Alpina Lawnmower AL4 46 Parts
Lawnmower AL4 46 - 2L0481024/A21 Deck without Brackets pag.1
# Part Num. Description
1 322034002/0 Washing Connection
2 112728450/0 Screw
3 119035000/0 Or Ring
4 322820077/1 Cap
5 322600310/0 Rear door
6 322108329/0 Rear Conveyor
7 112728697/0 Screw
8 322060242/2 Belt Protection
9 112728903/0 Screw
10 322140239/1 Mulching Deflector
10 322140250/0 Mulching Deflector
11 381005027/0 Grey Deck
Lawnmower AL4 46 - 2L0481024/A21 Height Adjusting pag.2
1 381302935/0 Axle, Front Wheels
1 381302935/1 Axle, Front Wheels
2 322785305/1 Support
3 112728697/0 Screw
4 322869733/0 Rod, Height Adjustment
4 322869733/1 Rod, Height Adjustment
5 122519823/0 Pin
6 112436050/0 Plate
7 122450494/0 Spring
8 381302855/1 Rear Wheel Axle
8 381302855/2 Rear Wheel Axle
9 381003356/0 Wheels Rear Adj. Lever
9 381003356/1 Wheels Rear Adj. Lever
10 122534131/0 Pin
11 122446192/0 Spring
12 112154510/0 Nut
13 322785500/0 Support
Lawnmower AL4 46 - 2L0481024/A21 Mask pag.3
1 112735410/0 Screw
2 322226292/0 Mask, Black
3 322393780/0 Front Handle
Lawnmower AL4 46 - 2L0481024/A21 Handle, Lower Part pag.4
1 381007645/0 Handle, Lower Part Black
7 322545189/0 Plate
8 112521350/0 Washer
9 112792611/0 Screw
10 112819121/0 Screw
11 122671651/0 Washer
12 122399900/0 Black Knob
13 381108602/1 Outfit, Screws
Lawnmower AL4 46 - 2L0481024/A21 Handle, Lower Part pag.5
1 381006740/0 Handle, Upper Part
2 112727783/0 Screw
3 322551640/0 Cable Holder
3 322551685/0 Cable Holder ø22
4 118390020/0 Conduit Clip
5 181030056/0 Cable, Thread Engine Brake
6 112154510/0 Nut
7 112154510/0 Nut
8 112521330/0 Washer
9 122430313/0 Guide Spring
10 381003394/0 Lever, Engine Brake Yellow
10 381003394/1 Lever, Engine Brake Yellow
Lawnmower AL4 46 - 2L0481024/A21 Wheel and Hub Cap pag.6
1 381007814/0 Wheel ø200
2 321660100/0 Washer
3 112521350/0 Washer
4 112155000/0 Nut
5 322110643/0 Hub Cap Grey
Lawnmower AL4 46 - 2L0481024/A21 Blade pag.7
1 112735108/1 Screw
2 1111-9168-01 Blade Holder
2 122463012/4 Hub, Crankshaft Ø 22.2
3 1111-9121-02 Blade
3 181004346/3 Left Mulching, Blade
4 122160400/0 Elastic Disc
5 112523080/0 Washer
6 112735698/0 Screw
7 112139100/0 Key
Lawnmower AL4 46 - 2L0481024/A21 Grass-Catcher pag.7
1 322486497/0 Rear door
2 322486496/0 Grass-Box, Upper Part
3 322486150/1 Grass-Box, Right Lower Part
4 322486151/1 Grass-Box, Left Lower Part
5 122450479/0 Spring
6 122517884/0 Pin
7 322600355/1 Stone Guard, Black
8 322109594/0 Stone Guard Support, Black
9 112728697/0 Screw
10 381008735/0 Outfit, Plastic Pin
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
AL4 46 - 2L0481024/A21
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N ALPINA:
STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS

Specific References

New

Download

Alpina AL4 46 Parts Drawing

Alpina AL4 46 Parts Drawing

Download (375.45KB)

You might also like

Woodruff Key for Petrol Lawnmower Alpina AL3 46 SBQ
GGP Italy SKU: 112139100/0
Woodruff Key for Petrol Lawnmower Alpina AL3 46 SBQ
Woodruff Key for Petrol Lawnmower Alpina AL3 46 SBQ Original replacement part Alpina, Woodruff Key 4x6,5 D.16 UNI6606 C40 for Petrol Lawnmowers AL3 46 SBQ - NTL 534 WTR/Q - BL 460 SB - AL3 51 SBQ....
on 7/10 Business Days Approx. €2.09
Details
3 Spoke Handwheel for Lawnmower Alpina FL 46 LMG
GGP Italy SKU: 122399900/0
3 Spoke Handwheel for Lawnmower Alpina FL 46 LMG
3 Spoke Handwheel for Lawnmower Alpina FL 46 LMG Original Part Alpina, 3 Spoke Handwheel (Black) for Lawnmowers Alpina - Castor FL 46 LMG - Mountfield 511 PD - M 462 HP Part for...
on 7/10 Business Days Approx €2.82
Details
Telf-Form Screw 3/8"x 1"1/4 for Lawnmower Alpina BL 510 SHQ
GGP Italy SKU: 112735108/1
Telf-Form Screw 3/8"x 1"1/4 for Lawnmower Alpina BL 510 SHQ
Telf-Form Screw 3/8"x 1"1/4 for Lawnmower Alpina BL 510 SHQ Original part Alpina, Telf-Form Screw 3/8"x 1"1/4 UNC I.F., for Self-Propelled Lawnmower BL 510 SHQ - AL3 51 SBQ - AL4 51 SBQ - BL 510 SBQ. Part for the following products: -...
on 7/10 Business Days Approx €2.19
Details
Cable Plate for Lawn Mower DINO 47
GGP Italy SKU: 322551685/0
Cable Plate for Lawn Mower DINO 47
Cable Plate for Lawn Mower DINO 47 Original spare part Alpina, Cable Plate ø22 From S/N 20AA2WBH066504 for Lawn Mower DINO 47 - BL 450. Parts for the following products: -  LAWNMOWER CASTELGARDEN XC 48 GSW4 - L AWNMOWER ALPINA BL 460...
on 7/10 Business Days Approx €7.97
Details
Hex-Head Screw 3/8" X 2" for Lawnmowers Alpina - Stiga
GGP Italy SKU: 112735698/0
Hex-Head Screw 3/8" X 2" for Lawnmowers Alpina - Stiga
Hex-Head Screw 3/8" X 2" for Lawnmowers Alpina - Stiga Original replacement part Alpina, Hex-Head Screw 3/8" X 2" for Lawnmowers Alpina - Stiga - Mountfield - Castelgarden - ATCO. Part for the following products: -  Self Propelled...
Last items in stock €1.92
Details
Alpina BL 510 SHQ Handle, Upper Part
GGP Italy SKU: 381006740/0
Alpina BL 510 SHQ Handle, Upper Part
Alpina BL 510 SHQ Handle, Upper Part Original spare part Alpina, Handle, Upper Part for Lawnmowers BL 510 SHQ - BL 460 SB - BL410 - BL 510 SB. Part for the following products: -  Lawnmower...
Last items in stock €27.31
Details
Alpina Washer M 10 for BL 510 SHQ
GGP Italy SKU: 112523080/0
Alpina Washer M 10 for BL 510 SHQ
Alpina Washer M 10 for Lawnmower BL 510 SHQ Original part Alpina, Washer M 10 - 11 x 30 x 2,5 for Lawnmowers BL 510 SHQ - BL 410 - AL3 46 G - AL5 51 G. Part for the following products: -  Traction Lawnmower BL 510 SHQ BL 510 SHQ...
AVAILABLE €1.59
Details
Alpina Rod Pin for BL 510 SHQ
GGP Italy SKU: 122519823/0
Alpina Rod Pin for BL 510 SHQ
Alpina Rod Pin for Lawnmower BL 510 SHQ Original part Alpina, Wheel Control Rod Pin for Lawnmowers BL 510 SHQ - AL3 51 SBQ. Part for the following products: -  Lawnmower Alpina BL 510 SHQ - 295546934 -  Lawnmower Alpina...
AVAILABLE €2.44
Details
Alpina AL3 46 B Pin
GGP Italy SKU: 122534131/0
Alpina AL3 46 B Pin
Alpina Lawnower AL3 46 B Pin Genuine replacement part Alpina, Rear Rod lever Pin for Lawnower AL3 46 B - AL5 51 G. Part for the following products: -  Lawnmower Alpina AL3 46...
AVAILABLE €1.65
Details
Comments (0)
