ABAC Pole Position L30P Parts
€0.12
VAT included
ABAC Pole Position L30P Spare Parts
Rely on our experience and professionalism. Take care of your Air Compressor ABAC Pole Position L30P - 1129100045 by choosing original spare parts. Buy safely and choose guaranteed original parts for maintenance.
ABAC Pole Position L30P Parts
€0.12
VAT included
ABAC Pole Position L30P Spare Parts
Rely on our experience and professionalism. Take care of your Air Compressor ABAC Pole Position L30P - 1129100045 by choosing original spare parts. Buy safely and choose guaranteed original parts for maintenance.
settings
80 Spare parts
description
2 exploded views
verified_user
Original Product
Manufacturer warranty included
support_agent
Technical Support
Our team helps you choose
Secure and guaranteed payments
80 spare parts
Page 1
zoom_in View exploded
local_shipping Usually Ships in 10 BUSYNESS DAYS
Page 2
zoom_in View exploded
local_shipping Usually Ships in 10 BUSYNESS DAYS
Shipping and delivery information will be available shortly.
ABAC Pole Position L30P Spare Parts
Rely on our experience and professionalism. Take care of your Air Compressor ABAC Pole Position L30P - 1129100045 by choosing original spare parts. Buy safely and choose guaranteed original parts for maintenance.
In the following table, find the spare parts for the ABAC air compressor and their corresponding codes.
| ABAC Pole Position L30P - 1129100045 Spare Parts | ||
| # | Part Num. | Description |
| 50 | 9700003763 | Tank 24L |
| 51 | 9100010750 | Plug 1/2”G |
| 53 | 9700001574 | Ball valve 3/8” |
| 54 | 9700003748 | Wheel D150 |
| 54A | 9700003580 | Wheel hub cover |
| 55 | 9700003804 | Screw D16× M10 |
| 55A | 9700003805 | Washer |
| 56 | 7020080000 | Nut M10 |
| 57 | 7030040000 | Washer D10 |
| 58 | 7012290000 | Screw ST5x20 |
| 59 | 9100010400 | Power cable |
| 60 | 9100010500 | Check valve |
| 61 | 7230010000 | Rilsan pipe D6 |
| 62 | 9700000328 | Nut 1/2”G |
| 63 | 7231660000 | Feed pipe D14 |
| 64 | 9700000326 | Nut 1/2”G |
| 65 | 7041170000 | Olive |
| 66 | 7192270000 | Safety valve 10.5bar |
| 67 | 9700000388 | CE pressure switch |
| 68 | 9700000330 | Fitting |
| 69 | 7100640000 | Pressure reducer |
| 71 | 9700000276 | Universal tap |
| 72 | 7110240000A | Pressure gauge D40 |
| 73 | 7110300000A | Pressure gauge D50 |
| 74 | 7360090000 | Rubber foot |
| 75 | 7011220000 | Screw M6 |
| 76 | 7030190000 | Washer D6 |
| 77 | 9100930130 | Knob |
| 78 | 7021010000 | Nut M6 |
| 100 | 1129102621 | PUMP UNIT GM302 V230/50HZ - L30P |
| 101 | 1129704854 | Feed pipe kit |
| Motor Pump Page 2 | ||
| # | Part Num. | Description |
| 1A | 9700010186 | Washer D6 |
| 2 | 9700002651 | Aftercooler |
| 3 | 1127150076 | Plate |
| 4 | 1127210301 | Filter element |
| 5 | 1127150077 | Intake filter |
| 6 | 7012100000 | Screw ST4.2x19 |
| 6A | 7010650000 | Screw ST4x16 |
| 7 | 9100250080 | START valve 2.2bar |
| 8 | 2234900007 | Head |
| 9 | 7070600000 | Gasket |
| 10 | 9100010240 | Valve plate |
| 11 | 9100010080 | Gasket 0.2mm |
| 12 | 9100010370 | Reed valves |
| 12A | 9100280090 | Reed valves |
| 13 | 9100020140 | Gasket 0.5mm |
| 14 | 9100020030 | Cylinder Ф55 |
| 15 | 7020070000 | Nut M8 |
| 16 | 7078150000 | Gasket 1mm |
| 17 | 4080030000 | Piston ring Ф55 |
| 18 | 9100020120 | Piston |
| 19 | 9100020080 | Piston pin |
| 20 | 9100010580 | Snap ring D13 |
| 21 | 9100020070 | Connecting rod |
| 22 | 2234900005 | Cover |
| 23 | 6214833200 | Bearing 6205 |
| 25 | 2234900047 | Crank |
| 26 | 1127150073 | Shroud |
| 26A | 1127150075 | Shroud |
| 26B | 1127150074 | Shroud |
| 27A | 9700010089 | Plastic cover |
| 28 | 1127650018 | Crankcase cover |
| 29 | 7012160000 | Screw M6x12 |
| 30 | 9700010187 | Screw M5x14 |
| 31 | 2234900048 | O-ring |
| 32 | 9100010430 | Oil seal d25xD52x10 |
| 33 | 2234900004 | Crankcase |
| 34 | 9700003772 | Rotor |
| 35 | 2234900053 | Motor 230V/50Hz |
| 36 | 7060010000 | Bearing 6203-2RS/2RZ |
| 37 | 7310550000 | Capacitor |
| 38 | 9700010188 | Nut M8 |
| 38A | 9700010184 | Washer D8 |
| 40 | 2234900058 | Tie rod M6x140 |
| 41 | 7200070000 | Fan |
| 42 | 9700002031 | Screw ST4.2×9.5 |
| 42A | 9700010183 | Washer D4 |
| 43 | 9100010050 | Stud bolt M8x36 |
| 44 | 9100270280 | O-ring |
| 45 | 7011420000 | Screw M6x16 |
All product specifications in this catalog are based on information from official sources, including the official manufacturer’s ABAC websites. Official documents may contain mistakes or printing errors, and we cannot confirm that all data is precise. Manufacturers may change product specifications without notice. Please check important parameters with our sales team before purchasing. All content in this catalog is the intellectual property of www.bricoutensili.com. Reproduction without reference to the source is prohibited.
1129100045
