Alpina Spare Parts for Electric Lawn Mower AL1 38 E

SKU: AL1 38 E 294380060-A12-2017
€1.74
VAT included

Alpina Spare Parts for Electric Lawn Mower AL1 38 E

ALPINA Original spare parts at attractive and competitive prices on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Electric Lawn Mower AL1 38 E/294380060-A12-2017.

AL1 38 E 294380060-A12-2017
Alpina Spare Parts for Electric Lawn Mower AL1 38 E
  • Alpina Spare Parts for Electric Lawn Mower AL1 38 E
  • Alpina Spare Parts for Electric Lawn Mower AL1 38 E
  • Alpina Spare Parts for Electric Lawn Mower AL1 38 E
  • Alpina Spare Parts for Electric Lawn Mower AL1 38 E
  • Alpina Spare Parts for Electric Lawn Mower AL1 38 E
GGP Italy

Alpina Spare Parts for Electric Lawn Mower AL1 38 E

SKU: AL1 38 E 294380060-A12-2017 Condition: New
€1.74
VAT included

Alpina Spare Parts for Electric Lawn Mower AL1 38 E

ALPINA Original spare parts at attractive and competitive prices on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Electric Lawn Mower AL1 38 E/294380060-A12-2017.

AL1 38 E 294380060-A12-2017
settings 85 spare parts
description 4 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Shipped on: 10/15 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10/15 BUSINESS DAYS
CHECK ITEM CODE OR S/N:: CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N ALPINA:: STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
85 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 322066760/0 Gray Chassis €75.88
1
 photo_cameraImage coming soon 322066783/0 Deck STIGA Grey €82.55
2
 photo_cameraImage coming soon 322785387/0 Wheel Support €1.90
2
 photo_cameraImage coming soon 322785450/0 Support, Wheel €1.99
3
 photo_cameraImage coming soon 322686105/0 Wheel €8.33
4
 photo_cameraImage coming soon 322110684/0 Hub Cap Grey €3.70
5
 photo_cameraImage coming soon 112604903/0 Washer €1.54
6
 photo_cameraImage coming soon 122033425/0 Rear Wheel Axle €8.44
7
 photo_cameraImage coming soon 322545142/0 Plate €1.66
8
 photo_cameraImage coming soon 112728714/0 Screw €1.37
9
 photo_cameraImage coming soon 322785414/0 Height Adjustment Lever €13.69
9
 photo_cameraImage coming soon 322785414/1 Lever, Height Adjustment From 01-September 2012 To 31-August 2017 €23.16
9
 photo_cameraImage coming soon 322785414/2 Lever, Height Adjustment €13.35
10
 Alpina Lawnmower AL1 34 E Pin 322524354/0 Alpina Lawnmower AL1 34 E Pin €1.59
11
 photo_cameraImage coming soon 122446195/0 Spring €2.76
12
 photo_cameraImage coming soon 322869680/0 Height Adjustment Control Rod €8.28
12
 Alpina AL1 38 E Height Adjust Rod Grey 322869690/0 Alpina AL1 38 E Height Adjust Rod Grey €8.85
13
 photo_cameraImage coming soon 322785415/0 Plate €1.37
14
 photo_cameraImage coming soon 122033424/0 Rear Wheel Axle €8.44
15
 photo_cameraImage coming soon 322785386/0 Support, Wheel to 31-August 2014 €3.17
15
 photo_cameraImage coming soon 322785438/0 Support, Wheel from 01-September-2014 €2.97
16
 photo_cameraImage coming soon 322686104/0 Wheel €5.33
17
 photo_cameraImage coming soon 322110683/0 Hub Cap Grey €1.44
18
 photo_cameraImage coming soon 322785385/0 Wheel Support €1.64
18
 photo_cameraImage coming soon 322785449/0 Support, Wheel €1.58
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 322055158/0 White Cover €17.06
2
 photo_cameraImage coming soon 322109565/0 Left Side Cover €6.17
2
 photo_cameraImage coming soon 322109856/0 Left Side Cover €4.55
3
 photo_cameraImage coming soon 322109854/0 Right Side Cover €4.55
3
 photo_cameraImage coming soon 322109899/0 Right Side Cover €10.65
4
 photo_cameraImage coming soon 322393658/0 Cover €4.77
4
 photo_cameraImage coming soon 322393720/0 Handle €6.37
5
 photo_cameraImage coming soon 322393659/0 Handle, Lower Part €6.61
6
 photo_cameraImage coming soon 122450470/0 Spring €2.00
7
 photo_cameraImage coming soon 322524356/0 Pin €1.66
8
 photo_cameraImage coming soon 322600242/0 Safe Guard €15.24
8
 photo_cameraImage coming soon 322600288/0 Stone Guard, Grey €14.78
9
 photo_cameraImage coming soon 322486293/0 Bag Lower Side Right €17.33
9
 photo_cameraImage coming soon 322486393/0 Grass-Box, Right Lower Part €22.31
10
 photo_cameraImage coming soon 322486294/0 Bag Lower Side Left €17.33
10
 photo_cameraImage coming soon 322486394/0 Grass-Box, Left Lower Part €21.56
11
 photo_cameraImage coming soon 322486308/0 Grass-Box, Upper Part €12.36
12
 photo_cameraImage coming soon 322393656/0 Handle €3.05
13
 photo_cameraImage coming soon 322140242/0 Mulching Plug €12.91
14
 photo_cameraImage coming soon 322393672/0 Engine Protection €7.13
17
 photo_cameraImage coming soon 112728714/0 Screw €1.37
18
 photo_cameraImage coming soon 322055168/0 Front Plate €1.64
18
 photo_cameraImage coming soon 322055252/0 Front Plate €1.74
20
 photo_cameraImage coming soon 113300215/0 Scraper €5.66
Page 3 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 3
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 322291032/0 Upper Half Handle €14.72
1
 photo_cameraImage coming soon 322291070/0 Upper Half Handgrip Switch €18.14
2
 photo_cameraImage coming soon 381600521/0 Dead Hand Switch €34.42
2
 Dead Hand Switch for Lawnmower Alpina AL1 38 E 381600521/1 Dead Hand Switch for Lawnmower Alpina AL1 38 E €43.89
3
 photo_cameraImage coming soon 322291033/0 Lower Half Handle €14.72
3
 photo_cameraImage coming soon 322291035/0 Lower Half Handle €17.93
3
 photo_cameraImage coming soon 322291071/0 Lower Half Handgrip Switch €17.82
4
 photo_cameraImage coming soon 112728713/0 Screw €1.37
5
 photo_cameraImage coming soon 381007514/1 Handle Lower Part €7.42
5
 photo_cameraImage coming soon 381007515/0 Handle, Lower Side €7.92
6
 photo_cameraImage coming soon 122192000/1 Clamp €1.62
7
 photo_cameraImage coming soon 112523050/0 Washer €2.05
8
 photo_cameraImage coming soon 122524352/0 Pin €3.41
9
 photo_cameraImage coming soon 322319519/0 Fixing Lever Handle €2.37
9
 photo_cameraImage coming soon 322319519/1 Fixing Lever Handle €2.06
10
 photo_cameraImage coming soon 122943016/0 Screw €1.49
11
 photo_cameraImage coming soon 322246100/0 Joint €3.32
11
 photo_cameraImage coming soon 322246102/0 Handle Joint €3.57
12
 photo_cameraImage coming soon 122430210/0 Bearing €1.52
13
 photo_cameraImage coming soon 322745052/0 Right Joint €6.09
13
 photo_cameraImage coming soon 322745055/0 Right Joint €6.67
14
 photo_cameraImage coming soon 112728714/0 Screw €1.37
15
 photo_cameraImage coming soon 322745051/0 Left Joint €6.09
15
 photo_cameraImage coming soon 322745056/0 Left Joint €7.32
16
 photo_cameraImage coming soon 122943017/0 Screw €1.38
18
 photo_cameraImage coming soon 118566112/0 Polyethylene Push Road €1.62
19
 photo_cameraImage coming soon 381007513/0 Handle Lower Part €7.36
20
 photo_cameraImage coming soon 381007514/0 Handle, Lower Side right €6.97
20
 photo_cameraImage coming soon 381007514/1 Handle Lower Part €7.42
21
 photo_cameraImage coming soon 112521320/0 Washer €1.74
Page 4 zoom_in View exploded local_shipping Usually Ships in: 10/15 BUSINESS DAYS
Esploso pagina 4
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
1
 photo_cameraImage coming soon 112728699/0 Screw €1.66
3
 photo_cameraImage coming soon 112523020/0 Washer €1.74
4
 photo_cameraImage coming soon 118563696/1 Electric Motor 1600W From 01-September 2012 To 31-August 2017 €174.38
4
 photo_cameraImage coming soon 118563696/2 1600W Electric Motor €109.78
5
 Hub Fan for Lawnmower Alpina AL1 38 E 322465602/1 Hub Fan for Lawnmower Alpina AL1 38 E €5.70
6
 photo_cameraImage coming soon 181004154/0 Finned blade €17.89
6
 photo_cameraImage coming soon 181004160/0 Blade €17.78
7
 Blade Boss Hub Bolt for Lawnmower Alpina AL1 38 E 381004352/1 Blade Boss Hub Bolt for Lawnmower Alpina AL1 38 E €4.00
9
 Belt for Electric Lawnmower Alpina BL 380 E 118810092/0 Belt for Electric Lawnmower Alpina BL 380 E €14.80
