Alpina Spare Parts for Battery Lawn Mower BL 340 Li

SKU: BL340Li-294345064/A19-2019
€1.72
VAT included

Alpina Spare Parts for Battery Lawn Mower BL 340 Li

Alpina Genuine spare parts or replacement parts for to fix Battery Lawn Mower BL 340 Li/294345064/A19-2019.

Battery Lawn Mower BL 340 Li/294345064/A19-2019
Alpina Spare Parts for Battery Lawn Mower BL 340 Li
  • Alpina Spare Parts for Battery Lawn Mower BL 340 Li
  • Alpina Spare Parts for Battery Lawn Mower BL 340 Li
  • Alpina Spare Parts for Battery Lawn Mower BL 340 Li
  • Alpina Spare Parts for Battery Lawn Mower BL 340 Li
  • Alpina Spare Parts for Battery Lawn Mower BL 340 Li
  • Alpina Spare Parts for Battery Lawn Mower BL 340 Li

Alpina Spare Parts for Battery Lawn Mower BL 340 Li

SKU: BL340Li-294345064/A19-2019 Condition: New
€1.72
VAT included

Alpina Spare Parts for Battery Lawn Mower BL 340 Li

Alpina Genuine spare parts or replacement parts for to fix Battery Lawn Mower BL 340 Li/294345064/A19-2019.

Battery Lawn Mower BL 340 Li/294345064/A19-2019
settings 77 spare parts
description 5 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
on 10/15 Business Days Approx

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N ALPINA:: STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

66 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 322066759/0 Gray Chassis €50.53
1
photo_cameraImage coming soon 322066782/0 Deck STIGA Grey €50.53
2
photo_cameraImage coming soon 322785426/0 Wheel Support €2.88
2
photo_cameraImage coming soon 322785448/0 Support, Wheel €2.88
3
photo_cameraImage coming soon 322686107/0 Wheel €5.15
4
Avio Hub Cap for Corded Lawn Mower BL 340 EP 322110721/0 Avio Hub Cap for Corded Lawn Mower BL 340 EP €2.74
5
photo_cameraImage coming soon 112604903/0 Washer €1.54
6
photo_cameraImage coming soon 122033422/0 Axle, Wheels €6.22
7
photo_cameraImage coming soon 322545142/0 Plate €1.66
8
photo_cameraImage coming soon 112728714/0 Screw €1.37
9
Alpina AL1 34 E Height Adjust Lever 322785430/0 Alpina AL1 34 E Height Adjust Lever €5.66
10
Alpina Lawnmower AL1 34 E Pin 322524354/0 Alpina Lawnmower AL1 34 E Pin €1.59
11
photo_cameraImage coming soon 122450425/0 Spring €2.81
12
photo_cameraImage coming soon 322869687/0 Height Adjustment Control Rod €5.66
12
photo_cameraImage coming soon 322869689/0 Rod, Height Adjustment €5.66
13
photo_cameraImage coming soon 322785415/0 Plate €1.37
14
photo_cameraImage coming soon 122033422/0 Axle, Wheels €6.22
15
photo_cameraImage coming soon 322785429/0 Wheel Support €2.44
15
Alpina AL1 34 E Wheel Support 322785437/0 Alpina AL1 34 E Wheel Support €2.26
16
photo_cameraImage coming soon 322686106/0 Wheel €4.52
17
photo_cameraImage coming soon 322110685/0 Gray hubcap €1.37
18
photo_cameraImage coming soon 322785447/0 Support, Wheel €1.34
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 322055252/0 Front Plate €1.74
3
photo_cameraImage coming soon 112728714/0 Screw €1.37
5
photo_cameraImage coming soon 322393668/0 Handle €2.76
6
photo_cameraImage coming soon 122450250/0 Spring €1.38
7
photo_cameraImage coming soon 122512603/0 Pin €1.75
9
photo_cameraImage coming soon 322486392/0 Grass-Box, R Lower €13.54
10
photo_cameraImage coming soon 322486391/0 Grass-Box, L Lower €13.54
11
photo_cameraImage coming soon 322486358/0 Bag, Upper side €10.70
12
photo_cameraImage coming soon 322393718/0 Handle €3.58
16
photo_cameraImage coming soon 322140241/0 Mulching Plug €7.17
20
photo_cameraImage coming soon 322076570/1 Key Security Battery €5.39
22
photo_cameraImage coming soon 322055167/0 Cover €9.25
23
photo_cameraImage coming soon 122450473/0 Spring €1.87
24
photo_cameraImage coming soon 322600271/0 Holdere stone guard Black €1.87
25
photo_cameraImage coming soon 122450472/0 Spring €1.50
26
photo_cameraImage coming soon 322524355/0 Pin €1.56
27
photo_cameraImage coming soon 118210028/0 Security Key Kit €38.43
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Pos. Item Price Buy
1
photo_cameraImage coming soon 322291064/0 Upper Half handle €6.46
1
photo_cameraImage coming soon 322291068/0 Upper Half Handgrip Switch €10.45
2
photo_cameraImage coming soon 381600540/0 Motor protection €20.47
2
photo_cameraImage coming soon 381600540/1 Motor protection €29.86
3
photo_cameraImage coming soon 322291065/0 Lower Half handle €6.46
3
photo_cameraImage coming soon 322291069/0 Lower Half Handgrip Switch €10.13
4
photo_cameraImage coming soon 112728713/0 Screw €1.37
5
photo_cameraImage coming soon 381007532/0 Handle, Upper Part €5.66
6
photo_cameraImage coming soon 122192000/1 Clamp €1.62
7
photo_cameraImage coming soon 112523050/0 Washer €2.05
8
photo_cameraImage coming soon 122524352/0 Pin €3.41
9
photo_cameraImage coming soon 322319519/0 Fixing Lever Handle €2.37
9
photo_cameraImage coming soon 322319519/1 Fixing Lever Handle €2.06
10
photo_cameraImage coming soon 122943016/0 Screw €1.49
18
photo_cameraImage coming soon 118566116/0 Cap €2.07
19
photo_cameraImage coming soon 381007529/0 Right Handle, Lower Part €6.60
20
photo_cameraImage coming soon 381007530/0 Left Handle, Lower Part €6.48
21
photo_cameraImage coming soon 112728450/0 Screw €1.72
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Pos. Item Price Buy
1
Blade Boss Hub Bolt for Lawnmower Alpina AL1 38 E 381004352/1 Blade Boss Hub Bolt for Lawnmower Alpina AL1 38 E €3.90
2
photo_cameraImage coming soon 181004159/0 Blade €12.46
3
photo_cameraImage coming soon 322465653/0 Knife Hub €3.77
4
photo_cameraImage coming soon 112728699/0 Screw €1.66
5
photo_cameraImage coming soon 322207230/0 Flange €5.72
6
photo_cameraImage coming soon 118563515/0 Motor Battery €146.91
7
photo_cameraImage coming soon 118206003/0 Controller €142.55
7
photo_cameraImage coming soon 118206008/0 Controller €142.55
8
photo_cameraImage coming soon 112728714/0 Screw €1.37
Page 5 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
info_outline

No spare parts mapped to this page.
Check the other pages for available parts.

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

Alpina Spare Parts for Battery Lawn Mower BL 340 Li

Alpina Genuine spare parts or replacement parts for to fix Battery Lawn Mower BL 340 Li/294345064/A19-2019.

In the following table, look for the model of the Electric Lawn Mower and the respective parts of the code.
Battery Lawn Mower BL 340 Li/294345064/A19-2019

Battery Lawn Mower BL 340 Li/294345064/A19-2019 Spare Parts
Chassis Height Adjustment Pag.1
# Part Num. Description
1 322066759/0 Gray Chassis
1 322066782/0 Gray STIGA Chassis
2 322785426/0 Wheel Support
2 322785448/0 Wheel Support
3 322686107/0 Wheel
4 322110721/0 Avio hub cap
5 112604903/0 Washer
6 122033422/0 Axle Wheels
7 322545142/0 Plate
8 112728714/0 Screw
9 322785430/0 Height Adjustment Lever
10 322524354/0 Pin
11 122450425/0 Spring
12 322869687/0 Height Adjustment Control Rod
12 322869689/0 Height Adjustment Control Rod
13 322785415/0 Plate
14 122033422/0 Axle Wheels
15 322785429/0 Wheel Support
15 322785437/0 Wheel Support
16 322686106/0 Wheel
17 322110685/0 Gray hubcap
18 322785428/0 Wheel Support
18 322785447/0 Wheel Support
Chassis Pag.2
1 322055252/0 Front plate
2 381119727/0 Black Cover
3 112728714/0 Screw
5 322393668/0 Handle
6 122450250/0 Spring
7 122512603/0 Pin
8 322600270/0 Stoneguard Black
9 322486392/0 Bag, Right lower side
10 322486391/0 Bag, Left lower side
11 322486358/0 Bag, Upper side
12 322393718/0 Handle
16 322140241/0 Mulching cap
20 322076570/1 Key Security Battery
21 322545226/0 Plate
22 322055167/0 Cover
23 122450473/0 Spring
24 322600271/0 Black Stoneguard holder
25 122450472/0 Spring
26 322524355/0 Pin
27 118210028/0 Security Key Kit
Handle, Upper Side Pag.3
1 322291064/0 Upper Half handle
1 322291064/1 Upper Half handle
1 322291068/0 Upper Half handle
2 381600540/0 Motor protection
2 381600540/1 Motor protection
2 381600561/0 Motor protection
3 322291065/0 Lower Half handle
3 322291069/0 Lower Half handle
4 112728713/0 Screw
5 381007532/0 Handle, Upper Side
6 122192000/1 Cable clamp
7 112523050/0 Washer
8 122524352/0 Pin
9 322319519/0 Lever
9 322319519/1 Lever
10 122943016/0 Screw
18 118566116/0 Pin
19 381007529/0 Handle, Black right lower side
20 381007530/0 Handle, Black right lower side
21 112728450/0 Screw
Blade Pag.4
1 381004352/1 Screw
2 181004159/0 Blade
3 322465653/0 Knife Hub
4 112728699/0 Screw
5 322207230/0 Flange
6 118563515/0 Motor Battery
6 118563515/1 Motor Battery
6 118563515/2 Motor Battery
7 118206003/0 Controller
7 118206008/0 Controller
8 112728714/0 Screw
Battery Pag.5
1 270482010/A15 Battery 48V - 2Ah
1 270484010/A15 Battery 48V - 2Ah
2 270480020/A15 Battery Charger 48V - EU
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
BL340Li-294345064/A19-2019
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N ALPINA:
STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS

Specific References

New

Download

Diagram Alpina BL 340 Li

Diagram Alpina BL 340 Li

Download (617.59KB)
