P8K
Power Converter
8000 W water cooled power converter for our large capacity high frequency tools. Accepts 3-phase 380V for full power, and can also accept 3-phase 230V and single phase 230V at reduced power. Converts the mains supply to high frequency to control the motor.
Accepts 3-phase 380V, 3-phase 230 V, and single-phase 230V
Full electronic protection for over and under voltage, thermal and current overload
Built-in PRCD
LCD Information Display shows voltage, elapsed hours, error codes, etc.
Adaptor cable for single phase supply included
Use P8K with C18 concrete saw and R16 ring saw

In the following table, look for the model of the Concrete Grinderl and the respective parts of the code.

MODEL：P8K (AGP Europe) POWER CONVERTER Version 1.6
NO.	Code	Parts Name
1.)	0206-232504300-01	POWER SUPPLY CABLE
2.)	305-00007-000-009	CABLE GLAND
3.)	403-M05012001-140	PANHEAD TAPPING SCREW-A (M5x12)
4.)	0202-0126-00000-002	ENCLOSURE (RED-187C)
5.)	205-0001-00004-003	STRAP (BLACK)
6.)	406-M05020080-160	SOCKET CAP SCREW (M5x20xP0.8)
7.)	406-M04010070-160	SOCKET CAP SCREW (M4x10xP0.7)
8.)	425-040000-00	SPRING WASHER (M4)
9.)	0299-0259-0001-001	BRACKET
10.)	204-0026-00000-002	MIL-SPEC SOCKET RECEPTACLE
11.)	418-M05000080-080	NYLOCK NUT (M5xP0.8)
12.)	302-04205-000-002	TETHER
13.)	303-01240-004-002	BAYONET COLLAR
14.)	303-02009-004-095	O-RING (AS-137)
15.)	0299-0258-0001-001	CAP
16.)	403-M04012003-080	PANHEAD TAPPING SCREW-B (M4x12)
17.)	418-M04000070-080	NYLOCK NUT (M4xP0.7)
18.)	302-03251-901-001	FAN BRACKET
19.)	305-00303-000-004	FAN
20.)	406-M04012070-080	SOCKET CAP SCREW (M4x12xP0.7)
21.)	0205-0025-00000-001	MOLDED GASKET (Ø2 x 33cm)
22.)	0205-0025-00000-002	MOLDED GASKET (Ø2 x 63cm)
23.)	0203-0143-00026-001	COVER - PANEL
24.)	303-01031-000-004	WINDOW (65x35x1)
25.)	304-04006-000-007	LCD DISPLAY
26.)	403-M04008002-050	PANHEAD TAPPING SCREW-C (M4x8)
27.)	406-M06035100-080	SOCKET CAP SCREW (M6x35xP1.0)
28.)	424-071310-20	FLAT WASHER (Ø6.5xØ13x1)
29.)	303-02017-004-001	FOOT (BLACK)
30.)	418-M06000100-080	NYLOCK NUT (M6xP1.0)
31.)	406-M04020070-080	SOCKET CAP SCREW (M4x20xP0.7)
32.)	303-01384-026-001	COVER
33.)		N/A
34.)		N/A
35.)		N/A
36.)		N/A
37.)	0299-0276-0000-001	ELECTRONICS UNIT
38.)	407-M05010080-080	PANHEAD MACHINE SCREW (M5x10xP0.8)
39.)	0206-031503025-01	ADAPTOR CABLE
40.)	0299-0273-00251-001	DRAIN HOSE
41.)	432-M04000-00	RUBBER WASHER (Ø4xØ11x1)
42.)	304-04042-000-001	BUTTON
