Alpina Spare Parts for Battery Chain Saw AC 24 B

SKU: AC 24 B - 274100124/A17-2018
€3.78
VAT included

Alpina Spare Parts for Battery Chain Saw AC 24 B

Alpina genuine spare parts or replacement parts for to repair Battery Chain Saw AC 24 B - 274100124/A17-2018.

Light and compact cordless saw, suitable for precision work. Electric saw in the Alpina Catalog 2018.
24 V battery power supply
25 cm (10 ") cutting bar
Net weight without bar and chain of 2.7 kg
Alpina Spare Parts for Battery Chain Saw AC 24 B
  • Alpina Spare Parts for Battery Chain Saw AC 24 B
  • Alpina Spare Parts for Battery Chain Saw AC 24 B
  • Alpina Spare Parts for Battery Chain Saw AC 24 B

Alpina Spare Parts for Battery Chain Saw AC 24 B

SKU: AC 24 B - 274100124/A17-2018 Condition: New
€3.78
VAT included

Alpina Spare Parts for Battery Chain Saw AC 24 B

Alpina genuine spare parts or replacement parts for to repair Battery Chain Saw AC 24 B - 274100124/A17-2018.

Light and compact cordless saw, suitable for precision work. Electric saw in the Alpina Catalog 2018.
24 V battery power supply
25 cm (10 ") cutting bar
Net weight without bar and chain of 2.7 kg
settings 35 spare parts
description 1 exploded view
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10/15 Business Days Approx

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N ALPINA:: STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

35 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 323085000/0 Chain Cover €25.35
3
photo_cameraImage coming soon 118803822/0 Gray Handgrip €3.49
6
Bar 10” (25 cm) 3/8” .050” (1.3 mm) for Chainsaw Alpina A 305 123900360/0 Bar 10” (25 cm) 3/8” .050” (1.3 mm) for Chainsaw Alpina A 305 €16.90
7
photo_cameraImage coming soon 112581500/0 Grower €1.74
9
photo_cameraImage coming soon 112727810/0 Screw €1.79
10
photo_cameraImage coming soon 118803310/0 Clamp €1.24
11
photo_cameraImage coming soon 3353050 Seeger ring €1.76
12
photo_cameraImage coming soon 118810453/0 Toothed Wheel €3.51
14
photo_cameraImage coming soon 118810613/0 Gear Shaft €2.87
15
photo_cameraImage coming soon 118803297/0 Gear €1.42
23
photo_cameraImage coming soon 118810591/0 Oil tank €3.98
31
photo_cameraImage coming soon 118810651/0 Ring €1.42
33
photo_cameraImage coming soon 118810585/0 Plate €1.76
35
photo_cameraImage coming soon 2123210 SCREW €3.38
39
photo_cameraImage coming soon 118810587/0 Gear €5.38
42
photo_cameraImage coming soon 112727790/0 Screw €1.74
43
photo_cameraImage coming soon 118810622/0 Gear €5.51
44
photo_cameraImage coming soon 118810623/0 Gear €6.76
45
photo_cameraImage coming soon 118810590/0 Guard €5.79
46
photo_cameraImage coming soon 118810582/0 Shaft €3.30
47
photo_cameraImage coming soon 112728523/0 Screw €1.70
54
photo_cameraImage coming soon 118810620/0 Shaft €5.93
55
photo_cameraImage coming soon 118804136/0 Ball Bearing €5.66
56
photo_cameraImage coming soon 118810578/0 Box cover €11.89
57
photo_cameraImage coming soon 118810588/0 Cam €3.02
60
photo_cameraImage coming soon 118803325/0 Oil Pipe €1.24
70
photo_cameraImage coming soon 118810608/0 Black Oil Cap Assy €2.74
71
photo_cameraImage coming soon 118810603/0 Cap Black Chain €10.30
74
photo_cameraImage coming soon 118810643/0 Carter, Gray Assy €45.90
75
photo_cameraImage coming soon 118810605/0 Black Switch Assy €5.09
76
photo_cameraImage coming soon 118810606/0 Electrical circuit €73.67
78
photo_cameraImage coming soon 118810607/0 Oil Pump Assy €8.56
79
photo_cameraImage coming soon 118810609/0 Handle Assy €14.74
82
photo_cameraImage coming soon 118810755/0 Engine-Gears Assy €68.81
83
photo_cameraImage coming soon 118810756/0 Gray Clutch Cover Assy €26.96

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Alpina Spare Parts for Battery Chain Saw AC 24 B

Alpina genuine spare parts or replacement parts for to repair Battery Chain Saw AC 24 B - 274100124/A17-2018.

Light and compact cordless saw, suitable for precision work. Electric saw in the Alpina Catalog 2018.
24 V battery power supply
25 cm (10 ") cutting bar
Net weight without bar and chain of 2.7 kg

In the following table, look for the model of the Battery Saw and the respective parts of the code.


Battery Chain Saw AC 24 B
1 323085000/0 Chain Bar cover
2 1430140-01A Chain 10 "-3/8" -0.050 "-40E
3 118803822/0 Gray Handgrip
6 123900360/0 Bar 10"-3/8" -0.050"
7 112581500/0 Grower
8 118803808/0 Gray Handgrip
9 112727810/0 Screw
10 118803310/0 Clamp
11 3353050 Seeger ring
12 118810453/0 Cogwheel
14 118810613/0 Shaft
15 118803297/0 Gear
23 118810591/0 Oil tank
31 118810651/0 Ring
32 118810517/0 Connector
33 118810585/0 Plate
35 2123210 Screw
38 118810638/0 Engine
39 118810587/0 Gear
42 112727790/0 Screw
43 118810622/0 Gear
44 118810623/0 Gear
45 118810590/0 Protection
46 118810582/0 Shaft
47 112728523/0 Screw
53 118810616/0 Ring
54 118810620/0 Shaft
55 118804136/0 Ball Bearing
56 118810578/0 Box cover
57 118810588/0 Cam
59 118810565/0 PCB
60 118803325/0 Oil Pipe
61 118810615/0 Washer
63 118810602/0 Ring
70 118810608/0 Black Oil Cap Assy
71 118810603/0 Cap Black Chain
74 118810643/0 Carter, Gray Assy
75 118810605/0 Black Switch Assy
76 118810606/0 Electrical circuit
78 118810607/0 Oil Pump Assy
79 118810609/0 Handle
82 118810755/0 Engine-Gears Assy
83 118810756/0 Gray Clutch Cover Assy
1 270201020/17 24V battery - 2Ah
1 270401020/17 24V battery - 4Ah
2 270012020/17 Battery Charger 24V - EU + BS plug
