ABAC

ABAC Parts for Air Compressor 50 Lt Montecarlo B20 BASELINE

SKU: B20 BASELINE 1129100006
€10.39
VAT included

ABAC Parts for Air Compressor 50 Lt Montecarlo B20 BASELINE

Rely on our experience and our professionalism, take care of your ABAC Air Compressor 50 Lt Montecarlo B20 BASELINE - 1129100006 by choosing only original spare parts. Buy in total safety and pay without worries all spare parts needed for maintenance are Guaranteed Original.
ABAC Parts for Air Compressor 50 Lt Montecarlo B20 BASELINE
  • ABAC Parts for Air Compressor 50 Lt Montecarlo B20 BASELINE
  • ABAC Parts for Air Compressor 50 Lt Montecarlo B20 BASELINE - Tank Diagram
  • ABAC Parts for Air Compressor 50 Lt Montecarlo B20 BASELINE - Motor Diagram
ABAC

ABAC Parts for Air Compressor 50 Lt Montecarlo B20 BASELINE

SKU: B20 BASELINE 1129100006 Condition: New
€10.39
VAT included

ABAC Parts for Air Compressor 50 Lt Montecarlo B20 BASELINE

Rely on our experience and our professionalism, take care of your ABAC Air Compressor 50 Lt Montecarlo B20 BASELINE - 1129100006 by choosing only original spare parts. Buy in total safety and pay without worries all spare parts needed for maintenance are Guaranteed Original.
settings 33 spare parts
description 2 exploded views
picture_as_pdf Download Exploded PDF
ITEM CODE
Quantity
Usually Ships in: 10 Business Days Approx.

SHIPPING IN:: Usually Ships in: 10 BUSYNESS DAYS
MORE INFO:: [email protected]
verified_user
Original Product Manufacturer warranty included
support_agent
Technical Support Our team helps you choose
Secure and guaranteed payments
Visa Mastercard PayPal Bonifico Cash on delivery
Share this product

Know someone who might need this product? Share it!

Share on Facebook
search
33 spare parts
Page 1 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 1
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
51
 photo_cameraImage coming soon 1129102504 PLUG €10.39
52A
 ABAC - BALMA Rubber Foot D.22 1127360004 ABAC - BALMA Rubber Foot D.22 €4.36
52
 photo_cameraImage coming soon 1129102497 RUBBER FOOT €11.12
53
 photo_cameraImage coming soon 1129700324 DISCHARGE TAP 3/8”R €9.28
54
 ABAC MONTECARLO B20 Baseline Wheel D.150 1129704075 ABAC MONTECARLO B20 Baseline Wheel D.150 €8.64
59
 photo_cameraImage coming soon 1129701301 Infeed cable €34.24
60
 photo_cameraImage coming soon 1127190006 CHECK VALVE €37.23
61
 photo_cameraImage coming soon 1127230001 RILSAN TUBE €8.78
62
 photo_cameraImage coming soon 1129700631 NUT €7.67
63
 photo_cameraImage coming soon 1129700343 INFEED HOSE €12.15
64
 ABAC Nut M16 for Montecarlo L20 1129700325 ABAC Nut M16 for Montecarlo L20 €1.54
65
 photo_cameraImage coming soon 1127040107 OGIVE €6.28
66
 ABAC Safety Valve M1-4-9Bar 1129700303 ABAC Safety Valve M1-4-9Bar €10.71
67
 Pressure Switch 8 Bar B15/B20 for Compressors ABAC 1129701904 Pressure Switch 8 Bar B15/B20 for Compressors ABAC €24.91
68
 photo_cameraImage coming soon 1129700330 FITTING €6.73
69
 Pressure Regulator for ABAC Air Compressors 25/50 lt 1127100064 Pressure Regulator for ABAC Air Compressors 25/50 lt €25.39
71
 photo_cameraImage coming soon 1129700276 TAP €13.26
72
 ABAC Gauge D.40MM 1127110003 ABAC Gauge D.40MM €8.64
73
 photo_cameraImage coming soon 1127110008 PRESSURE GAUGE D40 X R1/4 AL €7.46
101
 photo_cameraImage coming soon 1129702030 INFEED HOSE €21.56
102
 photo_cameraImage coming soon 1124080301 WHEEL KIT D.150 €22.47
Page 2 zoom_in View exploded local_shipping Usually Ships in: 10 BUSYNESS DAYS
Esploso pagina 2
touch_app Click on the exploded view to buy spare parts
Pos. Item Price Buy
900
 photo_cameraImage coming soon 1124080116 Valve Plates kit B20 €48.83
901
 photo_cameraImage coming soon 1124080117 CYLINDER KIT €61.47
904
 photo_cameraImage coming soon 1124190033 CON ROD-PISTON KIT €50.08
906
 photo_cameraImage coming soon 1129703710 HEAD KIT GM146 RED LINE €62.72
909
 photo_cameraImage coming soon 1124080122 Gasket Kits B20 €20.24
911a
 photo_cameraImage coming soon 1129703717 FILTER CARTRIDGE €13.55
913
 photo_cameraImage coming soon 1124080118 FIELD KIT €94.15
914
 photo_cameraImage coming soon 1124080119 FAN COVER KIT €43.58
918
 photo_cameraImage coming soon 1127310032 CAPACITOR - CONDENSER €17.44
919
 photo_cameraImage coming soon 1129703712 CASE COVER KIT €55.61
920
 photo_cameraImage coming soon 1129703714 OIL PLUG €5.07
922
 Start Valve M 3/8 " 1.5 bar for Air Compressor ABAC Montecarlo 50 Lt 1127190601 Start Valve M 3/8 " 1.5 bar for Air Compressor ABAC Montecarlo 50 Lt €10.13

Informazioni sulle spedizioni e consegne saranno disponibili a breve.

ABAC Parts for Air Compressor 50 Lt Montecarlo B20 BASELINE

Rely on our experience and our professionalism, take care of your ABAC Air Compressor 50 Lt Montecarlo B20 BASELINE - 1129100006 by choosing only original spare parts. Buy in total safety and pay without worries all spare parts needed for maintenance are Guaranteed Original.

In the following table, look for the spare parts of the ABAC Air Compressor and the corresponding code.
Montecarlo L20 - 1129100023

ABAC MONTECARLO B20 BASELINE 230V 50Hz - 1129100006 - 01-04-2017 Pag.1
N° Code Descrizione
50 1129703718 TANK
51 1129102504 PLUG 1/2”G
52 1129102497 RUBBER FOOT
52A 1127360004 RUBBER FOOT
53 1129700324 DISCHARGE TAP 3/8”R
54 1129704075 WHEEL D150
55. X SCREW D20× M10
56. X NUT M10
57. X WASHER D10
58. X SCREW ST5X20
59 1129701301 POWER CABLE
60 1127190006 CHECK VALVE
61 1127230001 RILSAN TUBE
62 1129700631 NUT 3/8”G
63 1129700343 INFEED HOSE
64 1129700325 NUT M16
65 1127040107 OGIVE
66 1129700303 RELIEF VALVE
67 1129701904 PRESSURE SWITCH CE
68 1129700330 FITTING
69 1127100064 PRESSURE REDUCER
71 1129700276 TAP
72 1127110003 PRESSURE GAUGE D40 x R1/8 AL
73 1127110008 PRESSURE GAUGE D40 X R1/4 AL
100 1129102625 PUMP UNIT - Alternative code : 1129100014 GM146-50L CE
101 1129702030 INFEED HOSE
102 1129703749 KIT
ABAC MONTECARLO B20 BASELINE 230V 50Hz - 1129102625_00 Pag.2
N° Code Descrizione
900 1124080116 VALVE PLATE KIT
901 1124080117 CYLINDER KIT
904 1124190033 CON ROD-PISTON KIT
906 1129703710 HEAD KIT GM146 RED LINE
911 2236104790 AIR CLEANER KIT
911a 1129703717 FILTER CARTRIDGE
909 1124080122 GASKETS KIT
913 1124080118 FIELD KIT
914 1124080119 FAN COVER KIT
918 1127310032 CAPACITOR - CONDENSER
919 1129703712 CASE COVER KIT
920 1129703714 OIL PLUG
922 1127190601 START VALVE M3/8" - 1,5BAR
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s ABAC websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to ABAC brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
B20 BASELINE 1129100006
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS
MORE INFO:
[email protected]

Specific References

New

Download

Diagram Montecarlo B20 BASELINE

Diagram Montecarlo B20 BASELINE

Download (569.18KB)
