Alpina Spare Parts for Brushcutter BJC 336 (2013)

Name: Alpina Spare Parts for Brushcutter BJC 336 (2013)
Brand: GGP Italy
SKU: BJC336 (2013) 280220001/ALP
Availability: InStock

SKU: BJC336 (2013) 280220001/ALP

€1.41

VAT included

Alpina Spare Parts for Brushcutter BJC 336 (2013)

Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter BJC 336 (2013) 280220001/ALP.

106 spare parts

Page 1 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	118801251/0 Screw	€1.37
2	Image coming soon	118801250/0 Hub	€3.12
5	Image coming soon	118801252/0 Starter Cord	€3.68
6		118804060/0 Starter Spring for Brushcutters Alpina B 32 - B 42	€6.57
9	Image coming soon	118801263/0 Starter Handle	€2.12
10	Image coming soon	118801264/0 Retainer	€1.37
11		118801262/0 Recoil Starter Ass'y for Brushcutter Alpina B33	€27.70
12		2135030 Srew TX M5X20 2009 for Brushcutter Alpina TB 250 J	€1.40
13		118801254/0 Starter Cup Ass'y for Brushcutter Alpina B33	€7.53
17		119035159/0 Seal Ring 12X22X7 for Brushcutter Alpina B33	€1.57
18	Image coming soon	123685026/0 Crank Case	€17.32
19		123280047/0 Engine Housing Gasket for Brushcutter Alpina B33	€2.02
20	Image coming soon	114215218/0 Ball Bearing	€9.79
21		123020025/0 Krank Shaft Ass'y for Brushcutter Alpina B33	€46.78
22		123072002/0 Flywheel Woodruf for Brushcutters Alpina B 26 J-TB 250 J-T 26 J	€1.50
24	Image coming soon	123685027/0 Crank Case	€20.41
25	Image coming soon	2135060 Screw	€1.44
26	Image coming soon	123880018/0 Flywheel REPLACED BY 123880009/0 BUY WITH COIL	€30.27
29	Image coming soon	112154200/0 NUT	€1.37
30		118805187/0 Ignition Coil Assy for Brushcutter Alpina BJC 336	€61.69
32		2135030 Srew TX M5X20 2009 for Brushcutter Alpina TB 250 J	€1.40
35		123430583/0 Clutch Ass'y for Brushcutter Alpina B33	€17.61
37	Image coming soon	123878058/0 Screw	€1.74
53		123235007/0 Needl Bearing for Brushcutter Alpina B33	€2.91
54		123202009/0 Piston Pin Circlip for Brushcutter Alpina B33	€1.44
55		123760007/0 Piston Pin for Brushcutter Alpina B33	€1.44
56		123590008/0 Piston for Brushcutter Alpina B33	€9.20
57		123204010/0 Piston Ring for Brushcutter Alpina B33	€4.24
58		123280045/0 Cylinder Gasket for Brushcutter Alpina B33	€1.58
59		123071024/0 Cylinder for Brushcutter Alpina B33	€39.00
60	Image coming soon	112760475/0 Screw	€2.18
61		3210024 Spark Plug CJ7Y	€4.32
63	Image coming soon	118801258/0 Spark Plug Cover	€4.45
64	Image coming soon	123275023/0 Grommet	€1.37
65	Image coming soon	118801461/0 Cylinder Cover Red	€19.18
67	Image coming soon	118801464/0 Cover Red	€6.08
68	Image coming soon	112788910/0 Screw	€1.65
69		123280041/0 Intake Manifold Gasket for Brushcutter Alpina B33	€2.38
70		123073509/0 Intake Manifold for Brushcutter Alpina B33	€6.50
71		2135030 Srew TX M5X20 2009 for Brushcutter Alpina TB 250 J	€1.40
72		118801227/0 Intake Manifold Gasket for Brushcutter Alpina B33	€1.42
73	Image coming soon	123054025/0 Carburetor	€42.33
74	Image coming soon	118801229/0 Lever	€1.37
76	Image coming soon	123190000/0 Shutter	€1.37
78	Image coming soon	2132160 Screw	€2.13
79		123220011/0 Air Filter for Brushcutter Alpina B33	€3.82
80	Image coming soon	118801298/0 Red filter cover	€13.99
81	Image coming soon	118801267/0 Muffler Gasket	€18.55
83	Image coming soon	183740022/0 Muffler	€55.16
85	Image coming soon	118801256/0 White Cover	€3.68
88		2122210 Muffler Screw M5x62 for Brushcutters Alpina B 26 J-T 26 J	€2.43
89		123280060/0 Rubber Gasket for Brushcutter Alpina B33	€1.44
90	Image coming soon	112788910/0 Screw	€1.65
91		118801265/0 Fuel Tank Ass'y for Brushcutter Alpina B33	€19.81
92	Image coming soon	118801266/0 Lower Guard	€8.95
93		2135030 Srew TX M5X20 2009 for Brushcutter Alpina TB 250 J	€1.40
94	Image coming soon	2135200 Screw	€1.42
95		118801319/0 Fuel Pipe mm 3X1X90 for Brushcutter Alpina B33	€5.53
96		118801318/0 Fuel Pipe Grommet for Brushcutter Alpina B33	€1.44
97		118801313/0 Fuel Pipe mm 3X1X160 for Brushcutter Alpina B33	€3.80
98		183520005/0 Fuel Filter Ass'y for Brushcutter Alpina TB 26	€3.84
99		118801243/0 Fuel Tank Cap Ass'y for Brushcutter Alpina B33	€3.84

Page 2 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1		123050012/0 Clutch Drum for Brushcutter Alpina B33	€15.84
3	Image coming soon	118801261/0 Guard	€3.36
4	Image coming soon	112610800/0 Seeger	€1.73
5	Image coming soon	119216048/0 Bearing	€17.88
6	Image coming soon	112609200/0 Seeger	€1.65
8	Image coming soon	112760475/0 Screw	€2.18
9	Image coming soon	118801260/0 Button	€1.37
10	Image coming soon	118801316/0 Reduction	€4.25
11	Image coming soon	118801311/0 Reduction	€6.70
12	Image coming soon	118801310/0 Support	€11.20
13	Image coming soon	118801309/0 Support	€11.27
14	Image coming soon	2135020 Screw	€1.45
15		2135030 Srew TX M5X20 2009 for Brushcutter Alpina TB 250 J	€1.40
21		183869073/0 Trasmission Shaft + Drive Shaft for Brushcutter Alpina B33	€50.54
22		123020038/0 Drive Shaft for Brushcutter Alpina B33	€17.92
31	Image coming soon	118801337/0 Clamp	€2.28
32	Image coming soon	112789000/0 Screw	€1.77
33	Image coming soon	118801335/0 Safety Lever, Red	€1.37
34	Image coming soon	118801336/0 Throttle Lever, Red	€2.19
35	Image coming soon	118801334/0 Spring	€1.37
36	Image coming soon	118801373/0 Right Handle, Black	€13.68
37	Image coming soon	112735105/0 Screw	€1.67
38	Image coming soon	118801354/0 Throttle Cable	€8.94
40	Image coming soon	118801333/0 Spring	€1.37
41	Image coming soon	118801329/0 Stop Knob,Red	€1.37
43	Image coming soon	118801330/0 Stop Plate	€1.37
44	Image coming soon	118801338/0 Spring	€1.37
45	Image coming soon	118801328/0 Stop Wire	€6.62
46	Image coming soon	118801375/0 Left Handle, Black	€13.68
50	Image coming soon	118801322/0 Earth Cable	€1.37
51	Image coming soon	183780002/0 Harness Support	€3.61
52	Image coming soon	123170004/0 Spacer	€2.84
55	Image coming soon	118801382/0 Handle Grip Assembly, Black	€46.78
71	Image coming soon	118801327/0 Harness	€13.22

Page 3 View exploded Usually Ships in: 10/15 BUSINESS DAYS

Click on the exploded view to buy spare parts

Pos.		Item	Price
1	Image coming soon	183820507/0 Gears Head Assembly	€85.50
6		112727801/0 Screw TCB Torx M6x20 for Lawnmower Cutting Height Adjustment	€1.74
7	Image coming soon	112789000/0 Screw	€1.77
8	Image coming soon	112727794/0 Screw	€1.65
10	Image coming soon	123670002/0 Guard	€3.55
15		123250002/0 Upper Ring Nut for Brushcutter Alpina B33	€5.97
16		123250003/0 Lower Ring Nut for Brushcutter Alpina B33	€5.97
18	Image coming soon	123120015/0 Left Nut	€1.60
21		123784012/0 Safety Guard Support for Brushcutter Alpina TB 26	€8.32
22		2135050 Srew TX M5X30 2009 for Brushcutter Alpina TB 250 J	€1.33
23	Image coming soon	2135180 Screw	€1.40
24		118801341/0 Safety Guard for Brushcutter Alpina B33	€20.21
25	Image coming soon	112735654/0 Screw	€1.26
27	Image coming soon	112728099/1 Screw	€1.65
28		123311013/0 Safety Guard Line Cutter Blade for Brushcutter Alpina B33	€3.84
31		123155009/0 Head Tap & Go M10X1,25 for Brushcutters ALPINA	€20.66
32	Image coming soon	123155010/0 3 Teeth Disc	€8.71

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Alpina Spare Parts for Brushcutter BJC 336 (2013)

Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center

and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter BJC 336 (2013) 280220001/ALP.

In the following table, look for the model of the Brushcutter and the respective parts of the code.

ALPINA BJC 336 (2013) 280220001/ALP - Engine Pag.1
#	Part Num.	Description
1	118801251/0	Screw
2	118801250/0	Hub
4	118801249/0	Starter Pulley
5	118801252/0	Starter cord
6	118804060/0	Spring
9	118801263/0	Starter Handle
10	118801264/0	Retainer
11	118801262/0	Starter Ass.Y Black
12	2135030	Screw
13	118801254/0	Starter Cup Ass.Y
17	119035159/0	Seal Ring
18	123685026/0	Crank Case
19	123280047/0	Crankcase Gasket
20	114215218/0	Ball Bearing
21	123020025/0	Crankshaft
22	123072002/0	Flywheel Key
24	123685027/0	Crank Case
25	2135060	Screw
26	123880018/0	Flywheel
29	112154200/0	Nut
30	118805187/0	Ignition Coil
32	2135030	Screw
35	123430583/0	Clutch Unit
37	123878058/0	Screw
53	123235007/0	Needle Bearing
54	123202009/0	Circlip
55	123760007/0	Piston Pin
56	123590008/0	Piston
57	123204010/0	Piston Ring
58	123280045/0	Cylinder Gasket
59	123071024/0	Cylinder
60	112760475/0	Screw
61	3210024	Spark Plug
63	118801258/0	Spark Plug Cover
64	123275023/0	Grommet
65	118801461/0	Red Cylinder Cover
67	118801464/0	Red Cover
68	112788910/0	Screw
69	123280041/0	Intake Manifold Gasket
70	123073509/0	Intake Manifold
71	2135030	Screw
72	118801227/0	Carburetor Gasket
73	123054025/0	Carburetor
74	118801229/0	Lever
75	118801228/0	Air Filter Support + Cover
76	123190000/0	Shutter
78	2132160	Screw
79	123220011/0	Air Filter
80	118801298/0	Filter Cover Red
81	118801267/0	Muffler Gasket
83	183740022/0	Muffler
85	118801256/0	White Cover
88	2122210	Screw
89	123280060/0	Rubber Gasket
90	112788910/0	Screw
91	118801265/0	Fuel Tank
92	118801266/0	Lower Guard
93	2135030	Screw
94	2135200	Screw
95	118801319/0	Tube
96	118801318/0	Grommet
97	118801313/0	Fuel Line
98	183520005/0	Intake Filter
99	118801243/0	Fuel Tank-Cap Ass.Y
Handle-Trasmission Pag.2
1	123050012/0	Clutch Drum Assy
2	2122080	Screw
3	118801261/0	Guard
4	112610800/0	Seeger
5	119216048/0	Bearing
6	112609200/0	Seeger
7	118801259/0	Clutch Case
8	112760475/0	Screw
9	118801260/0	Button
10	118801316/0	Reduction
11	118801311/0	Reduction
12	118801310/0	Support
13	118801309/0	Support
14	2135020	Screw
15	2135030	Screw
21	183869073/0	Assy Transm. Tube+Flex
22	123020038/0	Trasmission Shaft
31	118801337/0	Clamp
32	112789000/0	Screw
33	118801335/0	Safety Lever, Red
34	118801336/0	Throttle Lever, Red
35	118801334/0	Spring
36	118801373/0	Right Handgrip,Black
37	112735105/0	Screw
38	118801354/0	Throttle Cable
40	118801333/0	Spring
41	118801329/0	Stop Knob,Red
43	118801330/0	Stop Plate
44	118801338/0	Spring
45	118801328/0	Stop Wire
46	118801375/0	Left Handgrip,Black
50	118801322/0	Stop Wire Adapter
51	183780002/0	Harness Support
52	123170004/0	Spacer
55	118801382/0	Front Handle Assy, Black
71	118801327/0	Harness
Gear Case Pag.3
1	183820507/0	Gear case assy
6	112727801/0	Screw
7	112789000/0	Screw
8	112727794/0	Screw
10	123670002/0	Guard
15	123250002/0	Upper Ring Nut
16	123250003/0	Lower Ring Nut
18	123120015/0	Nut
21	123784012/0	Support
22	2135050	Screw
23	2135180	Screw
24	118801341/0	Safety Cover, Black
25	112735654/0	Screw
26	118801342/0	Guard, Black
27	112728099/1	Screw
28	123311013/0	Line Cutter Blade
31	123155009/0	2 Hedges Nylon Head
32	123155010/0	3 Teeth Disc

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.

Reference BJC336 (2013) 280220001/ALP

Available 12 Items

Data sheet

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N ALPINA:: STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS

Specific References

Condition New

Download

Diagram Alpina BJC 336 (2013)

Download (585KB)

GGP Italy SKU: 123204010/0

Piston Ring for Brushcutter Alpina B33

Piston Ring for Brushcutter Alpina B33 Original replacement part Alpina, Piston Ring for Brushcutter Alpina B33 - TB 34 Model Year 2012 - AIPL2012_20100803_TB34. Part for the following products: - Brushcutter...

AVAILABLE €4.24

Cart (0)

Subcategories

Subcategories

Subcategories

Power Tools Spare Parts

Garden Spare Parts

Air Compressor Spare Parts

Protezione & Edilizia

Impianti & Utensili

Casa & Giardino

Alpina Spare Parts for Brushcutter BJC 336 (2013)

Alpina Spare Parts for Brushcutter BJC 336 (2013)

Alpina Spare Parts for Brushcutter BJC 336 (2013)

Alpina Spare Parts for Brushcutter BJC 336 (2013)

Alpina Spare Parts for Brushcutter BJC 336 (2013)

Data sheet

Specific References

Download

Diagram Alpina BJC 336 (2013)

You might also like
