina, Screw Torx Wn1451 K40X16 for Lawnower AL3 46 SG - AL3 46 SBQ. Part for the following products: -  Lawnower Mountfield S481...
AVAILABLE €1.65
Details
Alpina AL3 46 B Pin
GGP Italy SKU: 122534131/0
Alpina AL3 46 B Pin
Alpina Lawnower AL3 46 B Pin Genuine replacement part Alpina, Rear Rod lever Pin for Lawnower AL3 46 B - AL5 51 G. Part for the following products: -  Lawnmower Alpina AL3 46...
AVAILABLE €1.65
Details
Comments (0)
